Use the following procedures to unpack and assemble your
U
NPACKING
Position the shipping carton so the "Heavy End" logo is located at the bottom. Open the top of the carton and fold back all four
flaps. Carefully tilt the box forward so that the box may be lifted to expose the cycle. Remove all parts from the shipping carton
and foam inserts, and verify that the following parts are included in your shipment:
Assembly Parts
V-bike Parts List
Description
Main Frame Assembly (not shown)
A. Handlebar
B. Seat
C. Handlebar Post
D. Seat Post
E. Back Leg
F. Front Leg
G. Leveling Adjusters (pre-installed)
H. Pedals (set of two)
Spare Parts Kit- Save the box of spare parts in a safe place so you have service parts when needed in the future.
Take time now to enter your V-bike
member). If parts are missing, or if you have any operational questions, please call Star Trac's Service department at (800) 503-
1221; have your serial number ready.
Serial No._____________________________________________
Page 5
S
ETUP
S
ETUP

ASSEMBLY AND SETUP

®
STAR TRAC V-BIKE SPINNER.
Qty.
1
1
1
1
1
1
1
4
1
Spinner serial number in the space below (serial number is located on the bottom cross
® ®
Spare Parts Kit
Description
I. Tension Handles w/Washers
J. Tension Handles w/o Washers
K. Water Bottle Brackets
L. 8mm x 70mm (long) w/Washer and Nuts
M. 8mm x 60mm (short) w/o Washer and Nuts
N. Allen Wrenches, Metric
O. Multi-Purpose Wrench
P. Spare Parts Kit
(includes brake pad and pedal straps)
STAR TRAC GROUP CYCLES OWNER'S GUIDE
_
Qty.
2
2
2
2
2
2
1
1
