MOVING AND LEVELING
To move the cycle to a new location:
Lift the cycle from the rear and use the front wheels (located on the front leg, below the handlebar) to roll the cycle from one location
to another.
To level the cycle:
Use the four leveling adjusters (located on the underside of the front and rear legs) to compensate for uneven floor surfaces.

PARTS REPLACEMENT

B P R
RAKE AD EPLACEMENT
Removal
1. Remove tension from the brake pad by turning the Push Brake System knob counterclockwise, until
completely loose.
2. Using the Multi-Purpose Wrench, remove the two bolts supporting the brake
pad onto the frame ).
Installation
1. Carefully re-install the two bolts through the brake pad bracket onto the frame.
Tighten by using the Multi-Purpose Wrench.
Page 19 STAR TRAC GROUP CYCLES OWNER'S GUIDE
