Memory DIMM Installation Instructions For DIMM Part Numbers 64 MB: 70043001 128 MB: 70043101 256 MB: 70043201 59382902...
Page 2
Installation Caution! Circuit boards can be damaged by static electricity and rough handling. Keep the board in its packaging until you're ready to install it. Installation Mise en garde! Les cartes de circuit imprimé peuvent êtres endommagées par l'électricité statique et une manipulation brutale. Conservez le module dans l’emballage jusqu’à...
Page 3
C53_Off_Unplug_USB.jpg 1. Turn off the printer (1). 2. Unplug the power cord (2). 3. Detach the interface cable from the back of the printer (3). 1. Éteignez l'imprimante (1). 2. Débranchez le cordon d'alimentation (2). 3. Débranchez le câble d'interface à l'arrière de l'imprimante (3).
Page 4
c53_02a_opencvr.jpg 4. Open the top cover. 4. Ouvrez le capot supérieur. 4. Abra la tapa superior. 4. Abra a tampa superior.
Page 5
c5x_016.jpg 5. Open the front cover. 5. Ouvrez le capot avant. 5. Abra la tapa delantera. 5. Abra a tampa frontal.
Page 6
c51_07_unscrewpanel.jpg 6. Loosen the thumbscrew holding the printer side cover in place. 6. Desserrez les vis à ailettes fixant le couvercle latéral de l’imprimante en place. 6. Afloje el tornillo de mariposa mientras sostiene la tapa lateral de la impresora en su lugar. 6.
Page 7
c5x_017.jpg 7. Lift up on the ends. Remove the side panel from the printer. 7. Soulevez les extrémités. Retirez le panneau latéral de l’imprimante. 7. Levante por los bordes. Retire el panel lateral de la impresora. 7. Levante segurando nas extremidades. Retire o painel lateral da impressora.
Page 8
8. Locate the DIMM socket. 8. Repérez le connecteur de module de mémoire DIMM. 8. Ubique el conector DIMM. c51_06_sidenopanel.jpg and c53_107_dimmsocket.jpg 8. Localize o soquete para memória DIMM.
Page 9
9. Push out the lock tabs at either end of the DIMM socket. 9. Poussez vers l’extérieur les languettes de blocage aux deux extrémités du connecteur de module de mémoire DIMM. c51_04a_dimmtabs.jpg and c53_107a_dimmsocket.jpg 9. Libere las lengüetas de sujeción a ambos lados del conector DIMM.
Page 10
Caution! To avoid damage, ground yourself (touch metal) before handling DIMMs. 10. Remove the DIMM from its shipping package. Mise en garde! Pour ne pas les endommager, reliez-vous à la terre (touchez du métal) avant de manipuler les modules DIMM 10.
Page 11
c51_03_dimm.jpg 11. Position the DIMM as shown. 11. Positionnez le module de mémoire DIMM tel que montré. 11. Coloque la DIMM en la forma que se indica. 11. Posicione a memória DIMM como ilustrado.
Page 12
c53_109a_dimminsert.jpg 12. Insert the DIMM in the socket. Press the DIMM in firmly, until you feel the tabs snap to lock it in place. Note: You may need to push the tabs in manually to secure the DIMM. 12. Insérez le module dans le connecteur. Appuyez fermement sur celui-ci jusqu’à...
Page 13
c51_07_unscrewpanel.jpg 13. Place the side panel on the printer. Use the thumbscrew to secure the panel. 13. Ce le panneau latéral de l’imprimante. Utilisez les vis à ailettes pour fixer le panneau. 13. Vuelva a colocar el panel lateral de la impresora. Utilice el tornillo de mariposa para fijar el panel.
Page 14
c5x_016.jpg 14. Close the front cover. 14. Fermez le capot avant. 14. Cierre la tapa delantera. 14. Feche a tampa frontal.
Page 15
c53_45_latchcvr.jpg 15. Close the top cover. 16. Attach the interface cable. 17. Plug in the power cord. 18. Turn on the printer. Next, go to “Verify the Installation” on page 16. 15. Fermez le capot supérieur. 16. Rebranchez le câble d'interface. 17.
Verify the Installation Print the MenuMap Note: The MenuMap is a list of the current menu settings. Keypad.eps 1. Press one or more times until INFORMATION MENU displays. 2. Press ENTER twice. The MenuMap prints. 3. Look at the top of the printout. Find the Total Memory Size. Total Memory Size = Standard Memory + Additional Memory.
Page 17
Change the Driver Setting ® Windows Postscript Emulation Driver 1. Click Start → Settings → Printers [Printers and Faxes for XP]. 2. Right click the appropriate printer icon. Click Properties. Windows XP, 2000 and NT 4.0 a. Click the Device Settings tab. b.
Page 18
Change the Driver Setting ® Macintosh Mac OS 9.1+ 1. Activate Chooser from the Apple menu. 2. Select LaserWriter 8. 3. Click Printer → Setup. 4. Click Configure. 5. Select Memory Configuration in the Change drop down menu. Select the new total memory installed to enable the option.
Page 19
Change the Driver Setting Mac OS X.3+ 1. Activate the Printer Setup Utility from Local Hard Drive → Applications → Utilities → Printer Setup Utility. 2. Highlight the printer name. Select from the menu Printers → Show Info. 3. Next to Memory Configuration, click on the drop drown menu. Select the new total memory installed to enable the option.
Vérification de l’installation Impression de MenuMap Note: La liste des menus (MenuMap) comprend la liste des paramètres de menu courants. Keypad.eps 1. Appuyez sur + une ou plusieurs fois jusqu’à ce que INFORMATION MENU s’affiche. 2. Appuyez deux fois sur ENTER. La Menu Map s'imprime.
Page 21
Modification du paramètre de pilote ® Windows Pilote d'émulation PostScript 1. Cliquez sur Start (Demarrer) → Settings (Paramètres) → Printers (Imprimantes) [Imprimantes et télécopieurs dans Windows XP] 2. Cliquez du droit sur l'icône d'imprimante. Cliquez sur Propriétés Windows XP, 2000 et NT 4.0 a.
Page 22
Modification du paramètre de pilote ® Macintosh Mac OS 9.1+ 1. Accédez au Chooser (Sélecteur) dans le menu Apple (Pomme). 2. Sélectionnez LaserWriter 8. 3. Cliquez sur Printer (Imprimante) → Setup (Réglages). 4. Cliquez sur Configure (Configurer). 5. Dans le menu déroulant Change (Modifier), sélectionnez Memory Configuration (Configuration mémoire).
Page 23
Modification du paramètre de pilote Mac OS X.3+ 1. Activez Printer Setup Utility (l'utilitaire de configuration de l’imprimante) en accédant à Local Hard Drive (Disque dur local) → Applications → Utilities (Utilitaires) → Printer Setup Utility (Utilitaire de configuration de l’imprimante). 2.
Page 24
Verifique la instalación Imprima el MenuMap Note: El MenuMap contiene una lista de las configuraciones actuales del menú. Keypad.eps 1. Presione el botón una o más veces hasta que aparezca el mensaje INFORMATION MENU (MENU DE INFORMACIÓN). 2. Presione el botón ENTER dos veces. MenuMap se imprime.
Page 25
Cambie la configuración del controlador ® Windows Controlador de emulación Postscript 1. Haga clic en Start (Inicio) → Settings (Configuración) → Printers (Impresoras) [Printers and Faxes (Impresoras y Faxes) bajo XP]. 2. Haga clic con el botón derecho en el icono de la impresora apropiado. Haga clic en Properties [Propiedades].
Page 26
Cambie la configuración del controlador Windows 98: a. Haga clic en la ficha Device Options (Opciones de dispositivo). b. Busque la opción Installable Options (Opciones instalables). Haga clic en VMOptions. c. Seleccione el total de nueva memoria recién instalada de la lista desplegable. Total Memory Size (Memoria total) = Standard Memory (Memoria estándar) + Additional Memory (Memoria adicional).
Page 27
Cambie la configuración del controlador Mac OS X a X.1 No es necesario activar. Mac OS X.2 1. Active el Print Center (Centro de Impresión) desde Local Hard Drive (Disco duro local) → Applications (Aplicaciones) → Utilities (Utilidades) → Print Center (Centro de Impresión).
Page 28
Verifique a instalação Imprima a estrutura do menu Note: A estrutura dos menus (MenuMap) é uma lista das configurações atuais dos menus. Keypad.eps 1. Pressione uma ou mais vezes até que INFORMATION MENU [MENU DE INFORMAÇÕES] seja exibido. 2. Pressione ENTER duas vezes. A estrutura do menu será...
Page 29
Altere a configuração do driver ® Windows Driver da emulação Postscript 1. Clique em Start (Iniciar) → Settings (Configurações) → Printers (Impressoras) [Printers and Faxes (Impressoras e faxes) no XP]. 2. Clique com o botão direito do mouse no ícone da impressora apropriado. Clique em Properties [Propriedades].
Page 30
Altere a configuração do driver 4. Clique em OK. Feche a caixa de diálogo Printers (Impressoras) [Printers and Faxes (Impressoras e faxes)]. Driver PCL Não é necessário fazer alterações no driver PCL. ® Macintosh Mac OS 9.1+ 1. Ative o Chooser [Seletor] no menu Apple. 2.
Page 31
Altere a configuração do driver Mac OS X.2 1. Ative o Print Center [Centro de impressão] em Local Hard Drive [Disco rígido local] → Applications [Aplicativos] → Utilities [Utilitários] → Print Center [Centro de impressão]. 2. Realce o nome da impressora. Selecione no menu Printers [Impressoras] → Show Info [Mostrar informações].
