Star Trac V-bike Spinner Owner's Manual page 21

Chain Replacement
CAUTION: Do not get your fingers caught in the chain or sprockets.
1. Remove the chain guard by unscrewing the chain guard screws.
2. Apply tension to the brake knob by turning it all the way clockwise so the
flywheel does not turn.
3. Using the 16mm or 5/8" socket and socket wrench
loosen the axle nuts on the sides of the flywheel.
4. Using the 10mm open end wrench, loosen the lock
nuts on the chain adjustment screws.
5. Loosen the adjustment bolt to allow the chain to go
very slack.
6. Using the chain break tool cut the chain open and
remove the chain from the bike.
7. Put the new chain on the front sprocket and over the
crank arm but not onto the large rear sprocket if the
chain contains a master link, insert the master link
and tighten it making sure the two links are joined
and are flexible.
8. Lift the chain up onto the rear large sprocket.
9. Proceed to chain adjustment.
