Table of Contents
About This Guide..............................................................................................................................................1
National Conventions......................................................................................................................................1
FCC Notice .........................................................................................................................................................2
WEEE Declaration..............................................................................................................................................2
HG Declaration ..................................................................................................................................................3
Precautions ........................................................................................................................................................3
Setup stand and base......................................................................................................................................4
Adjusting Viewing Angle ................................................................................................................................4
Connecting Cables...........................................................................................................................................5
Wall Mounting....................................................................................................................................................6
Setting Optimal Resolution............................................................................................................................7
External Controls..............................................................................................................................................8
Menu Illustration...............................................................................................................................................9
Hotkey Illustration ............................................................................................................................................9
Menu Icon Definition......................................................................................................................................10
LED Indicators.................................................................................................................................................14
I-Menu software ..............................................................................................................................................14
Drives.................................................................................................................................................................15
Windows 2000 .................................................................................................................................................15
Windows ME ....................................................................................................................................................15
Windows XP.....................................................................................................................................................16
Windows Vista.................................................................................................................................................16
Technical Support ..........................................................................................................................................17
Frequently Asked Questions.......................................................................................................................17
Product Specifications..................................................................................................................................18
EPA ENERGY STAR ®...................................................................................................................................19
Preset Display Modes....................................................................................................................................19
Pin Assignments ............................................................................................................................................20
Plug and Play...................................................................................................................................................21
Advertisement
Table of Contents
Related Manuals for Envision G2461w
Summary of Contents for Envision G2461w
-
Page 1: Table Of Contents
Table of Contents About This Guide..............................1 National Conventions............................1 FCC Notice .................................2 WEEE Declaration..............................2 HG Declaration ..............................3 Precautions ................................3 Setup stand and base............................4 Adjusting Viewing Angle ..........................4 Connecting Cables............................5 Wall Mounting..............................6 Setting Optimal Resolution..........................7 External Controls..............................8 Menu Illustration...............................9 Hotkey Illustration ............................9 Menu Icon Definition............................10 LED Indicators..............................14 I-Menu software ..............................14... -
Page 2: About This Guide
About This Guide This guide describes the monitor's features, setup, and operation. information in this document is subject to change without notice. The sections are as follows: • Safety Instructions: lists safety information. • Setup: describes the initial setup process. •... -
Page 3: Fcc Notice
FCC Notice FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Hg Declaration
HG Declaration SAFETY: Lamp Disposal LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. FOR MORE INFORMATION, CONTACT THE ELECTRONIC INDUSTRIES ALLIANCE AT WWW.EIAE.ORG. Precautions WARNING: Use of controls, adjustments, or procedures other than those specified in this documentation may result in exposure to shock, electrical hazards, and/or mechanical hazards. -
Page 5: Setup Stand And Base
Setup stand and base Please setup or remove the base following below steps. Adjusting Viewing Angle • For optimal viewing it is recommended to look at the full face of the monitor, and then adjust the monitor's angle to your own preference. •... -
Page 6: Connecting Cables
Connecting Cables Cable Connections On Back of Monitor and Computer 1. Power 2. DVI 3. Analog Turn off your computer before performing the procedure below. Connect the power cable to the AC port on the back of the monitor. Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer's D-Sub port. -
Page 7: Wall Mounting
Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for instructions on attaching it to the wall. Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official department of ENVISION. -
Page 8: Setting Optimal Resolution
Setting Optimal Resolution The recommended resolution for this monitor is 1920 by 1080. To setup the monitor to this resolution, follow the steps below. Click START. Click SETTINGS. Click CONTROL PANEL. Double click DISPLAY. Click SETTINGS. Set the resolution SLIDE-BAR to 1920 by 1080. -
Page 9: External Controls
External Controls Press the power button to turn the monitor on or off. The other control knobs are located at front panel of the monitor (See Figure Below). By changing these settings, the picture quality can be adjusted to your personal preferences. -
Page 10: Menu Illustration
Menu Illustration • Press the MENU-button to activate the OSD window. • Press to navigate through the functions. Once the desired function is highlighted, press the ＞ ＜ MENU-button to activate it. If the function selected has a sub-menu, press again to navigate ＞... -
Page 11: Menu Icon Definition
Menu Icon Definition Luminance Adjust Range Description Brightness 0-100 Backlight Adjustment Contrast 0-100 Contrast from Digital-register. Standard Mode Standard Text Mode Text Internet Mode Internet Eco mode Game Mode Game Movie Mode Movie Sports Mode Sports Gamma1 Adjust to Gamma1 Gamma Gamma2 Adjust to Gamma 2... - Page 12 Image Setup Adjust picture Clock to reduce Clock 0-100 Vertical-Line noise. Adjust Picture Phase to reduce Phase 0-100 Horizontal-Line noise Adjust the horizontal position of H.Position 0-100 the picture. Adjust the vertical position of V.Position 0-100 the picture. Color Temp. Recall Warm Color Warm 6500K...
- Page 13 Picture Boost Frame Size 14-100 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness Contrast 0-100 Adjust Frame Contrast Adjust Frame horizontal H. position Position Position V.position Adjust Frame vertical Position Bright Frame on or off Disable or Enable Bright Frame OSD Setup Adjust the horizontal position of H.Position...
- Page 14 Select wide or 4:3 format for Image Ratio wide or 4:3 display DDC-CI yes or no Turn ON/OFF DDC-CI Support Select timing to turn off the 0~24hours Off Timer monitor. Show the information of the Information main image and sub-image source Reset Reset...
-
Page 15: Led Indicators
LED Indicators Status LED Color Full Power Mode White Active-off Mode Orange I-Menu software Welcome to use “i-Menu” software by ENVISION. i-Menu makes it easy to adjust your display settings by mouse. -
Page 16: Drives
Drives Windows 2000 1. Start Windows® 2000 2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. 3. Double click on the 'Display' Icon. 4. Select the 'Settings' tab then click on 'Advanced...’ 5. Select 'Monitor' - If the 'Properties' button is inactive, it means your monitor is properly configured. -
Page 17: Windows Xp
Windows XP 1. Start Windows® XP 2. Click on the 'Start' button and then click on 'Control Panel'. 3. Select and click on the category 'Printers and Other Hardware' 4. Click on the 'Display' Item. 5. Select the 'Settings' tab then click on the 'Advanced' button. 6. -
Page 18: Technical Support
Also check the monitor's video cable and make sure none of No Plug & Play the pins are bent. • Make sure the ENVISION Monitor Drivers are installed • Adjust the Contrast and Brightness Controls. • Make sure you are not using an extension cable or switch box. We Picture Is Fuzzy &... -
Page 19: Product Specifications
Product Information Specifications Model number G2460w Driving system TFT Color LCD Viewable Image Size 599.4 mm diagonal Pixel pitch 0.2715mm(H) x 0.2715mm(V) LCD Panel Video R, G, B Analog lnterface & Digital Interface Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 148.5 MHz Horizontal scan range... -
Page 20: Epa Energy Star
EPA ENERGY STAR ® ENERGY STAR® is a U.S. registered mark. As an ENERGY STAR® Partner, ENVISION International (Europe) GmbH has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. Preset Display Modes HORIZONTAL VERTICAL STAND RESOLUTION... -
Page 21: Pin Assignments
Pin Assignments Pin Number 15-Pin Side of the Signal Cable Video-Red Video-Green Video-Blue Ground Detect Cable GND-R GND-G GND-B Ground Ground DDC-Serial data H-sync V-sync DDC-Serial clock Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2- TMDS Data 1- TMDS Data 0- TMDS Data 2+... -
Page 22: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
