Summary of Contents for Envision G2016WA2
-
Page 2: Operation Instructions
Operation Instructions Thank you for purchasing this monitor,a high-resolution multi-scan color monitor. Please read this guide thoroughly before installation. FCC Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This monitor has been tested and found to compliant with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 3: Table Of Contents
Contert Safety Precautions First Setup Quick Installation Front View of the Product Main Menu Adjusting the picture Supported Timing Modes Technical Specification Care and Maintenance Troubleshooting... -
Page 4: Safety Precautions
Safety Precautions This monitor is manufactured and tested on a ground principle that a user’s safety comes first.However,improper use or installation may result danger to the monitor as well as to the user.Carefully go over the following WARNINGS before installation and keep this guide handy. WARNINGS: This monitor should be operated only at the correct power sources indicated on the label on the rear end of the monitor.If you’re unsure of... -
Page 5: First Setup
First Setup Congratulations for purchasing this monitor of high performance! This monitor comes with the following accessories: LCD Monitor Owner's Manual Power Cord D-Sub Cable Audio Cable Quick Installation Install / Remove the base Place the display onto the base. Align the display with the swivel on the base and plug the display into the base. - Page 6 Example: 1680X1050 @ 60 Hz Resolution Right-click on the Windows desktop > Properties > Settings > “Desktop Area”. Set the resolution. Refresh Rate (vertical frequency) See your graphic card’s user guide for instructions. Example: Figure 2 AC Power Cord DVI Cable （Optional） D-sub Cable Audio Cable Connecting Cables...
-
Page 7: Front View Of The Product
Front View of the Product Figure 3 1. Auto Adjust Key/Exit 3. Increase>/ Input select 5. LED Press the MENU button (④ in fig. 3) to display the OSD menu on the screen. 1. There are a total of 5 OSD submenus divided by categories. Select the desired submenu by pressing the OSD button <... -
Page 8: Main Menu
Main Menu Figure 4 The OSD Message Adjusting the picture The descriptions for function control LEDS Main Main Menu Sub Menu Menu Item Item Icon Brightness Brightness/ Contrast Contrast Black level Auto level H-Position Controls the picture’s horizontal position. V-Position Controls the picture’s vertical position. Image Clock Adjust... - Page 9 Custom Language H-Position OSD Setup V-Position Timeout Input select Resolution Advanced Factory G2016wa2 Information Analogue Item 6500K Regulates the color temperature settings. Activate the OSD window using the 9300K SEL/MENU button. Go to the Colour option Native by pressing the < or > buttons. Press the SEL/MENU button and <...
-
Page 10: Supported Timing Modes
Supported Timing Modes VESA MODES 640 x 480@ 60Hz 640 x 480 @ 72 Hz 640 x 480 @ 75 Hz SVGA 800 x 600@ 56 Hz SVGA 800 x 600 @ 60 Hz SVGA 800 x 600 @ 72 Hz SVGA 800 x 600 @ 75 Hz 1024 x 768 @ 60 Hz... -
Page 11: Technical Specification
Technical Specification Input signal Display Type Viewable Diagonal size Native Resolution Colors Pixel Pitch Synchronization Recommended Resolution Supported Resolutions Pow er consumption Dimensions Weight Environmental The above specification is subject to actual panel specification and is subject to change without prior notice. Analog Dsub Digital DVI-D with HDCP Audio... -
Page 12: Care And Maintenance
Care and Maintenance Care Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare. Put your monitor in a well ventilated area. Do not place any heavy things on top of your monitor. Make certain your monitor is installed in a clean and moisture-free area.
