12V Power

This 2 conductor removable connector can be used to power the
KP-4000 with a wall adapter in an installation where PoE is not
available. You must run an additional two conductor cable to the
KP-4000 to utilize this feature. Connect a spliced power adapter
12Volt, 1AMP with the polarity (Positive & Negative) connected cor-
rectly.
-
+
12V 1A – Connect to the + conductor of a 12V, 1 Amp DC wall adapter.
GND – Connect to the – conductor of a 12V, 1 Amp DC wall adapter.
Page 7
