Page 2: Operation Instructions
Operation Instructions Thank you for purchasing this monitor,a high-resolution multi-scan color monitor. Please read this fuide thoroughly before installation. FCC Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This monitor has been tested and found to compliant with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 3: Table Of Contents
Contert Safety Precautions First Setup Quick Installation Front View of the Product Main Menu Adjusting the picture Supported Timing Modes Technical Specification Care and Maintenance Troubleshooting... -
Page 4: Safety Precautions
Safety Precautions This monitor is manufactured and tested on a ground principle that a user’s safety comes first.However,improper use or installation may result danger to the monitor as well as to the user.Carefully go over the following WARNINGS before installation and keep this guide handy. WARNINGS: This monitor should be operated only at the correct power sources indicated on the label on the rear end of the monitor.If you’re unsure of... -
Page 5: First Setup
First Setup Congratulation for purchasing this monitor of high performance! This monitor comes with the following accessories: LCD Monitor Owner's Manual Power Cord D-Sub Cable Audio Cable Quick Installation Install / Remove the base Place the display onto the base. Align the display with the swivel on the base and plug the display into the base. - Page 6 Windows users: Setting the Timing Mode(Resolution and Refresh Rate) Example: 1440 x 900 @ 60 Hz Resolution Right-click on the Windows desktop > Properties > Settings > “Desktop Area”. Set the resolution. Refresh Rate (vertical frequency) See your graphic card’s user guide for instructions.
-
Page 7: Front View Of The Product
Front View of the Product Figure 3 1. Auto Adjust Key/Exit 3. Increase>/Audio 5. LED Press the MENU button (④ in fig. 3) to display the OSD menu on the screen. 1. There are a total of 5 OSD submenus divided by categories. Select the desired submenu by pressing the OSD button <... -
Page 8: Main Menu
Main Menu Figure 4 The OSD Message Adjusting the picture The descriptions for function control LEDS Main Main Menu Sub Menu Menu Item Item Icon Brightness Brightness/ Contrast Contrast Auto Adjustment H-Position Controls the picture’s horizontal position. V-Position Controls the picture’s vertical position. Image Adjust Clock... - Page 9 Main Main Menu Sub Menu Menu Item Icon Color Custom H．OSD Position V.OSD CONTROL Position Timeout Language Input select Speaker Volume OTHERS Information Autoswitch RESET Item This menu lets you select a preset color 9300K temperature (9300K, 6500K or sRGB) by pressing the OSD buttons <...
-
Page 10: Supported Timing Modes
Supported Timing Modes 720 x 400 @ 70Hz 640 x 480 @ 60 Hz 640 x 480 @ 67 Hz VESA 640 x 480 @ 73 Hz VESA 640 x 480 @ 75 Hz VESA 800 x 600 @ 56 Hz VESA 800 x 600 @ 60 Hz VESA... -
Page 11: Technical Specification
Technical Specification Input signal Display Type Viewable Diagonal size Native Resolution Colors Pixel Pitch Synchronization Recommended Resolution Supported Resolutions Pow er consumption Dimensions Weight Environmental The above specification is subject to actual panel specification and is subject to change without prior notice. Analog Dsub Digital DVI-D with HDCP Audio... -
Page 12: Care And Maintenance
Care and Maintenance Care Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare. Put your monitor in a well ventilated area. Do not place any heavy things on top of your monitor. Make certain your monitor is installed in a clean and moisture-free area.
