M-T203 Series

NEW
M-T203
M-T203A
M-T203
Base Mechanism
10
T
hermal Printers
Thermal printers feature quiet operation and high throughput. Excellent for high-resolution graphics,
our thermal printers render beautifully crisp, clear logo marks and barcodes. The simplicity of the
paper path mechanism makes paper refills and maintenance easy. EPSON offers a wide variety of
thermal printers. You're sure to find one for your application needs.
1 -STATION PRINTER
Thermal Line
M-T203
with Paper Roll Holder
SPECIFICATIONS
Well fitted for ECR application
Through over 30 years experiences in ECR application of mini-printers,
M-T203 and T203A are designed to fit ECR usage. Print speed of 100
mm/sec. is high enough for receipt issuance. Durability of metal frame have
ECR's quite reliable.
Drop in, but ease of design
M-T203 and T203A have drop-in paper set mechanism with hinge. Users do
not have to be worry about designing drop-in paper set by themselves, you
can have best matching in design of paper loading mechanism totally.
Ultra thin autocutter (M-T203A only)
EPSON's new autocutter is extremely thin, only 6 mm. It keeps mechanism
height as without. Durability of the autocutter is 0.6 million cuts.
Variety of configuration
M-T203 series are provided with 5 standard configurations (factory option)
which help users to design ECR or other kinds of terminals quite easily (see
below). Full modular type will give you quick placement of whole printer
related mechanism in one time.
M-T203 M-T203A
with Journal Unit Base Mechanism
Paper Width
Resolution
80 mm / sec. max.
Printing Speed
(at 24 V)
Voltage
Reliability (MCBF)
Overall Dimensions 77.3 (W) x 174.5 (D) x 164.8 (H) mm
Mass Approx. 350 g (Take-up Paper Holder)
Best fit for ECR
M-T203A
with Paper Roll Holder
M-T203
57.5 ± 0.5 mm
8 dots / mm
100 mm / sec. max.
24 VDC ± 2.4 V
6
15 x 10 lines
83.1 (W) x 176 (D) x 113.8 (H) mm
Approx. 370 g (Paper Holder)
M-T203A
(at 24 V)
