Compaq Evo n410c - Notebook PC Software Manual page 71

Setup and Diagnostic Utilities
5. Select a test mode:
❏
❏
6. Select the Begin Testing button.
7. To view a test report after a test has run, select a tab:
❏
❏
❏
8. To save a test report:
❏
❏
9. To print a test report:
❏
❏
6–12
◆
To run all tests for your selected device, select the
Check All button.
◆
To run only the tests you select, select the Uncheck
All button, then select the check box for each test you
want to run.
Interactive Mode provides maximum control over the
testing process. You determine whether the test has been
passed or failed. You may be prompted to insert or
remove devices.
Unattended Mode does not display prompts. If errors are
found, they are displayed when testing is complete.
The Status tab summarizes the tests that have been run,
passed, and failed during the current testing session.
The Log tab lists the tests that have been run on the
system, the number of times each test has run, the
number of errors found on each test, and the total run
time of each test.
The Error tab lists all errors found on the notebook with
their error codes.
Select the Log tab Save button to save a Log tab report.
Select the Error tab Save button to save an Error tab
report.
If the report is on the Log tab, select File > Save As, then
print the file from your folder.
If the report is on the Error tab, select the Error tab Print
button.
Software Guide
