Sceptre X20G-NAGA2 Manual

20.1” uxga
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Opeartion is subjected to
the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference
that may cause undesired operation.
FCC WARNING
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
inerference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution:
To comply with the limits for an FCC Class B computing device, always use the
shielded signal cord supplied with this unit.
6200517392
i
P
REFACE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X20G-NAGA2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sceptre X20G-NAGA2

Summary of Contents for Sceptre X20G-NAGA2

  • Page 1: Fcc Compliance Statement

    REFACE FCC Compliance Statement This device complies with part 15 of the FCC Rules. Opeartion is subjected to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 The Federal Communications Commission warns that changes or modifications of the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CE mark for Class B ITE (Following European standard EN55022/1998; EN61000- 3-2/1995;...
  • Page 3 Important Operating Instructions Please read the following instructions carefully. This manual should be retained for future use. 1. To clean the LCD monitor screen, first, make sure the monitor is in the power off mode. Unplug the monitor from its power source before cleaning it.

  • Page 4: Table Of Contents

    Table of Contents PREFACE ......................I CHAPTER 1....................... 1 Unpacking Identifying Components The LCD Monitor — Front View The LCD Monitor — Rear View Adjusting the Viewing Angle Power Management System CHAPTER 2....................... 5 LCD Monitor Control Panel Adjusting the Monitor's Display OSD Main Menu Hot-Key Buttons for Quick Adjustment of Monitor Settings.

  • Page 5: Chapter 1

    HAPTER The LCD Monitor Unpacking After you unpack your LCD monitor, make sure the following items are included in the box and in good condition: STANDARD ITEM LCD monitor Monitor-to-PC analog signal cable (15-pin) Monitor-to-PC digital signal cable (24-pin) (optional) Power cord Quick Setup manual User’s manual...

  • Page 6: Identifying Components

    Identifying Components The LCD Monitor — Front View Figure 1-1: The LCD Monitor Front View Power-On Indicator This LED indicator stays lit when the power is on and blinks when the LCD monitor is in power saving mode 2. Monitor Stand 3.

  • Page 7: The Lcd Monitor - Rear View

    The LCD Monitor — Rear View Figure 1-2: LCD Monitor Rear View AC Power Inlet Upstream USB Port (optional) Downstream USB Ports (optional) Audio Line-in S-Video Connector AV Connector Digital VGA Cable Connector (optional) VGA Cable Connector Earphone Jack...

  • Page 8: Adjusting The Viewing Angle

    Adjusting the Viewing Angle Your LCD Monitor is designed to allow you to adjust it to a comfortable viewing angle and height (Optional). Please See Figure 1-3. Figure 1-3 A: Angle Settings Power Management System The LCD monitor complies with the VESA DPMS power management proposal. When the LCD monitor is in power saving mode or detects an incorrect timing, the monitor screen will be blank and the power LED indicator starts blinking.

  • Page 9: Chapter 2

    HAPTER The Display Controls LCD Monitor Control Panel Figure 2-1: The LCD Monitor Panel OSD Menu Button Press this button to pop up the OSD (On-Screen Display) menu. This button is also a Function Select button 2. Adjustment Control Buttons These two buttons allow you to adjust the selected control functions in the OSD.

  • Page 10: Adjusting The Monitor's Display

    Adjusting the Monitor's Display OSD Main Menu To access the OSD main menu, press the OSD Menu button. Use the Function Select buttons to scroll between the OSD main menu options. Pressing one of adjustment control buttons causes the following screen to appear: Figure 2-2: The OSD Main Menu ◆...
  • Page 11 H-POSITION: To move the LCD monitor's display left or right on a horizontal plane. V- POSITION: To move the LCD monitor's display up or down on a vertical plane. PHASE: To adjust the focus and clarity of the display. CLOCK: To adjust the display pixel alignment. GRAPHIC/TEXT: Press the adjustment control button to switch between text and graphic display modes.
  • Page 12 LANGUAGE: The supported languages include German, English, French, Spanish, Italian and Japanese. AUDIO VOLUME: To increase or decrease the volume of the LCD monitor’s sound system. INFORMATION: To indicate display mode timings and firmware version. EXIT: To exit the Misc-Control submenu. GRAPHIC-CONTROL: The Graphic-Control option lets you make adjustments that effect the contrast, brightness and color of the LCD monitor’s display.
  • Page 13 VIDEO-CONTROL: Press the Adjustment control button to display the submenu. DISPLAY-MODE: To select one of following modes for display: PC, Video PIP (Picture-In- Picture), PC PIP and Video modes. Press the Adjustment control button "-" to select mode and then press the Adjustment control button "+"...
  • Page 14 OSD-V-POSITION: To change the position of the OSD on a vertical plane. OSD-TIMER: The OSD menu display time can be set at 5, 10, 15, 20, 25 or 30 seconds. EXIT: To exit the OSD-Control submenu. MISC-CONTROL: The Misc-Control menu option lets you select the OSD display language, adjust the audio volume setting and view system information.
  • Page 15 VIDEO-CONTROL: Press the Adjustment control button to display the submenu. DISPLAY-MODE: To select one of following modes for display: PC, Video PIP (Picture-In- Picture), PC PIP and Video modes. Press the Adjustment control button "-" to select mode and then press the Adjustment control button "+"...
  • Page 16 SHARPNESS: Press the adjustment button to optimize the sharpness for your specific application. RESET: To reset all of the Video-Control submanu settings to the factory default. EXIT: To exit the Video-Control submenu. PIP-CONTROL: Press the Adjustment control button to display the submenu. PIP-SIZE: Adjust the PIP size.
  • Page 17 MISC-CONTROL: The Misc-Control menu option lets you select the OSD display language, adjust the audio volume setting and view system information. Press the Adjustment control button to display the submenu. LANGUAGE: The supported languages include German, English, French, Spanish, Italian and Japanese. AUDIO VOLUME: To increase or decrease the volume of the LCD monitor’s sound system.
  • Page 18 DISPLAY-MODE: To select one of following modes for display: PC, Video PIP (Picture-In- Picture), PC PIP and Video modes. Press the Adjustment control button "-" to select mode and then press the Adjustment control button "+" to enter your selection. VIDEO-SOURCE: To switch S-Video and Video display.
  • Page 19 PIP-V-POSITION: Adjust the PIP vertical position. EXIT: To exit the PIP-Control submenu. Note: No Video When the monitor is ON and there is no Video signal received, the following message will be displayed. Signal out of monitor’s supported timing range (Please refer to Addendum) When the frequency range is out of the monitor’s specifications, or the incoming resolution is higher than...

  • Page 20: Hot-Key Buttons For Quick Adjustment Of Monitor Settings

    Hot-Key Buttons for Quick Adjustment of Monitor Settings. (〝AUTO-ADJUST〞hot-key is effective only when analog input signal is selected for application) 1. "Auto-adjust" hot-key button: Press button 2 to apply the monitor setting automatically. A small “AUTO-ADJUST” OSD is also displayed. 2.

  • Page 21: Tft Lcd Monitor Specifications

    PPENDIX Technical Information TFT LCD Monitor Specifications LCD Panel 20.1” UXGA Control Software power switch with LED indicator Functions: Power On-Screen Mode Main Menu Sub Menu Display (OSD) PC MODE- AUTO ADJUST ANALOG MONITOR- H-POSITION, V- POSITION, SIGNAL INPUT CONTROL PHASE, CLOCK, GRAPHIC/TEXT, PORT- SELECT, RESET, EXIT...
  • Page 22 PC PIP MODE VIDEO-CONTROL DISPLAY-MODE, VIDEO- (OPTIONAL)- SOURCE, SATURATION, HUE, FOR PIP SHARPNESS, RESET, EXIT PIP-CONTROL PIP-SIZE, PIP-H-POSITION, PIP-V-POSITION, EXIT VIDEO MODE OSD-CONTROL OSD-H-POSITION, OSD-V- (OPTIONAL) POSITION, OSD-TIMER, EXIT MISC-CONTROL LANGUAGE, AUDIO VOLUME, INFORMATION, EXIT GRAPHIC- CONTRAST, BRIGHTNESS, CONTROL RESET, EXIT VIDEO-CONTROL DISPLAY-MODE, VIDEO- SOURCE, SATURATION, HUE,...
  • Page 23 Display Area (mm) 408.0 x 306.0 mm (20.1 inch diagonal) Display Colors 16.7M Video Input VGA, DVI (Optional), Earphone, S-Video / AV (Optional) Scanning Frequency 24-82kHz H/V, Hz 56-85 (Analog mode) Scanning Frequency 31-80kHz H/V, Hz 66-85 (Digital mode) Power Management Meets VESA DPMS Power Consumption 80W (max.)/5W (max.)
  • Page 24 PPENDIX Supported Timing Vertical Horizontal Sync Operating Item Standards Resolution Clock Scanning Scanning Polarity or Mode (MHz) Frequency Frequency composite (Hz) (kHz) sync (H/V) NEC PC98 640x400 25.20 70.15 31.50 NEC PC98 640x400 21.05 56.42 24.83 MAC 13” 640x480 30.24 66.67 35.00 mode...
  • Page 25 Vertical Horizontal Sync Item Standards Resolution Clock Scanning Scanning Polarity or Operating (MHz) Frequency Frequency composite Mode (Hz) (kHz) sync (H/V) VESA 1280x960 108.0 60.0 60.0 A/D/G 1280x102 VESA 108.0 60.02 63.98 A/D/G 1280x102 VESA 127.0 69.85 74.88 A/D/G 1280x102 VESA 135.0 75.03...

  • Page 26: Troubleshooting Procedures

    PPENDIX Troubleshooting Troubleshooting Procedures This LCD monitor comes pre-adjusted with standard VGA timing. Due to output timing differences among various VGA cards, you may initially experience an unstable or unclear display when a new display mode or new VGA card is selected. Before applying any of the following troubleshooting procedures, you should first apply the Auto Adjust option in the OSD menu.
  • Page 27 2. Turn off the LCD monitor and then turn it back on again. Press the OSD Menu button (refer to Chapter 2) once and then press either Adjustment Control button several times. If there is still no display, press the other Adjustment Control button several times.
