Cable Routing Procedures for
Dell™ PowerEdge™ T610 Systems
A Dell™ Technical White Paper
Dell™ │ Datacenter Infrastructure Engineering
By Chris Kitten and Jose L. Flores
March 2011

Advertisement

Table of Contents

   Related Manuals for Dell PowerEdge Metered

   Summary of Contents for Dell PowerEdge Metered

  • Page 1 Cable Routing Procedures for Dell™ PowerEdge™ T610 Systems A Dell™ Technical White Paper Dell™ │ Datacenter Infrastructure Engineering By Chris Kitten and Jose L. Flores March 2011...
  • Page 2 ERRORS AND TECHNICAL INACCURACIES. THE CONTENT IS PROVIDED AS IS, WITHOUT EXPRESS OR IMPLIED WARRANTIES OF ANY KIND. © 2011 Dell Inc. All rights reserved. Reproduction of this material in any manner whatsoever without the express written permission of Dell Inc. is strictly forbidden. For more information, contact Dell.
  • Page 3: Table Of Contents

    Cable Routing Procedures for Dell™ PowerEdge™ T610 Systems Contents Introduction ................................2 Section 1: Cabling a Dell™ PowerEdge™ T610 With a Cable Management Arm (CMA) ..........2 Connecting the CMA Cables to the System ....................2 Routing the Power Cables Through the Strain Reliefs ................. 3 Installation of the CMA ..........................
  • Page 4: Introduction

    If you are not using the CMA, following these procedures will ensure secure attachment and strain relief of the cables behind Best Practices the system. For guidelines on how to route cables within the rack, refer to the Dell Guide for Rack Enclosures white paper.
  • Page 5: Routing The Power Cables Through The Strain Reliefs

    Refer to Section 3 for details on power supply replacement. Best Practices Guide for NOTE: For guidelines on how to route cables within the rack, refer to the Dell Rack Enclosures white paper...
  • Page 6: Figure 3: Routing The Cables Through The Cma

    Cable Routing Procedures for Dell™ PowerEdge™ T610 Systems 5. Clip off the excess length of material from the tie wraps. Make sure that the heads of the tie wraps are positioned so as to avoid interference with adjacent systems. Return the CMA to the closed (retracted) position.
  • Page 7: Section 2: Cabling A Dell™ Poweredge™ T610 System Without A Cma

    Section 2: Cabling a Dell™ PowerEdge™ T610 System Without a CMA NOTE: The CMA on Dell™ PowerEdge™ T610 systems is optional. Without the CMA installed, the system must be powered down and all cables disconnected before it can be removed from the rack.
  • Page 8: Section 3: Replacing A Power Supply On A Poweredge™ T610 System With A Cma

    Cable Routing Procedures for Dell™ PowerEdge™ T610 Systems Section 3: Replacing a Power Supply on a PowerEdge™ T610 System With a NOTE: The steps described below apply to the bottom power supply only when the CMA is installed to the left side. If the CMA is attached to the right side, both power supplies can be removed without removal of the CMA.
