Intel Desktop Board DH55PJ Technical Product Specification
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Conventional PCI bus add-in card connector
B PCI Express x1 add-in card connector
C Battery
D PCI Express x1 add-in card connector
E PCI Express x16 add-in card connector
F Back panel connectors
G 12 V internal power connector (ATX12V)
H Rear chassis fan header
I LGA1156 processor socket
J Processor fan header
K DDR3 Channel A, DIMM 0 socket
L DDR3 Channel B, DIMM 0 socket
M Front chassis fan header
N Main power connector (2 x 12)
O Parallel port header
P Chassis intrusion header
Q SATA connectors
R BIOS setup configuration jumper block
S Alternate front panel power LED header
T Front panel header
U Standby power LED
V Front panel USB headers (3)
W Intel H55 Express Chipset
X Piezoelectric speaker
Y Serial port header
Z S/PDIF header
AA Front panel audio header
BB Internal mono speaker header
