Intel Desktop Board D945PWM Specification Update
Summary Table of Changes
The following table indicates the Specification Changes, Errata, Specification Clarifications, or
Documentation Changes that apply to the Intel
some of the errata in a future revision of the desktop board, and to account for the other
outstanding issues through documentation or specification changes as noted. This table uses
the following notations:
CODES USED IN SUMMARY TABLE
Doc: Document change or update that will be implemented.
PlanFix: This erratum may be fixed in a future revision of the desktop board,
driver, or BIOS.
Fixed: This erratum has been previously fixed.
NoFix: There are no plans to fix this erratum.
Shaded: This erratum is either new or modified from the previous version of the
document.
NO. PLANS
1 Doc Change to Section 2.8.2.3, Add-in Card Connectors
2 Doc
Changes to Section 1.9.2 Audio Connectors
NO. PLANS
1 Plan Fix The placement of capacitors behind PCI Express* x1 connector slot 1 may
prohibit some PCI Express x1 add-in cards from properly connecting to the
motherboard
2 Fixed Design for the rear-panel MIC bias circuitry will not correctly amplify rear-
panel microphone recording.
4
®
Desktop Board D945PWM. Intel intends to fix
SPECIFICATION CHANGES
ERRATA
