Model Number Description

All products are identified by a multiple character model
number listed on the unit nameplate. An explanation of the
alphanumeric identification code is provided below. Its use
can define the unit's specific components, type of applica-
tion, i.e. CV or VAV, for a particular unit.
Sam ple Model No.: S X H F - C20 4 0 A 1
Digit No.: 1 2 3 4 5,6,7 8 9 10 11 12 13 14 15 16 17 18 19 20 21+
Digit 1 - Unit Type
S = Self-Contained
Digit 2 - Unit Function
A = DX Cooling, No Heat
E = DX Cooling, Electric Heat
F = DX Cooling, Natural Gas Heat
L = DX Cooling, Hot Water Heat
S = DX Cooling, Steam Heat
X = DX Cooling, Extended Cas ings
# = DX Cooling, Propane Gas Heat
Digit 3 - Unit Airflow
H = Single-Zone
Digit 4 - Development Sequence
F = Six th
Digits 5, 6, 7 - Nominal Capacity
C20 = 20 Tons C55 = 55 Tons
C25 = 25 Tons C60 = 60 Tons
C30 = 30 Tons C70 = 70 Tons
C40 = 40 Tons C75 = 75 Tons
C50 = 50 Tons
Digit 8 - Power Supply
4 = 460/60/3 XL
5 = 575/60/3 XL
E = 200/60/3 XL
F = 230/60/3 XL
Note: SEHF units (unit with
electric heat) utiliz ing 208V or
230V require dual power source.
Digit 9 - Heating Capacity
Note: When the second digit
calls for "F" (Gas Heat), the
follow ing values apply:
Additionally, please note G and
M available ONLY on 50 Ton
models and above.
H = High Heat - 2 Stage
L = Low Heat - 2 Stage
0 = No Heat
J = Limited Modulating High Heat
G = Limited Modulating Low Heat
P = Full Modulating High Heat
M = Full Modulating Low Heat
Note: When the second digit
calls for "E" (electric heat), the
follow ing values apply:
D = 30 KW R = 130 KW
H = 50 KW U = 150 KW
L = 70 KW V = 170 KW
N = 90 KW W = 190 KW
Q = 110 KW
Note: When the second digit calls
"L" (Hot Water) or "S" (Steam)
Heat, one of the following valve
size values must be in Digit 9:
High Heat Coil: 1 = 50", 2 = .75",
3 = 1", 4 = 1.25", 5 = 1.5", 6 = 2".
Low Heat Coil: A = .50", B = .75",
C = 1", D = 1.25", E = 1.5", F = 2".
1. Available as standard 460 volt only for 70 and 75 ton models.
0 A 1 5 B 1
Digit 10 - Design Sequence
3 = Dis connect Redes ign
Note: Sequence may be any letter
A thru Z, or any digit 1 thru 9.
Digit 11 - Exhaust Option
0 = None
1 = Barometric
2 = 100% - 1.5 HP*
3 = 100% - 3 HP*
4 = 100% - 5 HP*
5 = 100% - 7.5 HP*
6 = 100% - 10 HP*
7 = 100% - 15 HP*
8 = 100% - 20 HP*
A = 50% - 1.5 HP
B = 50% - 3 HP
C = 50% - 5 HP
D = 50% - 7.5 HP
E = 100% - 1.5 HP**
F = 100% - 3 HP**
G = 100% - 5 HP**
H = 100% - 7.5 HP**
J = 100% - 10 HP**
K = 100% - 15 HP**
L = 100% - 20 HP**
# = 50% w/ Statitrac
* w/Statitrac
** w/o Statitrac (CV only )
Digit 12 - Exhaust Fan Drive
0 = None 8 = 800 PRM
4 = 400 RPM 9 = 900 RPM
5 = 500 RPM A = 1000 RPM
6 = 600 RPM B = 1100 RPM
7 = 700 RPM
Digit 13 - Filter Type
A = Throwaway
B = Cleanable Wire Mes h
C = High-Efficienc y Throwaway
D = Bag with Prefilters
E = Cartridge with Prefilters
F = No Filters (T/A Rack Only)
G = No Filters (Bag/Cart. Rack O nly)
Digit 14 - Supply Fan Horsepower
1 = 3.0 HP 6 = 20.0 HP
2 = 5.0 HP 7 = 25.0 HP
3 = 7.5 HP 8 = 30.0 HP
1
4 = 10.0 HP 9 = 40.0 HP
5 = 15.0 HP
Digit 15 - Supply Fan Drive
5 = 500 RPM B = 1100 RPM
6 = 600 RPM C = 1200 RPM
7 = 700 RPM D = 1300 RPM
8 = 800 RPM E = 1400 RPM
9 = 900 RPM F = 1500 RPM
A = 1000 RPM G = 1600 RPM
Digit 16 - Fresh Air Section
A = No Fresh Air
B = 0-25% Manual
D = 0-100% Ec onomizer

General Information

When ordering replacement parts or requesting service, be
sure to refer to the specific model number, serial number,
and DL number (if applicable) stamped on the unit name-
plate.
D 0 1 A,R,L,etc.
Digit 17 - System Control
1 = CV Control (Zone Control)
2 = VAV-(S/A Temp Control
without Inlet Guide Vanes)
3 = VAV-(S/A Temp Control
with Inlet Guide Vanes)
4 = Space Press ure Control with Exhaus t VFD
without By pass
5 = Space Press ure Control with Exhaus t VFD
and Bypas s
6 = VAV Supply Air Temperature Control
with VFD w/o Bypas s
7 = VAV Supply Air Temperature Control
with VFD and Bypass
8 = Supply and Exhaus t Fan with VFD
without Bypass
9 = Supply and Exhaus t Fan with VFD
and By pas s
Digit 18 - Accessory Panel
0 = None
A = BAYSENS008*
B = BAYSENS010*
C = BAYSENS013*
D = BAYSENS014*
E = BAYSENS019*
F = BAYSENS020*
G = BAYSENS021*
Digit 19 - Ambient Control
0 = Standard
1 = 0 Degree Fahrenheit
Digit 20 - Agency Approval
0 = None (UL Gas Heater, s ee note)
1 = UL
2 = CSA
Note: Includes UL clsssified gas heating
section only when second digit of
Model No. is a "F".
Digits 21 - 38 - Miscellaneous
21 A = Unit Disc onnec t Switc h
22 B = Hot Gas Bypas s
23 C = Economizer Control w/Comparative
Enthalpy
23 Z = Economizer Control w/Reference
Enthalpy
23 W = Economiz er Control w/Dry Bulb
23 O = None W/O Economiz er
24 E = Low Leak Fres h Air Dampers
25 F = High Duct Temperature Thermos tat
26 G = High Capacity Ev aporator Coil
27 H = Copper Fins (Cond. only)
28 K = Generic B.A.S. Module
29 L = High-Efficiency Motors (Supply & Exhaust)
30 M = Remote Human Interfac e
31 N = Ventilation Override Module
32 R = Extended Grease Lines
33 T = Acc es s Doors
34 V = Interproc ess or Communic ations Bridge
35 0 = No c ommunication module
35 Y = Trane Communic ation Interfac e Module
35 7 = LonTalk® Communication Interface Module
36 8 = Spring Is olators
37 6 = Factory-Powered 15A G FI Conv enienc e
O utlet
38 0 = None
