Specifications are subject to change without notice or obligation.
Processor and Core Logic
Processor options
Processor packaging
Level 2 cache
Chipset-Northbridge
Chipset-Southbridge
Processor side bus speed
BIOS
SPECIFICATIONS
Gateway 3100/3600 Series
®
One Intel
Celeron™ M CPU
■
-OR-
®
One Mobile Intel
Pentium
■
To determine your notebook's processor, click Start, My Computer,
then click View System Information. The processor is listed.
478-pin uFCPGA
512 KB or 1 MB (Celeron M)
■
-OR-
1 MB or 2 MB (Mobile Pentium M)
■
Intel 910GML (Celeron M)
■
-OR-
Intel 915GM (Pentium M)
■
Intel ICH6-M
400 MHz (Celeron M)
■
-OR-
400/533 MHz (Pentium M)
■
Phoenix BIOS
■
8 MB Flash ROM
■
SMBIOS 2.3 support
■
Advanced Configuration and Power Interface 2.0 (ACPI 2.0)
■
support
Wired for Management 2.0 (WfM 2.0)
■
www.gateway.com
Notebook
®
M CPU
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Gateway 3100 Series
Summary of Contents for Gateway 3100 Series
-
Page 1: Specifications
SPECIFICATIONS Gateway 3100/3600 Series Notebook Specifications are subject to change without notice or obligation. Processor and Core Logic ® Processor options One Intel Celeron™ M CPU ■ -OR- ® ® One Mobile Intel Pentium M CPU ■ To determine your notebook’s processor, click Start, My Computer, then click View System Information. - Page 2 Auto dim on battery and auto bright on AC power (selectable in ■ BIOS) External video Supports dual display and dual view External CRT resolutions Supports standard IBM VGA compatible modes × Maximum resolution: 2048 1536 Maximum color depth: 32-bit colors External CRT maximum refresh rate 85 Hz www.gateway.com...
- Page 3 Operating channels: 11 channels in the United States and Canada Security: 128 and 64 bit WEP encryption, WPA, and WPA2 Operating Frequency: 2.4 GHz Direct Sequence Spread Spectrum (IEEE 802.11b and IEEE 802.11g) Maximum Data Rate 54 Mbps (IEEE802.11g) ■ 11 Mbps (IEEE802.11b) ■ www.gateway.com...
- Page 4 Full-sized 86-keys ■ 19 mm × 19 mm key pitch ■ 3.0 mm key travel ■ Pointing device Gateway EZ-Pad™ touchpad with vertical scroll ■ 2-button design ■ Status indicators keyboard combination turns status indicators on and off. AC power ■...
- Page 5 A DVD logo in combination with a CD-R/RW logo indicates a DVD drive that also is a recordable/rewritable CD drive, and a DVD+ReWritable logo in combination with a CD-R/RW logo indicates a recordable/rewritable DVD drive that also is a recordable/rewritable CD drive. www.gateway.com...
- Page 6 PC 2001 compliant ■ ® CPU may support Intel Speedstep™ technology ■ Controls Icon on taskbar shows battery charge as a percentage remaining Power switch Supports Power On/Off, Standby/Resume, Hibernate using Windows Setting, Shutdown Lid switch LCD On/Off, Standby, Hibernate www.gateway.com...
- Page 7 ° Operating temperature F to 90 F (10 C to 32 ° ° ° ° Storage temperature F to 140 F (-15 C to 60 Operating humidity 20% to 80% relative humidity; no condensation MAN 3100/3600 SER SPECS 6/05 www.gateway.com...
