Printing Guide
Get the most from your printer by properly loading the trays and properly setting the types and sizes of media.
Loading the 250‑ or 550‑sheet tray
CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays
closed until needed.
1
Pull out the tray.
Notes:
•
When loading folio‑, legal‑, or oficio‑size paper, lift the tray slightly and pull it out.
•
Do not remove trays while a job prints or while Busy appears on the display. Doing so may cause a jam.
Printing Guide
Page 1 of 16

Advertisement

loading

Related Manuals for Lexmark MS810de

Summary of Contents for Lexmark MS810de

  • Page 1 Printing Guide Page 1 of 16 Printing Guide Get the most from your printer by properly loading the trays and properly setting the types and sizes of media. Loading the 250‑ or 550‑sheet tray CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed.
  • Page 2 Printing Guide Page 2 of 16 Squeeze and slide the width guide to the correct position for the size of the paper being loaded until it clicks into place. Note: Use the paper size indicators on the bottom of the tray to help position the guides.
  • Page 3 Printing Guide Page 3 of 16 Unlock the length guide, and then squeeze and slide the guide to the correct position for the size of the paper being loaded. Notes: • Lock the length guide for all paper sizes. • Use the paper size indicators on the bottom of the tray to help position the guides.
  • Page 4 Printing Guide Page 4 of 16 Flex the sheets back and forth to loosen them. Do not fold or crease the paper. Straighten the edges on a level surface. Load the paper stack with the printable side facedown. Note: Make sure the paper or envelope is loaded properly. •...
  • Page 5 Printing Guide Page 5 of 16 • If you are loading envelopes, then make sure that the flap side is facing up and the envelopes are on the left side of the tray. • Make sure the paper is below the maximum paper fill indicator. Warning—Potential Damage: Overfilling the tray can cause paper jams.

  • Page 6: Loading The 2100-Sheet Tray

    Printing Guide Page 6 of 16 Insert the tray. From the printer control panel, set the paper size and type in the Paper menu to match the paper loaded in the tray. Note: Set the correct paper size and type to avoid paper jams and print quality problems. Loading the 2100‑sheet tray CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately.
  • Page 7 Printing Guide Page 7 of 16 Squeeze and slide the length guide to the position for A5 until it clicks into place. Remove the A5 length guide from its holder. Insert the A5 length guide into its designated slot. Note: Press the A5 length guide until it clicks into place.
  • Page 8 Printing Guide Page 8 of 16 Loading A4‑, letter‑, legal‑, oficio‑, and folio‑size paper Pull up and slide the width guide to the correct position for the size of the paper being loaded. If the A5 length guide is still attached to the length guide, then remove it from its place. If the A5 length guide is not attached, then proceed to step d.
  • Page 9 Printing Guide Page 9 of 16 Put the A5 length guide in its holder. Squeeze the length guide and slide it to the correct position for the size of the paper being loaded until it clicks into place. Flex the sheets back and forth to loosen them. Do not fold or crease the paper. Straighten the edges on a level surface.
  • Page 10 Printing Guide Page 10 of 16 Load the paper stack with the printable side facedown. Note: Make sure the paper is loaded properly. • There are different ways for loading letterhead depending on whether an optional staple finisher is installed or not. Without an optional staple finisher With an optional staple finisher One‑sided printing One‑sided printing...
  • Page 11 Printing Guide Page 11 of 16 • Make sure the paper is below the maximum paper fill indicator. Warning—Potential Damage: Overfilling the tray can cause paper jams. Insert the tray. Note: Press the paper stack down while inserting the tray.

  • Page 12: Loading The Multipurpose Feeder

    Printing Guide Page 12 of 16 From the printer control panel, set the paper size and type in the Paper menu to match the paper loaded in the tray. Note: Set the correct paper size and type to avoid paper jams and print quality problems. Loading the multipurpose feeder Pull down the multipurpose feeder door.
  • Page 13 Printing Guide Page 13 of 16 Pull the multipurpose feeder extender. Note: Guide the extender gently so that the multipurpose feeder is fully extended and open. Slide the width guide to the correct position for the size of the paper being loaded. Note: Use the paper size indicators on the bottom of tray to help position the guides.
  • Page 14 Printing Guide Page 14 of 16 Prepare the paper or specialty media for loading. • Flex sheets of paper back and forth to loosen them. Do not fold or crease the paper. Straighten the edges on a level surface. • Hold transparencies by the edges.
  • Page 15 Printing Guide Page 15 of 16 • Load only one size and type of paper or specialty media at a time. • Make sure the paper fits loosely in the multipurpose feeder, lies flat, and is not bent or wrinkled. •...

  • Page 16: Setting The Paper Size And Type

    Printing Guide Page 16 of 16 • Make sure the paper or specialty media is below the maximum paper fill indicator. Warning—Potential Damage: Overfilling the feeder can cause paper jams. For custom- or universal-size paper, adjust the width guides to lightly touch the sides of the stack. From the Paper menu on the printer control panel, set the paper size and type in the Paper menu to match the paper loaded in the tray.
