Optional Digital Video Out Connector (J2G2); Processor Fan Connector (J2K1); Chassis Fan Connector (J2G1) - Intel D810E2CA3 Specification

Intel Desktop Board D810E2CA3 Technical Product Specification
Table 31.

Optional Digital Video Out Connector (J2G2)

Pin Signal Name
1 LTVCLKIN
3 P_RST_SLOTS#
5 Ground
7 Ground
9 Ground
11 Ground
13 Ground
15 Ground
17 Ground
19 Ground
21 Ground
23 Ground
25 Ground
27 Ground
29 Ground
31 Ground
33 Ground
35 Ground
37 Ground
39 Ground
Table 32. Processor Fan Connector
(J2K1)
Pin Signal
1 Ground
2 +12 V
3 Ground
Table 33.

Chassis Fan Connector (J2G1)

Pin Signal
1 FAN_DRIVE
2 +12 V
3 Reserved
56
Pin Signal Name
2 +5 V
4 LTVCL_3V
6 LTVDA_3V
8 LTVVSYNC
10 LTVHSYNC
12 LTVDAT0
14 LTVDAT1
16 LTVDAT2
18 LTVDAT3
20 LTVDAT4
22 LTVDAT5
24 LTVDAT6
26 LTVDAT7
28 LTVDAT8
30 LTVDAT9
32 LTVDAT10
34 LTVDAT11
36 LTVCLKOUT0
38 LTVCLKOUT1
40 LTVBLNK#
