- Page 1 V-bike Spinner ® ® Spinner® Pro Spinner® Elite Spinner® NXT ’ WNER UIDE...
-
Page 2: Table Of Contents
Parts Replacement ................19 Page 2 STAR TRAC GROUP CYCLES OWNER’S GUIDE... -
Page 3: Introduction
WARNING Your STAR TRAC group cycle is designed for aerobic exercise. Please check with your physician before beginning any exercise program. Do not push yourself to excess. Stop if you feel faint, dizzy or exhausted. Use common sense when exercising on the cycle. -
Page 4: Safety Instructions
NSTRUCTIONS The following fitness safeguards and operating precautions are directed to purchasers and users of STAR TRAC group cycles. Club Managers should ensure that members and fitness staff are trained to follow these same instructions. Failure to follow these safeguards may result in injury or serious health risk. -
Page 5: Assembly And Setup
(serial number is located on the bottom cross ® ® member). If parts are missing, or if you have any operational questions, please call Star Trac’s Service department at (800) 503- 1221; have your serial number ready. Serial No._____________________________________________ Page 5 STAR TRAC GROUP CYCLES OWNER’S GUIDE... - Page 6 Position the seat on top of the seat post and secure in place using a tension handle and washer. NOTE: Tighten the tension handles firmly. Step 4 Page 6 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
- Page 7 Repeat to install the left-side water bottle holder. Step 6 You have now completed the assembly of your STAR TRAC V-BIKE ® SPINNER ® Page 7 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
-
Page 8: Spinner ® Pro / Elite / Nxt Assembly And Setup
H. Spare Parts Kit (includes brake pad and pedal straps) Spare Parts Kit- Save the box of spare parts in a safe place so you have service parts when needed in the future. Page 8 STAR TRAC GROUP CYCLES OWNER’S GUIDE... - Page 9 (serial number is located on the bottom cross ® ® member). If parts are missing, or if you have any operational questions, please call Star Trac’s Service department at (800) 503- 1221; have your serial number ready. Serial No._____________________________________________ NOTE: If you are missing any of the parts listed above, inspect the packing material and the box for items that may have been overlooked.
- Page 10 (under bolt head and nut), to secure the front leg assembly to the frame. Tighten all hardware securely using a torque wrench to 85 Inch Pounds Step 2 (NXT) Page 10 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
- Page 11 Turn the left pedal spindle counterclockwise when threading into the left crank arm; turn the right pedal spindle clockwise when threading into the right crank arm. Step 4 Page 11 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
- Page 12 Position a water bottle holder in place against the frame assembly, and re-install the two screws to secure. Repeat to install the cross member water bottle holder. Step 6 Page 12 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
- Page 13 You have now completed the assembly of your STAR TRAC SPINNER PRO / ELITE / NXT ® SPINNER PRO SPINNER ELITE SPINNER NXT Testing the Bike Use this checklist to perform the bike test procedure. Recheck all the bolts and make sure they are all tightened to the proper torque specification and no parts are missing.
-
Page 14: Instructions For Use
NSTRUCTIONS FOR Your STAR TRAC group cycle is easy to use. Simply sit on the cycle, tighten the pedal straps and begin pedaling. The cycle allows the user full control over resistance by simply adjusting the brake pad. Typically, lower resistance levels enable you to pedal at a faster pace, placing increased demand on the cardiovascular system. -
Page 15: Handlebar Adjustments
SMART RELEASE™ SYSTEM (Spinner Elite) Allows the benefits of the direct drive system with a safety clutch to release the crank from the ® direct drive when a force is applied to the pedals. Page 15 STAR TRAC GROUP CYCLES OWNER’S GUIDE... -
Page 16: Smart Release™ System
Push down on the Push Brake System knob until the pedals come to a complete stop. ™ (Spinner Elite only) Apply back pressure to the pedals to engage the Smart Release system. Continue applying ® pressure until the pedals and flywheel come to a complete stop. Page 16 STAR TRAC GROUP CYCLES OWNER’S GUIDE... -
Page 17: Maintenance
Check the following parts for security and/or proper torque. Crank arms Use a foot pound torque wrench, tighten to 30 - 35 foot-pounds. Pedals Use a pedal wrench. Verify that the pedal is not cross-threaded. Page 17 STAR TRAC GROUP CYCLES OWNER’S GUIDE... - Page 18 Inspect brake pad for wear. Excessive wear, such as glazing or leather separation, indicates replacement is required. Inspect seat pad for wear. Rips, tears or excessive movement indicates replacement is required. Inspect pedals for play. Excessive movement of pedals indicates replacement is required. Page 18 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
-
Page 19: Adjustments
2. Using the Multi-Purpose Wrench, remove the two bolts supporting the brake pad onto the frame ). Installation 1. Carefully re-install the two bolts through the brake pad bracket onto the frame. Tighten by using the Multi-Purpose Wrench. Page 19 STAR TRAC GROUP CYCLES OWNER’S GUIDE... - Page 20 NOTE: When the alignment is at the optimal adjustment the chain will run smoother and quieter. 8. Tighten the adjustment lock nuts and the axle nuts on both sides alternating from side to side. 9. Install the chain guard and test the bike. Page 20 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
- Page 21 8. Lift the chain up onto the rear large sprocket. 9. Proceed to chain adjustment. Page 21 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
- Page 23 STAR TRAC 14410 Myford Road Irvine, California 92606 Telephone: (800) 228-6635, (714) 669-1660 Fax: (714) 508-3303 http://www.startrac.com August 2006 Part Number 620-7302, Rev. B October 2004 Page 2 STAR TRAC GROUP CYCLES OWNER’S GUIDE...
