Lexmark MS812dn Reference

Technical reference
Hide thumbs Also See for MS812dn:
Table of Contents

Advertisement

Quick Links

See also: Administrator's Manual , Information Manual
MS710dn, MS711dn,
MS810n/dn/dtn/de,
MS811n/dn/dtn, MS812dn/dtn/de,
MX710de/dhe, MX711de/dhe,
MX810de, MX811de, MX812de
Technical Reference
August 2013
www.lexmark.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS812dn and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexmark MS812dn

Summary of Contents for Lexmark MS812dn

  • Page 1 MS710dn, MS711dn, MS810n/dn/dtn/de, MS811n/dn/dtn, MS812dn/dtn/de, MX710de/dhe, MX711de/dhe, MX810de, MX811de, MX812de Technical Reference August 2013 www.lexmark.com...

  • Page 2: Edition Notice

    August 2013 The following paragraph does not apply to any country where such provisions are inconsistent with local law: LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

  • Page 3: Table Of Contents

    Appendix A: PCL support...................22 PCL emulation commands..........................22 GL/2 commands..............................28 Appendix B: PJL support..................31 Common variables for both printer languages....................31 Lexmark‑unique PJL variables for both printer languages................33 Common variables for PCL emulation.......................43 Lexmark‑unique variables for PCL emulation....................43 Common variables for PostScript emulation.....................44...
  • Page 4 Contents Lexmark‑unique variables for PostScript emulation..................44 Lexmark‑unique LRESOURCE variables......................44 Status Readback commands..........................44 USTATUS unsolicited status variables.......................45 PJL messages for auto-continuable conditions....................45 PJL messages for attendance conditions......................54 PJL messages for paper handling........................75 PJL messages for paper jams..........................78 Service errors..............................84 Device attendance messages..........................84 Lexmark‑unique PJL commands........................84...

  • Page 5: Introduction

    Introduction Overview This edition of the Technical Reference contains information about the following printers: MS710dn MS711dn MS810n MS810dn MS810dtn MS810de MS811n MS811dn MS811dtn MS812dn MS812dtn MS812de MX710de MX710dhe MX711de MX711dhe MX810de MX811de MX812de Understanding letters after model numbers Some Lexmark printers may have one or more letters after the model number to indicate features.

  • Page 6: Learning About The Printer

    Additional setup and instructions for using the printer: User's Guide and Quick Reference Guide—The guides may be available on the Software and Documentation CD. • Selecting and storing paper and specialty media For more information, visit http://support.lexmark.com. • Loading paper • Configuring printer settings •...
  • Page 7 Find it here Warranty information Warranty information varies by country or region: • In the U.S.—See the Statement of Limited Warranty included with this printer, or at http://support.lexmark.com. • In other countries and regions—See the printed warranty that came with your printer.

  • Page 8: Printer Control Language (Pcl) Page Formatting

    Printer Control Language (PCL) page formatting Printer Control Language (PCL) page formatting For more information on PCL, see the Printer Languages and Interfaces Technical Reference. It contains a complete listing with descriptions of PCL commands. To determine which PCL commands your printer supports, see “Appendix A: PCL support”...
  • Page 9 For the Universal paper size, the area dimensions are listed in pel ranges. Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.

  • Page 10: Printer Job Language (Pjl)

    Printer Job Language (PJL) Printer Job Language (PJL) PJL commands information Your printer supports complete PJL commands, including certain commands that cause the printer to enter PCL emulation, PostScript emulation, and Personal Printer Data Stream (PPDS). For a complete listing with descriptions of PJL commands, see the Printer Languages and Interfaces Technical Reference. To determine which commands your printer supports, see “Appendix B: PJL support”...

  • Page 11: Postscript (Ps) Emulation

    215.9 x 279.4 8.5 x 11.0 612 x 792 Oficio oficio 215.9 x 340.4 8.5 x 13.4 612 x 965 (Lexmark‑unique size) 612 x 972 (official PostScript size) Statement statement 139.7 x 215.9 5.5 x 8.5 396 x 612 Universal 215.9 x 355.6...

  • Page 12: Postscript Paper Tray Support

    PostScript (PS) emulation PostScript paper tray support When the printer receives one of the operators listed in “Tray selected with tray operators” on page 12, it performs the actions listed in this section. This paper tray selection process ends when a suitable paper source is chosen and paper is fed from this tray.

  • Page 13: Postscript Envelope Size Support

    PostScript (PS) emulation = Supported X = Not supported Printer model Operator Tray selected MS710, MS711, MS810, MX710, MX711 MX810, MX811, (corresponding image size MS811, MS812 MX812 is set) customtray Tray with custom-size paper executivetray Tray with executive-size paper foliotray Tray with folio-size paper ledgertray Tray with ledger‑size paper...

  • Page 14: Postscript Envelope Tray Support

    PostScript (PS) emulation Literal names supported = Supported X = Not Supported Literal names Printer model Literal name Compatible literal name MS710, MS711, MS810, MX710, MX711 MX810, MX811, MS811, MS812 MX812 b5envelope 176x250envelope c5envelope 162x229envelope com10envelope 4.125x9.5envelope dlenvelope 110x220envelope monarcenvelope 3.875x7.5envelope PostScript envelope tray support The envelope tray the printer selected when it receives an envelopetray operator is listed in...
  • Page 15 PostScript (PS) emulation = Supported X = Not supported Tray operators Printer model Operator Tray selected (corresponding image size is MS710, MS711, MX710, MX711 MX810, MX811, set) MS810, MS811, MX812 MS812 110x220envelopetray Tray with 110 x 220‑size envelopes dlenvelopetray Tray with 110 x 220‑size envelopes 162x229envelopetray Tray with 162 x 229‑size envelopes c5envelopetray...

  • Page 16: Printer Specifications

    Printer specifications Printer specifications Airflow requirement The room should meet ASHRAE 62—1989 standards. Noise emission levels The following measurements are in accordance with ISO 7779 and in conformance with ISO 9296. 1-meter average sound pressure, dBA Status MS710 MS711 MS810 MS811 MS812 MX710 MX711 MX810 MX811...

  • Page 17: Electrical Specifications

    Warning—Potential Damage: Do not use voltage converters with printers. Power requirements The following table specifies the average nominal power requirements for the base printer, including fuser power. Lexmark MS710dn, MS711dn, MS810dn, MS810de, MS811dn, MS812dn, and MS812de average nominal power requirements State...

  • Page 18: Physical Specifications

    Eco mode 5.0 kwh/wk 5.6 kwh/wk 4.9 kwh/wk 5.6 kwh/wk 6.0 kwh/wk Lexmark MS710dn, MS711dn, MS810dn, MS810de, MS811dn, MS812dn, MS812de, MX710, MX711, MX810, MX811, and MX812 maximum (average) current while printing State MS710dn, MS711dn MS810dn, MS810de, MX710, MX711, MX810, MS811dn, MS812dn, MS812de MX811, MX812 100–110 V...
  • Page 19 Dimensions of the supplies and furniture for MS710, MS711, MS810, MS811, and MS812 Option Height Width Length Weight Supplies shipped with the printer Lexmark Starter Return 125 mm (4.9 in.) 152 mm (6.0 in.) 317 mm (12.5 in.) 0.8 kg (1.8 lb) Program toner cartridge (10K) Imaging unit 83 mm (3.3 in.)

  • Page 20: Clearance Requirements

    Lexmark toner cartridge 125 mm (4.9 in.) 152 mm (6.0 in.) 317 mm (12.5 in.) 0.7 kg (1.5 lb) (6K) Lexmark high yield toner 125 mm (4.9 in.) 152 mm (6.0 in.) 317 mm (12.5 in.) 1.2 kg (2.6 lb) cartridge (25K) Lexmark extra high yield 125 mm (4.9 in.)

  • Page 21: Environmental Conditions

    Printer specifications Environmental conditions Note: When shipping or storing printers, always pack the printer supplies (such as cartridges and photoconductors) separately. Environmental specifications for MS710, MS711, MS810, MS811, MS812, MX710, MX711, MX810, MX811, and MX812 Environment Specifications Air relative humidity 8 to 80% 60 to 90.0°F (15.6 to 32.20°C) Ambient operating environment...

  • Page 22: Appendix A: Pcl Support

    Appendix A: PCL support Appendix A: PCL support PCL emulation commands = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Decimal 8 Backspace (BS) Decimal 9 Horizontal Tab (HT) Decimal 10 Line Feed (LF) Decimal 12...
  • Page 23 Appendix A: PCL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Disable Underline &d@ Collation ‑ Collated Copies &d#A (QTY) Select Underline Type &d#D Set Universal Height &f#F Set Universal Width &f#G...
  • Page 24 Appendix A: PCL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Job Separation & Left (Long-Edge) Offset & Registration Set Copy Count & Top (Short-Edge) Offset & Registration &n#W [operation] [string id] Alphanumeric ID Palette Control...
  • Page 25 Appendix A: PCL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Secondary Font Stroke Weight )s#B Secondary Font Pitch )s#H Secondary Font Spacing )s#P Secondary Font Style )s#S Secondary Font Typeface )s#T...
  • Page 26 Appendix A: PCL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Define Pattern *c#W[data] Picture Frame Horizontal Size *c#X (in Decipoints) Picture Frame Vertical Size *c#Y (in Decipoints) Logical Operation Pixel Placement Color Lookup Tables...
  • Page 27 Appendix A: PCL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Raster Width (Destination) *t#H Gamma Correction *t#I Render Algorithm *t#J Scale Algorithm *t#K Set Resolution *t#R Raster Height (Destination) *t#V Set Raster Configuration...

  • Page 28: Gl/2 Commands

    Appendix A: PCL support GL/2 commands = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Arc Absolute Anchor Corner Define Alternate Font Arc Relative Arc Absolute Three Point Bezier Relative Bezier Absolute Character Fill Circle...
  • Page 29 Appendix A: PCL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Fill Type - 22 Fill Type - 9 Initialize Input P1 and P2 Input Relative P1 and P2 Input Window Line Attributes Label, Default Terminator =...
  • Page 30 Appendix A: PCL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command Function MS812 MX710, MX711 MX812 Select Alternate Font Scalable/Bitmapped Fonts Scale Define Standard Font Absolute Character Size Character Slant Symbol Mode Select Pen Relative Character Size Select Standard Font...

  • Page 31: Appendix B: Pjl Support

    Appendix B: PJL support Appendix B: PJL support Common variables for both printer languages = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 AUTOCONT AUTOSELECT BINDING BITSPERPIXEL CLEARABLEWARNINGS CONTEXTSWITCH COPIES CPLOCK DENSITY...
  • Page 32 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 INTRAY2SIZE INTRAY3SIZE INTRAY4SIZE INTRAY5SIZE IOBUFFER IOSIZE JOBATTR JOBNAME JOBOFFSET LANG LOWTONER MANUALFEED MEDIASOURCE MEDIATYPE MPTRAY ORIENTATION OUTBIN PAGEPROTECT PAPER...

  • Page 33: Lexmark-Unique Pjl Variables For Both Printer Languages

    MX710, MX711 MX812 RESERVEJOBTIMEOUT RESOLUTION RESOURCESAVE RESOURCESAVESIZE STRINGCODESET TIMEOUT USERNAME VERIFYJOBTIMEOUT WIDEA4 Lexmark‑unique PJL variables for both printer languages = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LA5LOADING...
  • Page 34 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LBONDWEIGHT LBOTTOMMARGINOFFSET LBWLOCK LCANCEL LCARDSTOCKLENGTH LCARDSTOCKLOADING LCARDSTOCKOUTBIN LCARDSTOCKTEXTURE LCARDSTOCKWEIGHT LCOLLATION LCOLORBALANCEBLACK LCOLORBALANCECYAN LCOLORBALANCEMAGENTA LCOLORBALANCEYELLOW LCOLORCORRECTION LCOLOREDLENGTH LCOLOREDLOADING LCOLOREDOUTBIN LCOLOREDTEXTURE...
  • Page 35 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LCUSTOMTYPE1NAME LCUSTOMTYPE1OUTBIN LCUSTOMTYPE1TEXTURE LCUSTOMTYPE1WEIGHT LCUSTOMTYPE2LENGTH LCUSTOMTYPE2LOADING LCUSTOMTYPE2MEDIA LCUSTOMTYPE2NAME LCUSTOMTYPE2OUTBIN LCUSTOMTYPE2TEXTURE LCUSTOMTYPE2WEIGHT LCUSTOMTYPE3LENGTH LCUSTOMTYPE3LOADING LCUSTOMTYPE3MEDIA LCUSTOMTYPE3NAME LCUSTOMTYPE3OUTBIN LCUSTOMTYPE3TEXTURE LCUSTOMTYPE3WEIGHT LCUSTOMTYPE4LENGTH...
  • Page 36 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LCUSTOMTYPE5OUTBIN LCUSTOMTYPE5TEXTURE LCUSTOMTYPE5WEIGHT LCUSTOMTYPE6LENGTH LCUSTOMTYPE6LOADING LCUSTOMTYPE6MEDIA LCUSTOMTYPE6NAME LCUSTOMTYPE6OUTBIN LCUSTOMTYPE6TEXTURE LCUSTOMTYPE6WEIGHT LDOWNLOADTARGET LDRYTIMEDELAY LDUPLEXLEFTMARGINOFFSET LDUPLEXTOPMARGINOFFSET LDUPLICATEHELDJOBS LECOMODE LENVELOPEENHANCE LENVELOPELENGTH LENVELOPEOUTBIN...
  • Page 37 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LFONTDENSITY LGLOSSYLOADING LGLOSSYOUTBIN LGLOSSYTEXTURE LGLOSSYWEIGHT LHEAVYGLOSSYLOADING LHEAVYGLOSSYOUTBIN LHEAVYGLOSSYTEXTURE LHEAVYGLOSSYWEIGHT LHEAVYPAPERLOADING LHEAVYPAPEROUTBIN LHEAVYPAPERTEXTURE LHEAVYPAPERWEIGHT LHELDJOBPRTORDER LHIBERNATETIMEOUT LHIBERNATETIMEOUTOVERRIDE LHOLEPUNCHALARM LHOLEPUNCHMODE LHONORINIT...
  • Page 38 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LJAMASSIST LJAMRECOVERY LJOBPARKPERSIST LJOBWAITFORSUPPLIES LLABELSLENGTH LLABELSLOADING LLABELSOUTBIN LLABELSTEXTURE LLABELSWEIGHT LLASTTRAYRENUMBER LLEFTMARGINOFFSET LLETTERHEADLENGTH LLETTERHEADLOADING LLETTERHEADOUTBIN LLETTERHEADTEXTURE LLETTERHEADWEIGHT LLIGHTPAPERLOADING LLIGHTPAPEROUTBIN LLIGHTPAPERTEXTURE...
  • Page 39 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LMANUALPAPERTYPE MICRJOB LMAXSTATUSMSG LMPFEEDERPAPERTYPE LMPFEEDERRENUMBER LMULTIPAGEBORDER LMULTIPAGEORDER LMULTIPAGEPRINT LMULTIPAGEVIEW LNPAP LOPTIONALOUTBIN1NAME LOPTIONALOUTBIN2NAME LOPTIONALOUTBIN3NAME LOPTIONALOUTBIN4NAME LOPTIONALOUTBIN5NAME LOPTIONALOUTBIN6NAME LOPTIONALOUTBIN7NAME LOPTIONALOUTBIN8NAME LOPTIONALOUTBIN9NAME...
  • Page 40 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LPAPERSOURCE LPICTUREGRADE LPLAINLENGTH LPLAINOUTBIN LPLAINTEXTURE LPLAINWEIGHT LPOWERSAVER LPPDS LPPDSFORMLINES LPPDSLINESPERINCH LPREPRINTEDLENGTH LPREPRINTEDLOADING LPREPRINTEDOUTBIN LPREPRINTEDTEXTURE LPREPRINTEDWEIGHT LPRINTBUFFER LPRINTSCREENS LPRINTHEADIDLETIME LPRINTERUSAGE...
  • Page 41 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LREPEATPRINTLIMIT LRESET LRESOURCESAVE LRIGHTMARGINOFFSET LROUGHENVELOPELOADING LROUGHENVELOPEOUTBIN LROUGHENVELOPETEXTURE LROUGHENVELOPEWEIGHT LROUGHPAPERLOADING LROUGHPAPEROUTBIN LROUGHPAPERTEXTURE LROUGHPAPERWEIGHT LSCREENING LSEPARATORSHEETS LSEPARATORSOURCE LSMALLFONTENHANCER LSSGALVO LSTANDARDOUTBINNAME LSTAPLE...
  • Page 42 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 LTRAY1AUTOSIZE LTRAY2AUTOSIZE LTRAY3AUTOSIZE LTRAY4AUTOSIZE LTRAY5AUTOSIZE LTRAY1PAPERTYPE LTRAY2PAPERTYPE LTRAY3PAPERTYPE LTRAY4PAPERTYPE LTRAY5PAPERTYPE LTRAY1RENUMBER LTRAY1SENSEDTYPEPAPER LTRAY1SENSEDTYPETRANSPARENCY LTRAY2SENSEDTYPEPAPER LTRAY2SENSEDTYPETRANSPARENCY LTRAY3SENSEDTYPEPAPER LTRAY3SENSEDTYPETRANSPARENCY LTRAY4SENSEDTYPEPAPER LTRAY4SENSEDTYPETRANSPARENCY...

  • Page 43: Common Variables For Pcl Emulation

    MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 FONTNUMBER FONTSOURCE PITCH PTSIZE SYMSET Lexmark‑unique variables for PCL emulation = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812...

  • Page 44: Common Variables For Postscript Emulation

    MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812 ADOBEMBT JAMRECOVERY PRTPSERRS Lexmark‑unique variables for PostScript emulation = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Variable name MS812 MX710, MX711 MX812...

  • Page 45: Ustatus Unsolicited Status Variables

    Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command MS812 MX710, MX711 MX812 INQUIRE USTATUS USTATUSOFF USTATUS JOB USTATUS unsolicited status variables = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811,...
  • Page 46 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention Required 30016 Insufficient memory, some Held Jobs were Insufficient Memory deleted [37] Memory low, some held jobs lost [37]...
  • Page 47 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention Required 30016 Some held jobs were not restored Held Jobs May Not Be Restored Some held jobs not restored...
  • Page 48 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention Required 30018 Parallel Port Disabled [56] Parallel Port Error Intervention Required 30018 Serial [slot #] Port Disabled [56]...
  • Page 49 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention Required 30034 Incorrect paper size, open [source] [34] Short Paper Paper too short [34] Intervention Required 30075...
  • Page 50 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention Required 30107 Insert Box M Insert Box M Intervention Required 30107 Insert staple cartridge Insert Staple Cartridge Intervention Required...
  • Page 51 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention Required 32001 Operation Failed Jobs on Disk Disk Operation Failed Jobs on Disk Intervention Required 32002 Flash Full [52]...
  • Page 52 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention Required 32052 Unformatted disk [63] Unformatted Disk Intervention Required 32052 Unsupported Disk Format [64] Unsupported Disk Format Intervention Required...
  • Page 53 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention Required 40038 Fuser/Belt Life Warning [80] Fuser/Belt Life Warning Intervention Required 40038 Fuser/Belt Exhausted [80] Fuser/Belt Exhausted...

  • Page 54: Pjl Messages For Attendance Conditions

    Appendix B: PJL support PJL messages for attendance conditions = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 32015 Disk required - corrupted Disk Corrupted. Reformat? Intervention 32030...
  • Page 55 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40019 Remove Required - originals from the Remove Originals scanner from Scanner ADF automatic document feeder...
  • Page 56 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40021 Close door Required - Close Door [x] Intervention 40021 Close stapler Required - door Close Door [x]...
  • Page 57 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40021 Close top Required - access cover and front Close Cover and Door door Intervention 40021...
  • Page 58 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40021 Replace Required - defective cartridge Defective Print [31] Cartridge Intervention 40021 Replace Required - missing...
  • Page 59 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40021 Cartridge Required - part number unsupported Unsupported by device Cartridge [32.xx] Intervention 40021 Tray [x] Size...
  • Page 60 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40027 Install tray Required - Install Tray [x] or Cancel Job Intervention 40027 Install Tray Required -...
  • Page 61 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40030 Tray [x] Required - Config Error [33] Tray Config Error Intervention 40030 Input config Required -...
  • Page 62 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40038 Replace Toner Required - Cartridge Replace Toner Cartridge Intervention 40038 Replace Toner Required - To Continue Replace Toner...
  • Page 63 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40038 Yellow Toner Required - Low [88] Toner Low Magenta Toner Low [88] Cyan Toner Low [88] Black Toner...
  • Page 64 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40050 Replace Fuser Required - Replace Fuser Intervention 40050 Replace Required - Transfer Kit Replace Transfer Kit Intervention...
  • Page 65 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40096 Insert Duplex Required - Option Insert Duplex Option Intervention 40107 Insert the Required - hole punch Insert Hole Punch...
  • Page 66 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40200 black Required - cartridge nearly low Cartridge Nearly Low [88.1x] Intervention 40200 Black Required -...
  • Page 67 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40203 yellow Required - cartridge nearly low Cartridge Nearly Low [88.1x] Intervention 40203 Yellow Required -...
  • Page 68 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40215 Transfer Required - module near life warning Transfer Module [83.xx] Near Life Warning Intervention 40216 Fuser Life...
  • Page 69 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40304 Replace Required - photoconducto r [84] Replace Photoconductor Intervention 40305 Replace black Required - PC Unit [84] 84 Replace Black PC...
  • Page 70 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40311 Replace Required - unsupported magenta Replace unsupported cartridge cartridge [32.xx] Intervention 40311 magenta Required -...
  • Page 71 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40316 Replace Required - maintenance kit, Maintenance Kit EOL recommended (Distinct From AEOL) life exceeded [80.xy] Intervention...
  • Page 72 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40405 Black PC Unit Required - missing [84.41] [Color] PC Unit Missing Intervention 40405 Black...
  • Page 73 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40409 Defective Required - black cartridge Defective Cartridge [31.xx] Intervention 40409 Missing or Required - defective black...
  • Page 74 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MX810, MX811, Message Status code Return string MS810, MS811, MS812 MX710, MX711 MX812 Intervention 40412 Missing Required - yellow cartridge Toner Cartridge and/or yellow Missing imaging unit [30.xx] Intervention 40412...

  • Page 75: Pjl Messages For Paper Handling

    Appendix B: PJL support PJL messages for paper handling = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention 11xyy Tray [paper source Required - #] Empty Tray [x] Empty Intervention 12x01...
  • Page 76 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention 40019 Remove paper from Required - standard output bin Remove Paper From Standard Output Bin Intervention 40019...
  • Page 77 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention 41xyy Load Manual Feeder Required - with [Custom Type Name] [orientation] Load Manual Request Intervention 41xyy...

  • Page 78: Pjl Messages For Paper Jams

    Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Message Status code Return string MS812 MX710, MX711 MX812 Intervention 41xyy Change [paper Required - source] to [Custom String] load Change Request [orientation] Intervention 41xyy...
  • Page 79 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MX810, MX811, Message Status code MS811, MS812 MX710, MX711 MX812 Intervention Required - 4201z Paper Jam Intervention Required - 4202x Paper Jam Intervention Required - 4202z Paper Jam Intervention Required -...
  • Page 80 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MX810, MX811, Message Status code MS811, MS812 MX710, MX711 MX812 Intervention Required - 4231x Paper Jam Intervention Required - 4231z Paper Jam Intervention Required - 4232x Paper Jam Intervention Required -...
  • Page 81 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MX810, MX811, Message Status code MS811, MS812 MX710, MX711 MX812 Intervention Required - 4248w Paper Jam Intervention Required - 4249w Paper Jam Intervention Required - 4250w Paper Jam Intervention Required -...
  • Page 82 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MX810, MX811, Message Status code MS811, MS812 MX710, MX711 MX812 Intervention Required - 4261w Paper Jam Intervention Required - 4261x Paper Jam Intervention Required - 427xz Paper Jam Intervention Required -...
  • Page 83 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MX810, MX811, Message Status code MS811, MS812 MX710, MX711 MX812 Intervention Required - 4283w Paper Jam Intervention Required - 4283x Paper Jam Intervention Required - 4283z Paper Jam Intervention Required -...

  • Page 84: Service Errors

    MS810, MS811, MX810, MX811, Message MS812 MX710, MX711 MX812 RDYMSG OPMSG STMSG Lexmark‑unique PJL commands These commands are Lexmark extensions which have been added to the PJL command set to provide the user with remote control of many printer functions.
  • Page 85 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command MS812 MX710, MX711 MX812 Common file system commands • LFORMAT • LDEFRAG • LOPENFILE • LCLOSEFILE • LREADFILE • LWRITEFILE • LRUNFILE •...
  • Page 86 Appendix B: PJL support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Command MS812 MX710, MX711 MX812 • LPRINTPSFONTS • LPRINTDIAG1TEST • LPRINTDIAG2TEST • LPRINTDIAG3TEST LPROGRAM LPROGRAMADAPTOR LPROGRAMCOFF LPROGRAMENG LPROGRAMRIP LWRITEOM...

  • Page 87: Appendix C: Postscript Support

    Appendix C: PostScript support Appendix C: PostScript support Supplemental operators = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Operator name MS812 MX710, MX711 MX812 appletalktype buildtime byteorder checkpassword currentfilenameextend currentmanualduplexmode currentuniversalsize defaulttimeouts deletefile devcontrol devdismount devforall devformat...
  • Page 88 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Operator name MS812 MX710, MX711 MX812 duplexmode enginesync file filenameforall fileposition firstside fontnonzerowinding hardwareiomode idlefonts ignoresize initializedisk jobname jobsource jobtimeout manualfeed manualfeedtimeout newsheet pagecount pagesprinted...
  • Page 89 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Operator name MS812 MX710, MX711 MX812 resolution revision sccbatch sccinteractive setcoverpage setdefaulttimeouts setdoidlefonts setdojamrecovery setdoprinterrors setdoret setdostartpage setdosysstart setduplexmode setenginesync setethernetaddress setfilenameextend setfileposition sethardwareiomode setidlefonts...

  • Page 90: Page Device Parameters

    Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Operator name MS812 MX710, MX711 MX812 settumble setuniversalsize setuserdiskpercent softwareiomode tumble userdiskpercent waittimeout Page device parameters = Supported X = Not supported Printer model MS710, MS711, MS810, MS811,...
  • Page 91 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 • EdgeToEdge • DefaultPoliciesPageSize • SubstituteSize • LineDetail • Type • ColorCorrection • ColorBalance • ColorSaver • ImageBrightness •...
  • Page 92 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 ‑ MediaColor ‑ MediaType ‑ MediaWeight ‑ InputLocation • Mode • Priority Install ManualFeed ManualFeedTimeout MediaColor MediaPosition MediaType MediaWeight NumCopies NupDetails...
  • Page 93 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 ‑ PunchModesSupported • 1 - Optional Bin 1 ‑ OutputType ‑ OutputLocation • 2 - Optional Bin 2 ‑...
  • Page 94 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 • 10 - Optional Bin 10 ‑ OutputType ‑ OutputLocation • Priority OutputPage OutputType PageDeviceName PageSize Policies • PageSize •...

  • Page 95: User Interpreter Parameters

    Appendix C: PostScript support User interpreter parameters = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Default MS812 MX710, MX711 MX812 AccurateScreens false CollatedCopies Collation - Collated Copies (QTY) value HalftoneMode IdiomRecognition true JobName JobTimeout JobTimeout system parameter MaxDictStack MaxExecStack...

  • Page 96: System Interpreter Parameters

    Appendix C: PostScript support System interpreter parameters = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 BuildTime ByteOrder CurDisplayList CurFontCache CurFormCache CurInputDevice CurOutlineCache CurOutputDevice CurPatternCache CurScreenStorage CurSourceList CurUPathCache DisableFastProcs DoPrintErrors DoStartPage EnableExtraFonts EngineBoot EngineCode...
  • Page 97 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 JobTimeout languagelevel MaxDisplayList MaxDisplayAndSourceList MaxFontCache MaxFormCache MaxImageBuffer MaxOutlineCache MaxPatternCache MaxPermanentVM MaxRasterMemory MaxScreenStorage MaxSourceList MaxUPathCache PageCount PanelCode PrinterCode PrinterName RamSize RealFormat Revision...

  • Page 98: Devices Supported

    Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 UseOldfonts ValidNV WaitTimeout Devices supported = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Device MS812 MX710, MX711...
  • Page 99 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Device MS812 MX710, MX711 MX812 %flash1% %IP_A% %IP_B% %IP_C% %IP_D% %IR_A% %IR_B% %IR_C% %IR_D% %LexLinkA% %LexLinkB% %LexLinkC% %LexLinkD% %LocalTalkA% %LocalTalkB% %LocalTalkC% %LocalTalkD% %LPR_A% %LPR_B% %LPR_C%...
  • Page 100 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, Device MS812 MX710, MX711 MX812 %PrinterServerA% %PrinterServerB% %PrinterServerC% %PrinterServerD% %RemotePrinterA% %RemotePrinterB% %RemotePrinterC% %RemotePrinterD% %rom% %SerialA% %SerialB% %SerialC% %SerialD% %TokenRingPhysicalA% %TokenRingPhysicalB% %TokenRingPhysicalC% %TokenRingPhysicalD% %TokenTalkA% %TokenTalkB% %TokenTalkC%...

  • Page 101: Device Parameters

    Appendix C: PostScript support Device parameters = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 Device Parameters for the Communication Device %Parallel%, %ParallelA%, %ParallelB%, %ParallelC%, %ParallelD% DelayedOutputClose Enabled Filtering Handshake HasNames Interpreter OutputDevice PCLSmartSwitch...
  • Page 102 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 PortLocation PSSmartSwitch RobustXon SerialMode StopBits Type Device Parameters for the Communication Device %LocalTalk%, %LocalTalkA%, %LocalTalkB%, %LocalTalkC%, %LocalTalkD% DelayedOutputClose Enabled Filtering HasNames...
  • Page 103 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 NodeID PCLSmartSwitch PortLocation PSSmartSwitch Type Device Parameters for the Communication Device %IR%, %IR_A%, %IR_B%, %IR_C%, %IR_D% DelayedOutputClose Enabled Filtering HasNames Interpreter...
  • Page 104 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 Device Parameters for the Communication Device %TokenTalk%, %TokenTalkA%, %TokenTalkB%, %TokenTalkC%, %TokenTalkD% Address Bridging DelayedOutputClose Enabled Filtering HasNames Interpreter NodeID PCLSmartSwitch PortLocation...
  • Page 105 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 Enabled Filtering HasNames Interpreter PortLocation Type Device Parameters for the Communication Device %PrintServer%, PrintServerA%, PrintServerB%, %PrintServerC%, %PrintServerD% DelayedOutputClose Enabled Filtering HasNames...
  • Page 106 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 PortLocation Type Device Parameters for the Communication Device %IP%, %IP_A%, %IP_B%, %IP_C%, %IP_D% GatewayAddress IPAddress IPAddressDynamic NetworkMask Physical PortLocation Type Device Parameters for the Communication Device %EthernetPhysical%, %EthernetPhysicalA%, %EthernetPhysicalB%,...
  • Page 107 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 Type Device Parameters for the Parameters Device %Console% Language Type Device Parameters for the Parameters Device %Calendar%, %CalendarA%, %CalendarB%, %CalendarC%, %CalendarD% Hour Minute Month...
  • Page 108 Appendix C: PostScript support = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 Type Writeable Device Parameters for the Parameters Device %flash1% BlockSize Free HasNames InitializeAction LogicalSize Mounted PhysicalSize Removable Searchable SearchOrder Type Writeable...

  • Page 109: Postscript Message Keys Commands

    Appendix C: PostScript support PostScript message keys commands = Supported X = Not supported Printer model MS710, MS711, MS810, MS811, MX810, MX811, MS812 MX710, MX711 MX812 status source...

  • Page 110: Index

    33 PJL, attendance conditions 54 LRESOURCE 44 USTATUS variables 45 PJL, auto-continuable conditions 45 PJL, Lexmark‑unique variables for PCL PJL commands, information location PJL, device attendance 84 emulation 43 Printer Languages and Interfaces PJL, paper handling 75 PJL, Lexmark‑unique variables for...
  • Page 111 Index noise emission levels 16 power requirements 17 publications where to find 6 required clearance 20 shipping and storage ranges 21 shock specification 21 size, printer 18 supplemental operators PostScript 87 tray operators PostScript 12 weight, printer 18...
