Sceptre X20 Manual

Sceptre X20 Manual

Lcd monitor
Hide thumbs Also See for X20:

Advertisement

Quick Links

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
This device may not cause harmful interference
This device must accept any interference received, including interference that
my cause undesired operation.
Please Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the
receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Caution: To comply with the limits for an FCC Class B computing device,
always use the signal cord and power cord supplied with this unit.
The Federal communications Commission warns that changes or modifications
to the unit not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
European Notice
CE mark for Class B ITE (Following European standard EN55022/1998;
EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998,
EN60950/1992+A1+A2+A3+A4+A11)
SCEPTRE X20
Page1

Advertisement

loading

Summary of Contents for Sceptre X20

  • Page 1 European Notice CE mark for Class B ITE (Following European standard EN55022/1998; EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998, EN60950/1992+A1+A2+A3+A4+A11) SCEPTRE X20 Page1...
  • Page 2 Regulation of the Canadian Department of Communications. “Le présent appareil numérique n’èmet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class B prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada." Page2 SCEPTRE X20...
  • Page 3 SCEPTRE X20 Page3...
  • Page 4 Page4 SCEPTRE X20...
  • Page 5 X20 LCD MONITOR and to protect it Do not overload power strips and from overheating, be sure these openings extension cords. Overloading can result in are not blocked or covered. Do not place fire or electric shock. SCEPTRE X20 Page5...
  • Page 6 Display changes substantially. Avoid using dropped or damaged Operating environment: Temperature: 5°C appliances. If the product is dropped and ~ 35°C, Humidity: 10% to 90% the housing is damaged, the internal non-condensing, Altitude: 0~10,000 ft. components may function abnormally. Page6 SCEPTRE X20...
  • Page 7 ) .......................25 - 2 ..................26 ( 1 - " 2 ((....................26 ................27 2 (( 1 2 .......................27 ................28 " ................29 " .....................29 ( ) 4 ................32 ....................33 & 5................35 " " 1 & ..............36 " ) ............38 SCEPTRE X20 Page7...
  • Page 8 We hope you enjoy your new SCEPTRE X20 LCD monitor. For technical assistance, please call 1800-788-2878 and select option 3 or email our tech support group at monitor-ts@sceptre.com.
  • Page 9 The SCEPTRE X20 is packaged in a carton together with standard accessories. The weight of the LCD display is approximately 10.36lbs. Since the LCD panel can be easily scratched or broken, please handle the product gently. Never place the unit on a surface with the glass facing downwards unless it is on a protective padding.
  • Page 10 1. Please place the base on a flat surface (i.e. table). 2. Hold the monitor directly 90 degrees above the base. 3. Connect the monitor to the base by inserting the monitor into the base. Page10 SCEPTRE X20...
  • Page 11 Click on OK on all windows to exit. On the monitor, press the M button twice in succession to AUTO ADJUST. Wait until the monitor finishes calibrating. Reboot your computer and your monitor is ready for use. SCEPTRE X20 Page11...
  • Page 12 # # # # 1. Place the monitor on a flat surface with cloth so the bezel does not get scratched. 2. Unscrew the 6 screws that lock the arm to the monitor. Page12 SCEPTRE X20...
  • Page 13 3. Once the 6 screws are removed, the stand will come off and the monitor will be ready for mounting. SCEPTRE X20 Page13...
  • Page 14 " " " " NATIVE RESOLUTION : This monitor’s clearest picture is produced under its native resolution. The native resolution of the monitor is 1680 x 1050 at 60 Hz refresh rate. Page14 SCEPTRE X20...
  • Page 15 POWER – This button turns the monitor ON or OFF. POWER INDICATOR LIGHT – This indicator light turns green when the monitor is turned on. The indicator light turns orange when the monitor is in power saving mode. SCEPTRE X20 Page15...
  • Page 16 The LCD Monitor’s angle settings range from 3 to 15 . Page16 SCEPTRE X20...
  • Page 17 " " " " Mounting Specification : 100mm x 100mm using screw size M4. Length of screw should not exceed 10mm. SCEPTRE X20 Page17...
  • Page 18 VGA – VGA stands for Video Graphics Array. This connection is for computers to send video signals to the monitor by an analog signal. This method of connection is the most commonly used connection. & & & & Cable Name Cable Head Corresponding Connection Picture (digital video) (analog video) Power Cord Page18 SCEPTRE X20...
  • Page 19 Please Note : Some video cards may have their DVI connection turned off by default. If you do not get video, please consult your video card’s technical support. The PC’s clearest picture is produced under 1680x1050 at 60Hz. SCEPTRE X20 Page19...
  • Page 20 Connect the other end of the cable to your X20 LCD MONITOR. Turn on the power of both the X20 LCD MONITOR and the PC. Please Note : The PC’s clearest picture is produced under 1680x1050 at 60Hz. Page20 SCEPTRE X20...
  • Page 21 You can use this function by pressing MENU, then press (+) or (–) to select Auto Adjust. Once Auto Adjust is highlighted, press MENU again to use the function. Please Note : This function is only available under VGA. SCEPTRE X20 Page21...
  • Page 22 CONTRAST adjusts the white levels in a picture. If the value is adjusted too high, the picture will not have any details in bright parts of the picture. If set too low, the picture will looked washed out. Page22 SCEPTRE X20...
  • Page 23 PHASE – This option adjusts the video signal in a small increment to sync with the PC. Please Note : It is always suggested for the USER to use the AUTO ADJUST function instead of manual adjustments. This LCD’s native resolution is 1680x1050 at 60 Hz. SCEPTRE X20 Page23...
  • Page 24 5800K – This option adjusts the white balance towards the red color giving the picture a reddish tint and warmer look. USER PRESET – This option lets the user adjust the white balance by tweaking the RED, GREEN, and BLUE color. Page24 SCEPTRE X20...
  • Page 25 H-POSITION – This option moves the OSD menu left or right. V-POSITION – This option moves the OSD menu up or down. OSD TIME – This option change the time which the OSD will remain on screen while idle. SCEPTRE X20 Page25...
  • Page 26 Press the (+) or (–) buttons to select the option you want to recall. Press MENU to enter the option and with the (+) or (–) buttons select Yes to recall. COLOR RECALL – recalls all settings of COLOR function. RECALL ALL – recalls all settings besides COLOR function. Page26 SCEPTRE X20...
  • Page 27 You can switch sources easily by using the SOUCE button on the side of the monitor. This function exits the OSD menu. Select the EXIT function with the (+) or (–) buttons and press MENU to exit. SCEPTRE X20 Page27...
  • Page 28 1680X1050 59.883 64.7 VESA 1680x1050 146.25 59.954 65.29 *Once a mode is optimized, there is no need to make any further adjustment as long as the VGA card remains unchanged. **Specifications are subject to change without notice. Page28 SCEPTRE X20...
  • Page 29 After the setting of RANGE” 60Hz has been change you can then use the LCD on the computer. To change the setting go to display settings by right clicking on your desktop SCEPTRE X20 Page29...
  • Page 30 If your VGA can then, your video card’s THE RESOLUTION DVI cannot support widescreen resolutions. 1680X1050 Sometimes your video card will not read the monitor correctly and will not allow you to achieve the resolution you want. Rebooting your computer will solve the situation. Page30 SCEPTRE X20...
  • Page 31 Sometimes the colors are not correct because your THE COLORS ARE VGA or DVI cable is loose or corrupt. Please try NOT CORRECT reconnecting your cable or swap out your current cable to see if the problem persists. SCEPTRE X20 Page31...
  • Page 32: Cleaning The Screen

    When the screen is dirty to the point where you cannot simply dry wipe it, please lightly dampen the wiping material with clean water and wipe again. Wipe the display with a dry micro-fiber cloth or 100% cotton cloth afterwards. Page32 SCEPTRE X20...
  • Page 33 10.36 lbs (4.7 Kgs) 100V to 240VAC @ 50/60 Hz Max, Power input Features 480i @ 60 Hz 480p @ 60 Hz VIDEO DVI (HDCP) 720p @ 60 Hz 1080i @ 60 Hz 1080p @ 60 Hz SCEPTRE X20 Page33...
  • Page 34 1024 * 768 @ 60, 70, 75 Hz 1152 * 864 @ 75 Hz 1280 * 1024 @ 60, 72 ,75 Hz 1680 * 1050 @ 60 Hz VGA, DVI (HDCP) *Specifications are subject to change without notice. Page34 SCEPTRE X20...
  • Page 35 For more information on warranty services or repairs after the warranty period, please contact our support department at the number below. For technical help, contact our Sceptre Technical Support Group via email or phone. Please have your Sceptre p/n number, serial number, and date of purchase available before you call.
  • Page 36 Service Labor During a period of one (1) year from the effective warranty date, SCEPTRE will provide, when needed, service labor to repair a manufacturing defect at Sceptre’s own Service Center. To obtain warranty service in the Untied States, you must first call our Customer Support at (800) 788-2878.
  • Page 37 SCEPTRE retains the right to assess all warranty claims and to determine if damages are covered by the warranty. In case of a claim that is not covered by the warranty, you will be contacted to determine whether SCEPTRE should repair the damage for a fee or whether the product should be returned to you as received by the repair center.
  • Page 38 Microsoft, Windows are registered trademarks of Microsoft Corporation in the United States and other countries. Sceptre, Inc. shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.
