Page 1: Digital Camera
PREPARATIONS BASIC FUNCTIONS MOVIE FUNCTIONS INSTRUCTIONS PRINTING PICTURES USING A PERSONAL COMPUTER CAMERA SETTINGS MISCELLANEOUS DIGITAL CAMERA C-2020ZOOM Before using your camera, read this manual carefully to ensure correct use. We recommend that you take test shots to get accustomed to your camera before taking important photographs.
Page 2: Important Safety Instructlons
IMPORTANT SAFETY INSTRUCTlONS Thank you for purchasing the Olympus digital camera. Before you start to use your new camera, please read these instructions carefully to obtain optimum performance and a longer service life from the unit. Be sure to retain this manual for future reference.
Page 3 7. Water and Moisture — Do not use this product near water — for example, near a bath tub, kitchen sink, or laundry tub, in a wet basement, near a swimming pool or rain. 8. Accessories — Do not place this product on an unstable stand, tripod, bracket, table, or cart.
Page 4: Radio And Television Interference
16. Damage Requiring Service — If using the optional AC adapter, unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) If liquid has been spilled, or objects have fallen into the product. b) If the product has been exposed to rain or water.
Page 5 Declaration of Conformity Model Number: C-2020ZOOM Trade Name: OLYMPUS Responsible party: Olympus America Inc. Address: 2 Corporate Center Drive, Melville, New York 11747-3157 U.S.A. Telephone number: 516-844-5000 This device complies with Part 15 of the FCC rules. Operation is subject to...
Page 6: For Safe Use
• No part of this publication may be reproduced or reprinted except for personal use without the prior permission of Olympus. • Olympus makes no representations or warranties regarding any damages, or benefit expected by using this unit lawfully, or any request from a third person, which are caused by the inappropriate use of this unit.
Page 7 CONTINUOUSLY. YOU MAY GET BURNED. 8. IF YOU DROP THE CAMERA IN WATER OR GET WATER INSIDE IT, UNLOAD THE BATTERIES IMMEDIATELY AND CONTACT YOUR NEAREST OLYMPUS SERVICE CENTER. LEAVING BATTERIES IN A WET CAMERA MAY CAUSE FIRE OR ELECTRIC SHOCK.
Page 8: Care And Storage
CAUTION 1. IF YOU NOTICE AN UNUSUAL SMELL, NOISE, OR SMOKE EMITTING FROM THIS CAMERA, UNLOAD THE BATTERIES CAREFULLY TO AVOID BEING BURNED. CONTACT YOUR NEAREST OLYMPUS SERVICE CENTER IMMEDIATELY. 2. NEVER ATTEMPT TO DISASSEMBLE THIS CAMERA. IT CONTAINS HIGH-VOLTAGE CIRCUITRY THAT MAY CAUSE ELECTRIC SHOCK AND INJURY.
Page 9: Battery Handling
Do not turn the camera when it is mounted on a tripod. Turn the tripod head instead. Do not touch any of the camera’s internal parts. Do not use the flash for extended periods as this can cause the flash to become excessively hot.
Page 10: Table Of Contents
CONTENTS Important safety instructlons............2 For safe use................6 Care and storage ..............8 Battery handling..............9 Main features................15 PREPARATION............17 Checking the contents ..............18 Names of parts .................20 Attaching the strap..............23 Loading the batteries ..............24 Using the AC adapter (optional) ..........26 Inserting SmartMedia ...............28 Adjusting the date and time ............30 Learning the basics ..............32 Holding the camera...............32...
Page 11 Shutter priority mode ..............52 Manual mode................54 Zoom ..................55 Exposure compensation ............56 Using the flash................57 Spot metering mode ..............61 Macro mode................62 Macro + Spot metering mode ...........63 Manual focus ................64 Still picture record menu............66 Sequence mode ...............67 Selftimer/Remote control ............69 Auto bracket ................73 Extension flash .................75 Slow shutter synchronization flash mode .........77 Digital tele mode...............79...
Page 12 MOVIE FUNCTIONS..........105 [Record Mode] Recording movies..............106 Recording movies using the optical viewfinder....106 Recording movies using the LCD monitor ......108 Quick view................110 Focus lock................111 Working range ................112 Zoom..................113 Exposure compensation ............114 Manual focus ................115 Movie picture record menu .............117 Selftimer/Remote control ............118 White balance.................122 ISO ..................124 Picture effects.................126...
Page 13 PRINTING PICTURES.........139 Printing pictures..............140 Card print................141 Print-reserve (card).............141 Still picture display menu (card-print) .........142 Print-all (card) ..............143 Date-print (card)..............144 Index-print (card) ..............145 Direct-print ................146 Printing with the P-300 ............146 Index print (P-300) ..............148 Close-up print (P-300) ............149 Random print (P-300) ............150 Direct print menu ..............152 All print (P-300)..............153 Cut print (P-300) ..............154...
Page 14 CAMERA SETTINGS...........171 All reset...................172 Sharpness ................174 SHQ setup ................175 SQ setup.................176 Beep sound ................177 Rec view .................178 File number................180 LCD brightness...............183 Meters/Feet selection .............185 Index-display adjustment............186 MISCELLANEOUS ..........187 Questions and answers ............188 Troubleshooting..............190 System chart................194 Error codes ................195 Optional items.................196 Notes on display and backlight..........196 Compatibility of the picture data ..........197 Specifications .................198...
Page 15: Main Features
Various exposure modes make advanced shooting possible. The Olympus high-resolution 3X optical zoom lens plus the Digital tele mode make possible photographs equivalent to 7.5X zoom. Movie function incorporated that lets you record up to approx.
Page 17: Preparation
PREPARATION...
Page 18: Checking The Contents
CHECKING THE CONTENTS Camera Strap Lens cap Video cable RS-232C PC serial Conversion connector cable for Macintosh Remote control Software CD’s Warranty card/ Instructions/Remote Registration card control instructions...
Page 19 Battery charger AA NiMH batteries (4 pieces) Power plug Instructions SmartMedia Static-free case (SSFDC-8MB) Index labels (2 pieces) Write-protect adhesive seals (4 pieces) Instructions...
Page 20: Names Of Parts
NAMES OF PARTS CAMERA Selftimer/Remote control Control panel (P. 22) signal (P. 69/118) Remote control window (P. 72/121) Zoom lever (P. 55/113) Diopter Strap hole adjustment (P. 23) dial (P. 33) Flash (P. 57) Connector cover Lens Flash synchronization socket (P. 75) AC adapter connector (P.
Page 21: Viewfinder Display
Flash button (P. 57) / Jog dial (P. 39) Erase button (P. 98) Mode dial (P. 35) Spot/Macro button Shutter release button (P. 61) / (P. 33) Info button (P. 94) Zoom lever Viewfinder (P. 55/113) (P. 21) OK button (P.
Page 22: Control Panel
CONTROL PANEL Flash mode Manual white balance Macro mode Slow shutter synchroniza- Extension flash tion flash Writing SLOW Manual focus Exposure Sequential compensation shooting Auto bracket Card error Number of Recording storable pictures Selftimer/Remote mode control Spot metering mode Battery check LCD MONITOR (Record mode) (Display mode)
Page 23: Attaching The Strap
Attach the strap to the strap hole on the camera. Caution: • Attach the strap correctly as shown so that the camera does not fall off. If the strap is attached incorrectly and the camera comes loose and falls off, Olympus is not responsible for any damage.
Page 24: Loading The Batteries
LOADING THE BATTERIES This camera uses four AA nickel metal–hydride batteries, AA alkaline batteries, AA lithium batteries or AA NiCd batteries. Performance will be limited with alkaline batteries, especially in low temperatures. NiMH batteries are recommended. Do not use manganese batteries; they may overheat and destroy the camera.
Page 25 Note: • Make sure that the power is off before loading the batteries. • Do not touch the inside of the battery compartment. • If the camera is left without batteries for approx. one hour, all the settings will reset to the default. •...
Page 26: Using The Ac Adapter (Optional)
USING THE AC ADAPTER (Optional) An optional Olympus AC adapter allows you to power your digital camera from a common AC wall outlet Make sure that the camera power is off. Plug the AC adapter into a AC wall outlet power outlet.
Page 27 Warning: Incorrect use may cause a fire or electric shock. • Be sure to use an Olympus AC adapter. Olympus is not responsible for any damage caused by the use of other kinds of AC adapters. • Use an AC120V power source.
Page 28: Inserting Smartmedia
INSERTING SmartMedia Insert the SmartMedia card in the direction shown. Make sure that the camera power is off. Open the Card compartment cover. Insert SmartMedia. Insert the SmartMedia card correctly as shown. Close the cover tightly. To eject the card, turn off the power, open Card...
Page 29 Note: • Use 3V (3.3V) cards only. 5V cards cannot be used. • Olympus brand cards are recommended (already formatted). Non- Olympus brand cards must be formatted by the camera. • When using a special function SmartMedia card (optional), insert it in the same way.
Page 30: Adjusting The Date And Time
ADJUSTING THE DATE AND TIME You can adjust the date and time. Set the Mode dial to P, A/S/M, • Set it to other than when no images are stored in the card. Press the Menu button to display the Menu. •...
Page 31 Press the top/bottom arrows on the Jog dial to adjust the first setting, then press the right arrow on the Jog dial to adjust the second setting. Repeat until the minute is adjusted. Press button. • For accurate setting, press the OK button when the clock hits 00 seconds.
Page 32: Learning The Basics
LEARNING THE BASICS HOLDING THE CAMERA Hold the camera firmly with both hands while keeping your elbows at your sides to prevent the camera from moving. Proper Proper Improper Note: • Do not subject the lens to physical shocks. • Keep your fingers and the strap away from the lens and flash.
Page 33: Adjusting The Diopter
ADJUSTING THE DIOPTER Diopter adjustment dial • Turn the Diopter adjustment dial to see the Autofocus mark Viewfinder clearly. Autofocus mark PROPER SHUTTER RELESE Press the Shutter release button halfway to lock the focus and exposure. • The Green lamp next to the viewfinder lights.
Page 34: Basic Operating Procedure
BASIC OPERATING PROCEDURE Remove the lens cap. Set the Mode dial to P, A/S/M, to turn on the power. • A/S/M, P and set the camera to the Record mode. The lens will come out and the remaining battery power as well as the number of storable pictures will be displayed on the control panel.
Page 35: How To Use The Mode Dial
HOW TO USE THE MODE DIAL You can easily turn the camera on or off or change the mode using the Mode dial. Aperture priority Movie picture recording Shutter priority Manual Program Power off Display P or A/S/M (Still picture recording) (p. 42 ~ 91) With P, the camera selects the optimal aperture and the shutter speed automatically.
Page 36: Checking The Card
CHECKING THE CARD When the power is turned on in the Record mode, the camera checks the SmartMedia card. Control Card error SLOW SLOW When there is no SmartMedia card panel in the camera / the card is protected: The Card error indicator on the Viewfinder Green control panel and the Green lamp...
Page 37: Checking The Batteries
CHECKING THE BATTERIES When the power is turned on in the Record mode, the remaining battery power will be displayed on the control panel. lights and turns off automatically. Batteries are OK. You can shoot. blinks and other indicators on the control panel are displayed normally.
Page 38: Checking The Number Of Storable Pictures
CHECKING THE NUMBER OF STORABLE PICTURES When the power is turned on in the Still Picture Record mode, the number of storable pictures will appear on the control panel. (For movie pictures, the seconds remaining will appear.) Number or storable pictures •...
Page 39: How To Use The Menu
HOW TO USE THE MENU Set the Mode dial. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select the item to adjust. Press the right arrow on the Jog dial to display further selections.
Page 40 Press the top/bottom arrows to adjust the item. When finished, press the left arrow on the Jog dial to confirm the adjustment. Press the OK button to save the adjustment and cancel the Menu. Scroll LCD monitor F2.0 1/800 + 2.0 DRIVE SLOW DIGITAL...
Page 41: Basic Functions
BASIC FUNCTIONS...
Page 42: [Record Mode] Taking Pictures
TAKING PICTURES TAKING PICTURES USING THE OPTICAL VIEWFINDER Set the Mode dial to P or A/S/M. Compose the picture by placing the subject within the autofocus marks viewfinder or using the focus lock. (p. 47) • Turn the Diopter adjustment dial to see the Autofocus mark clearly.
Page 43 When the Green lamp stops blinking (after about 2 ~ 43 seconds), the camera is ready to take the next picture. • The Shutter will not release while the Green lamp is blinking. Caution: • NEVER open the card cover, eject the card, remove the batteries, or pull the plug while the Card access lamp is blinking.
Page 44: Taking Pictures Using The Lcd Monitor
TAKING PICTURES USING THE LCD MONITOR Set the Mode dial to P or A/S/M. With P, press the LCD monitor ON/OFF button to turn on the LCD monitor. • With A/S/M, the LCD monitor will turn on automatically. Compose the picture using the LCD monitor.
Page 45 F2.0 1/800 + 2.0 When the recorded image is no longer displayed, the camera is ready to take the next picture. • The recorded image will not be displayed if the Rec view is off. (p. 178) • To turn off the LCD monitor, press monitor ON/OFF button again.
Page 46: Quick View
QUICK VIEW You can immediately shift from the Record mode to the Display mode, and check the picture you have just taken. When the Mode dial is set to P or A/S/M, quickly press the LCD monitor ON/OFF button twice. •...
Page 47: Focus Lock
FOCUS LOCK If your main subject is not within the autofocus marks, follow the procedure below to obtain focus. This is called focus lock. Position your subject within Viewfinder the autofocus marks, and press the Shutter release button halfway. • The Green lamp next to the viewfinder lights.
Page 48: Autofocus
AUTOFOCUS There are certain conditions where the autofocus may not work properly even when the Green lamp lights when the Shutter release button is pressed halfway. When this happens, try the procedure below or use Manual focus. (p. 64) 1 Subjects with low contrast Lock the focus on an object that is at the same distance from the camera as the subject, then aim at the subject to take the picture.
Page 49 3 Subjects in excessively bright light Lock the focus on an object that is at the same distance from the camera as the subject, then aim at the subject to take the picture. (p. 47) 4 Subjects at different distances Lock the focus on an object that is at the same distance from the camera as the subject, then aim at the subject to take the picture.
Page 50: Working Range
WORKING RANGE The viewfinder’s picture frame shows the area that can be shot for subjects at !. However, the picture area will move lower in the viewfinder as you get closer to the subject, especially with Telephoto shooting. Viewfinder Picture frame Image area of picture at close distance Take pictures at a distance between 8"...
Page 51: Aperture Priority Mode
APERTURE PRIORITY MODE You can set the aperture manually for the Aperture priority mode. It is especially useful for taking portrait pictures with blurred backgrounds. Set the Mode dial to A/S/M. • The LCD monitor turns on A/S/M automatically, and the aperture setting will be displayed.
Page 52: Shutter Priority Mode
SHUTTER PRIORITY MODE You can set the shutter speed manually for the Shutter priority mode. Set it to a fast speed to capture a moving object. Set it to a slow speed to express motion. Set the Mode dial to A/S/M. A/S/M •...
Page 53 Available Shutter Speed Settings AUTO 1 ~ 1/800 4 ~ 1/800 2 ~ 1/800 1 ~ 1/800 (unit: seconds) Note: • When the right exposure cannot be attained, the shutter speed display will blink and (overexposure) or (underexposure) will appear on the LCD monitor.
Page 54: Manual Mode
MANUAL MODE You can set the aperture and shutter speed manually in the Manual mode. It is especially useful for taking portrait pictures with blurred backgrounds or expressing motion. Set the Mode dial to A/S/M. A/S/M • The LCD monitor turns on automatically, and the aperture and shutter speed settings are displayed.
Page 55: Zoom
ZOOM You can select Telephoto or Wide-angle with the 3X zoom lever. Press the lever to T to choose Telephoto shooting. Press the lever to W to choose wide-angle shooting. Note: • When used with the Digital tele mode, you can take an approx. 7.5X zoom photograph.
Page 56: Exposure Compensation
EXPOSURE COMPENSATION In addition to automatic exposure, you can also adjust it manually by +/– 2 (approx. 1/3 steps). Adjust + when the subject is mostly bright. Adjust – when the subject is mostly dark. Set the Mode dial to P or A/S/M. •...
Page 57: Using The Flash
USING THE FLASH Select the flash mode according to the shooting conditions. You can select the following flash modes with each press of the Flash mode button. Flash mode Auto-Flash (p. 58) Automatically fires in low-light and backlight conditions. Red-Eye Reducing Flash (p. 58) Significantly reduces the phenomenon of “red-eye”...
Page 58 AUTO-FLASH In the Auto-Flash mode, the flash will fire automatically in low-light and backlight conditions. Viewfinder Backlighting correction mark When you take a picture that is backlit, position the subject within the backlighting correction marks to fire the flash. RED-EYE REDUCING FLASH This mode significantly reduces the phenomenon of “red-eye”.
Page 59 FILL-IN FLASH (FORCED ACTIVATION) In the Fill-In Flash mode, the flash fires regardless of available light. For example, this mode can be used to brighten up the subject’s shaded face. Another use of this mode is to correct the color shift produced by artificial lights (eg.
Page 60: Selecting The Flash Mode
SELECTING THE FLASH MODE Set the Mode dial to P or A/S/M. With each press of the Flash mode button, the flash mode will switch from Auto-Flash to (Red-Eye Reducing Flash, p, 58), (Fill-In Flash, p. 59) (Flash Off, p. 59). •...
Page 61: Spot Metering Mode
SPOT METERING MODE The Spot metering mode is used to obtain the right exposure regardless of the backlight. Place the subject in the center of the autofocus marks. You can select the following modes with each press of the Spot/Macro button. "...
Page 62: Macro Mode
MACRO MODE You can get as close as 8" to your subject. An approx. 2.4" x 3" subject can be photographed fully within the frame. Set the Mode dial to P or A/S/M. Press the Spot/Macro button several times until appears on the control panel.
Page 63: Macro + Spot Metering Mode
MACRO + SPOT METERING MODE Use this mode when you want to use the Spot metering mode and your subject is closer than 31". Set the Mode dial to P or A/S/M. Press the Spot/Macro button several times until appear on the control panel. •...
Page 64: Manual Focus
MANUAL FOCUS With Manual focus, you can select a pre-adjusted focal length. It is especially useful when quick shooting is required. Set the Mode dial to P or A/S/M. Press the OK button to turn on the LCD monitor. Press the right arrow on the Jog dial to select the Manual focus mode.
Page 65 F2.0 1/800 + 2.0 When the cursor is moved below 2.6ft, shorter distances 31inch will appear on the LCD monitor. 24inch 16inch Press the OK button to save 8inch AF MF 2.5x the setting. Note: • When Manual focus is selected from the Macro mode, the distances on page 65 will be displayed on the LCD monitor.
Page 66: Still Picture Record Menu
STILL PICTURE RECORD MENU * When the Mode dial is set to A/S/M or P. (p. 39) Monitor display For using the Sequence mode (p. 67), " DRIVE Selftimer/Remote control (p. 69) or Auto bracket (p. 73). For using an extension flash. (p. 75) SLOW For taking photographs of night views.
Page 67: Sequence Mode
SEQUENCE MODE In the Sequence mode, the camera takes pictures sequentially while the Shutter release button is pressed. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select DRIVE.
Page 68 Press the left arrow on the Jog dial to confirm the setting. If you take a picture without pressing the OK button, the setting will be valid until the Menu is canceled. • Press the OK button to save the setting and cancel the Menu.
Page 69: Selftimer/Remote Control
SELFTIMER/REMOTE CONTROL Use a tripod to hold the camera securely. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select DRIVE. Press the right arrow on the Jog dial, then press the F2.0 1/800 + 2.0 top/bottom arrows to select...
Page 70 Press the left arrow on the Jog dial to confirm the setting. Press the OK button to save the setting and cancel the Menu. • You can take pictures without pressing the OK button. Note: • Unless OFF is selected in All Reset, the setting will be canceled when the power is turned off.
Page 71 TAKING A PICTURE USING THE SELFTIMER When the shutter is released, the Selftimer/Remote control signal Selftimer/Remote control signal Shutter release lights for approx. 10 seconds then button blinks for approx. 2 seconds before the picture is taken. To stop the activated selftimer, press the Menu button.
Page 72 TAKING A PICTURE USING THE REMOTE CONTROL Compose the picture, aim the remote control at the Remote control window camera, then press 15° 15° Shutter release button on the remote control to take a picture. • The Selftimer/Remote control signal blinks for approx. 3 seconds before the picture is taken.
Page 73: Auto Bracket
AUTO BRACKET Images will be recorded sequentially with different exposures. You can select frames to store by erasing unwanted frames. Set the Mode dial to P or A/S/M . • For A/S/M, the Shutter priority mode or Aperture priority mode must be selected. (p. Press the Menu button to display the Menu.
Page 74 Press the right arrow on the Jog dial, then press the top/bottom arrows to select the number of pictures. Press the left arrow on the Jog dial to confirm the setting. If you take a picture without pressing the OK button, the setting will be valid until the F2.0 1/800 + 2.0 Menu is canceled.
Page 75: Extension Flash
EXTENSION FLASH When an extension flash is used along with the main flash, shadows can be reduced by bouncing the extension flash light off of the ceilings or walls. Place the flash on the mount, then plug the cord into the camera’s Flash synchronization socket.
Page 76 Control panel Press the left arrow on the Jog dial to confirm the setting. Set the extension flash to the calibration mode. If you take a picture without pressing the OK button, the setting will be valid until the Menu is canceled. •...
Page 77: Slow Shutter Synchronization Flash Mode
SLOW SHUTTER SYNCHRONIZATION FLASH MODE You can set the flash to fire during the first or second half of a slow shutter speed’s release duration. It is especially great for taking photographs of night views. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu.
Page 78 Press the left arrow on the Jog dial to confirm the setting. If you take a picture without pressing the OK button, the setting will be valid until the Menu is canceled. • Press the OK button to save the setting and cancel the Menu.
Page 79: Digital Tele Mode
DIGITAL TELE MODE When used with the 3X optical zoom, you can take an approx. 7.5X zoom photograph. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select DIGITAL TELE.
Page 80: White Balance
WHITE BALANCE You can select the white balance according to the light source. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select WB. Press the right arrow on the Jog dial, then press the top/bottom arrows to select AUTO,...
Page 81 Press the left arrow on the Jog dial to confirm the setting. If you take a picture without pressing the OK button, the setting will be valid until the Menu is canceled. • Press the OK button to save the setting and cancel the Menu.
Page 82: Iso
You can select the sensitivity from auto, as well as approx. 100, 200 and 400. Set the Mode dial to P. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select ISO. Press the right arrow on the Jog dial, then press the top/bottom arrows to select...
Page 83 Press the left arrow on the Jog dial to confirm the setting. If you take a picture without pressing the OK button, the setting will be valid until the Menu is canceled. • Press the OK button to save the setting and cancel the Menu.
Page 84: Picture Effects
PICTURE EFFECTS You can select from four picture effects. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select FUNCTION. Press the right arrow on the Jog dial, then press the top/bottom arrows to select the desired picture effect.
Page 85: Panorama Mode
PANORAMA MODE You can make panorama pictures. Set the Mode dial to P, and turn on the LCD monitor. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select Press the right arrow on the Jog dial to select PLAY.
Page 86 Panorama mode and Menu. Note: • The Panorama mode is available only when an Olympus brand Standard memory card is used. • Turn on the LCD monitor before pressing the Menu button in order to select the Panorama mode.
Page 87: Card Setup (Card Format)
CARD SETUP (CARD FORMAT) You can format the card. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select CARD SETUP. Press the right arrow on the Jog dial to select F2.0 1/800 + 2.0 FUNCTION...
Page 88 • Formatting will not be engaged when the write-protect adhesive seal is placed on the card. • Non-Olympus brand cards or cards formatted from or used in a computer must be formatted by the camera. These cards may take longer to record than recommended Olympus brand cards.
Page 89: Selecting The Recording Mode
SELECTING THE RECORDING MODE You can select the Standard Quality mode SQ or the High Quality modes HQ/SHQ. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select Press the right arrow on the Jog dial, then press the top/bottom arrows to select the recording...
Page 90 If you take a picture without pressing the OK button, the setting will be valid until the Menu is canceled. • Press the OK button to save the setting and cancel the Menu. Mode Resolution Compression 640 x 480 (VGA) Standard 1024 x 768 (XGA) 1600 x 1200...
Page 91: A/S/M Mode
A/S/M MODE You can select Aperture priority mode, Shutter priority mode or Manual mode for A/S/M on the Mode dial. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select A/S/M MODE.
Page 92: Displaying Recorded Pictures
DISPLAYING RECORDED PICTURES You can display the pictures you have taken on the LCD monitor. Set the Mode dial to • The LCD monitor turns on automatically. The camera will check the card. • If there is a problem, blinks on the control panel.
Page 93 With each press of the right arrow on the Jog dial, you can view the succeeding picture. With each press of the left arrow, you can view the preceding picture. [10-frame jump using the Jog dial] • With each press of the bottom arrow, you can view the picture 10 frames ahead.
Page 94: Picture Data
PICTURE DATA You can display picture information (settings, date, file number, etc.) on the LCD monitor. Set the Mode dial to • The last picture taken, Frame number, Recording mode and Battery check indicator will appear on the LCD monitor for five seconds.
Page 95: Index-Display Mode
INDEX-DISPLAY MODE Multiple pictures can be displayed on the LCD monitor Set the Mode dial to Press the Zoom lever toward W to display several pictures on the monitor. • It may take a few seconds before the picture is displayed. Press the right arrow on the Jog dial to select succeeding pictures.
Page 96: Close-Up Display Mode (3X Inspection)
CLOSE-UP DISPLAY MODE (3X INSPECTION) Enlarged pictures can be displayed on the LCD monitor. Set the Mode dial to , and display the picture you want to enlarge. With each press of the Zoom lever toward T, the picture is enlarged 1.5X, 2X, 2.5X, and •...
Page 97: Protection
PROTECTION You can prevent accidental erasure of pictures you want to keep. Set the Mode dial to , and display the picture you want to protect. Press the OK button. • appears on the LCD monitor. • To cancel protection, press the OK button again while the picture is displayed.
Page 98: One-Frame Erase
ONE-FRAME ERASE You can delete pictures you do not need. Set the Mode dial to , and display the picture you want to erase. Press the Erase button to display Press the OK button with YES selected to erase the picture. •...
Page 99: Still Picture Display Menu
LCD monitor. (p. 39) Monitor display For a slide-show display. (p. 100) FUNCTION For using with optional Olympus special function SmartMedia cards. CARD For performing All-Frame erase or Card format. SETUP (p.101/102) MODE For making adjustments.
Page 100: Slide-Show Mode
SLIDE-SHOW MODE You can run through all the stored pictures automatically. Set the Mode dial to , and display a still picture. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select •...
Page 101: Card Setup
CARD SETUP ALL-FRAME ERASE Set the Mode dial to , and display a still picture. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select CARD SETUP. Press the right arrow on the Jog dial, then press the top/bottom arrows to select Press the OK button to display...
Page 102: Card Format
CARD FORMAT You can format the card. Set the Mode dial to , and display a still picture. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select CARD SETUP. Press the right arrow on the Jog dial, then press the top/bottom arrows to select FUNCTION...
Page 103 • Formatting will not be engaged when the write-protect adhesive seal is placed on the card. • Non-Olympus brand cards or cards formatted from or used in a computer must be formatted by the camera. These cards may take longer to record than recommended Olympus brand cards.
Page 104: Connecting To A Television
CONNECTING TO A TELEVISION Recorded images can be viewed on a TV (NTSC only). Make sure that the power of the TV and the camera are off before connecting. Connect the cable by inserting it into the video output connector of the camera and Video cable the input connector of the TV.
Page 105: Movie Functions
MOVIE FUNCTIONS You can record movies for up to approx. 60 seconds in the SQ mode and approx. 15 seconds in the HQ mode. The recorded movie images will be stored as a Motion JPEG file. You can observe the images in the Display mode.
Page 106: [Record Mode] Recording Movies
RECORDING MOVIES RECORDING MOVIES USING THE OPTICAL VIEWFINDER Set the Mode dial to Compose the picture by placing the subject within the autofocus marks viewfinder or using the focus lock. (p. 111) • Turn the Diopter adjustment dial to see the Autofocus mark clearly.
Page 107 Press the Shutter release button fully again to stop recording. When the Green lamp stops blinking, the camera is ready to record the next movie. • The Shutter will not release while the Green lamp is blinking. Caution: • NEVER open the card cover, eject the card, remove the batteries, or pull the plug while the Card access lamp is blinking.
Page 108: Recording Movies Using The Lcd Monitor
RECORDING MOVIES USING THE LCD MONITOR Set the Mode dial to Compose the picture using the LCD monitor. Record the movie in the same way as you would when using the optical viewfinder. (p. 106) • The seconds remaining appear on the LCD monitor.
Page 109 F2.0 1/800 + 2.0 When the buffer memory is full, the upper block will light and no other operation can be performed until the Card access lamp stops blinking. Note: • Some noise may appear compared to a still picture. •...
Page 110: Quick View
QUICK VIEW You can immediately shift from the Record mode to the Display mode, and check the movie you have just recorded. When the Mode dial is set to , quickly press the LCD monitor ON/OFF button twice. • The LCD monitor will display the last movie recorded.
Page 111: Focus Lock
FOCUS LOCK If your main subject is not within the autofocus marks, follow the procedure below to obtain focus. This is called focus lock. Viewfinder Position your subject within the autofocus marks, and press the Shutter release button halfway. • The Green lamp next to the viewfinder lights.
Page 112: Working Range
WORKING RANGE The viewfinder’s picture frame shows the area that can be shot for subjects at !. However, the picture area will move lower in the viewfinder as you get closer to the subject, especially with Telephoto shooting. Viewfinder Picture frame Image area of picture at close distance Record movies at a distance between 8"...
Page 113: Zoom
ZOOM You can select Telephoto or Wide-angle with the 3X zoom lever. Press the lever to T to choose Telephoto shooting. Press the lever to W to choose wide-angle shooting. Note: • Unless OFF is selected in All Reset, the setting will be canceled when the power is turned off.
Page 114: Exposure Compensation
EXPOSURE COMPENSATION In addition to automatic exposure, you can also adjust it manually by +/– 2 (approx. 1/3 steps). Adjust + when the subject is mostly bright. Adjust – when the subject is mostly dark. Set the Mode dial to •...
Page 115: Manual Focus
MANUAL FOCUS With Manual focus, you can select a pre-adjusted focal length. Set the Mode dial to Press the OK button to turn on the LCD monitor. Press the right arrow on the Jog dial to select the Manual focus mode. •...
Page 116 F2.0 1/800 + 2.0 When the cursor is moved below 2.6ft, shorter distances 31inch will appear on the LCD monitor. 24inch 16inch Press the OK button to save 8inch AF MF 2.5x the setting. Note: • When Manual focus is selected from the Macro mode, the distances on page 116 will be displayed on the LCD monitor.
Page 117: Movie Picture Record Menu
MOVIE PICTURE RECORD MENU * When the Mode dial is set to . (p. 39) Monitor Display For using the Selftimer/remote control. (p. 118) For selecting the white balance. (p. 122) For selecting the ISO sensitivity. (p. 124) FUNCTION For using picture effects. (p. 126) CARD For formatting the card.
Page 118: Selftimer/Remote Control
SELFTIMER/REMOTE CONTROL Use a tripod to hold the camera securely. Set the Mode dial to Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select F2.0 1/800 + 2.0 Press the right arrow on the Jog dial, then press the top/bottom arrows to select ON .
Page 119 Press the left arrow on the Jog dial to confirm the setting. Press the OK button to save the setting and cancel the Menu. • You can record movies without pressing the OK button. Note: • Unless OFF is selected in All Reset, the setting will be canceled when the power is turned off.
Page 120 RECORDING A MOVIE USING THE SELFTIMER When the shutter is released, the Shutter release button Selftimer/Remote control signal Selftimer/Remote lights for approx. 10 seconds then control signal blinks for approx. 2 seconds before the movie is recorded. To stop the activated selftimer, press the Menu button.
Page 121 RECORDING A MOVIE USING THE REMOTE CONTROL Compose the picture, aim the remote control at the Remote control window 15° 15° camera, then press Shutter release button on the remote control to record a movie. • The Selftimer/Remote control signal blinks for approx. 3 seconds before the movie is 16.4ft recorded.
Page 122: White Balance
WHITE BALANCE You can select the white balance according to the light source. Set the Mode dial to Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select WB. Press the right arrow on the Jog dial, then press the top/bottom arrows select...
Page 123 Press the left arrow on the Jog dial to confirm the setting. If you record a movie without pressing the OK button, the setting will be valid until the Menu is canceled. • Press the OK button to save the setting and cancel the Menu.
Page 124: Iso
You can select the sensitivity from auto, as well as approx. 100, 200 and 400. Set the Mode dial to Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select ISO. Press the right arrow on the Jog dial, then press the top/bottom arrows to select the sensitivity.
Page 125 Press the left arrow on the Jog dial to confirm the setting. If you record a movie without pressing the OK button, the setting will be valid until the Menu is canceled. • Press the OK button to save the setting and cancel the Menu.
Page 126: Picture Effects
PICTURE EFFECTS You can select from two picture effects. Set the Mode dial to Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select FUNCTION. Press the right arrow on the Jog dial, then press the F2.0 1/800 + 2.0 top/bottom arrows to select the desired picture effect.
Page 127: Card Setup (Card Format)
CARD SETUP (CARD FORMAT) You can format the card. Set the Mode dial to Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select CARD SETUP. Press the right arrow on the F2.0 1/800 + 2.0 Jog dial to select CARD...
Page 128 • Formatting will not be engaged when the write-protect adhesive seal is placed on the card. • Non-Olympus brand cards or cards formatted from or used in a computer must be formatted by the camera. These cards may take longer to record than recommended Olympus brand cards.
Page 129: Selecting The Recording Mode
SELECTING THE RECORDING MODE You can select the Standard Quality mode SQ or the High Quality mode Set the Mode dial to Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select Press the right arrow on the Jog dial, then press the top/bottom arrows to select...
Page 130 If you record a movie without pressing the OK button, the setting will be valid until the Menu is canceled. • Press the OK button to save the setting and cancel the Menu. Mode Resolution 160 x 120 (5 frames/sec.) 320 x 240 (5 frames/sec.) Note: •...
Page 131: Movie Picture Display Menu
MOVIE PICTURE DISPLAY MENU * When the Mode dial is set to and a movie picture is displayed on the LCD monitor. (p. 39) Monitor display PLAY For displaying movie pictures as a movie. (p. 132) CARD For performing All-Frame erase or Card format. SETUP (p.
Page 132: Playing Movies
PLAYING MOVIES You can play movies you have recorded. will appear on the LCD monitor for movies. Set the Mode dial to • The LCD monitor turns on automatically. Display a picture with the LCD monitor using the Jog dial. •...
Page 133 Press the OK button during the movie to pause it. Press it again to restart. • The following operations can be performed during pause. Press the top arrow on the Jog dial to pause at the beginning ’99.12.23 21:56 of the movie. Press the bottom arrow to pause at the ending of the movie.
Page 134: Card Setup
CARD SETUP ALL-FRAME ERASE Set the Mode dial to Display a picture with the LCD monitor using the Jog dial. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select CARD SETUP. PLAY CARD SETUP...
Page 135 Press the OK button with YES selected to erase all the pictures in the card. • To cancel, press the OK button with NO selected. When complete, NO PICTURE appears on the LCD monitor. • Protected frames will remain in the card, and the last frame will be displayed.
Page 136: Card Format
CARD FORMAT You can format the card. Set the Mode dial to Display a picture with the LCD monitor using the Jog dial. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select CARD SETUP.
Page 137 • Formatting will not be engaged when the write-protect adhesive seal is placed on the card. • Non-Olympus brand cards or cards formatted from or used in a computer must be formatted by the camera. These cards may take longer to record than recommended Olympus brand cards.
Page 139: Printing Pictures
PRINTING PICTURES...
Page 140: Printing Pictures
Camera File system/DCF” standard in the card for making prints using a printer or lab that supports this system. (p. 141 ~ 145) The other is Direct-Print, which is for use with the Olympus P-330N, P- 330 or P-300 printer.
Page 141: Card Print
CARD-PRINT PRINT-RESERVE (CARD) You can store data for making prints with a printer or at a lab that supports this system. (p. 140) Set the Mode dial to Display the picture you want to print, then press the Shutter release button. •...
Page 142: Still Picture Display Menu (Card-Print)
STILL PICTURE DISPLAY MENU (CARD-PRINT) * When the Mode dial is set to and a still picture is displayed on the LCD monitor. (Page 2/2 of the Menu.) (p. 39) Monitor display For storing data for Print-All (card). (p. 143) For storing data for Date-Print (card).
Page 143: Print-All (Card)
PRINT-ALL (CARD) You can store data for printing all the pictures in the card. (p. 140) Set the Mode dial to , and display a still picture . Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select •...
Page 144: Date-Print (Card)
DATE-PRINT (CARD) You can store data for printing the date with pictures. (p. 140) Set the Mode dial to , and display a still picture. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select •...
Page 145: Index-Print (Card)
INDEX-PRINT (CARD) You can store data for making index prints. (p. 140) Set the Mode dial to , and display a still picture . Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select CARD INDEX.
Page 146: Direct-Print
DIRECT-PRINT PRINTING WITH THE P-300 By connecting the camera to the P-300 printer with the direct connect cable, pictures can be printed directly from the camera. Make sure that the power of the printer and the camera are off before connecting.
Page 147 Set the Mode dial to turn on the LCD monitor. Select the picture you want to print using the Jog dial. Enter the number of copies to be printed on the printer, then press the DIRECT PRINT button on the printer to start printing.
Page 148: Index Print (P-300)
INDEX PRINT (P-300) Index prints can be made. Connect the camera to the printer, then set the Mode dial • See page 146 for connection to the printer. Select the Index-Display mode. (p. 95) Enter the number of copies to be printed on the printer, then press the DIRECT PRINT button to start printing.
Page 149: Close-Up Print (P-300)
CLOSE-UP PRINT (P-300) You can print enlarged images. Connect the camera to the printer, then set the Mode dial • See page 146 for connection to the printer. Select the Close-Up display mode. (p. 96) Enter the number of copies to be printed on the printer, then press the DIRECT PRINT button to start printing.
Page 150: Random Print (P-300)
RANDOM PRINT (P-300) You can select a series of pictures to be direct-printed to the P-300 printer. Connect the camera to the printer, then set the Mode dial • See page 146 for connection to the printer. Display the picture you want to print, then press the Shutter release button.
Page 151 Enter the number of copies to be printed on the printer, then press the DIRECT PRINT button to start printing. Note: • This mode is available only when the camera is connected to the P-300 printer. • The selection data will remain even after printing, but will be erased when the Mode dial is switched.
Page 152: Direct Print Menu
DIRECT PRINT MENU * When the Mode dial is set to and the camera is connected to a P- 300 printer. (p. 39) Monitor display For printing all the pictures in the card. (p. 153) For making 4-cut prints. (p. 154) For making 16-cut prints.
Page 153: All Print (P-300)
ALL PRINT (P-300) You can print all the pictures in the card using the P-300 printer. Connect the camera to the printer, then set the Mode dial • See page 146 for connection to the printer. Press the Menu button to display the Menu.
Page 154: Cut Print (P-300)
CUT PRINT (P-300) You can make 4/16-cut prints using the P-300 printer. • In order to make sticker prints, the specialty paper must be set in the P- 300 printer’s paper feeder. Connect the camera to the printer, then set the Mode dial •...
Page 155: Mirror Print (P-300)
MIRROR PRINT (P-300) You can make mirror-image prints using the P-300 printer. This mode is especially useful for making T-shirt prints. Connect the camera to the printer, then set the Mode dial • See page 146 for connection to the printer. Display the picture you want to print.
Page 156: Date Print (P-300)
DATE PRINT (P-300) You can print the date with pictures using the P-300 printer. Connect the camera to the printer, then set the Mode dial • See page 146 for connection to the printer. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select •...
Page 157: Using Apersonal Computer
USING A PERSONAL COMPUTER...
Page 158: Computer System Requirements
COMPUTER SYSTEM REQUIREMENTS When using the provided utility software: Personal computers used with this camera must conform to the following minimum standards. IBM PC/AT compatible Windows 98/95/NT4.0 : Pentium or later CD-ROM drive 16MB RAM 45MB available HD space Standard RS-232C interface D-SUB 9-pin connector Monitor with 256 colors 640 x 480 screen resolution...
Page 159: Installing Provided Software
INSTALLING PROVIDED SOFTWARE To take full advantage of a wide range of functions, including download, display, storage and panorama, your Olympus digital camera comes with software applications and CAMEDIA Master. For installation and operation, please refer to the software’s online documentation.
Page 160: Connecting To A Personal Computer
CONNECTING TO A PERSONAL COMPUTER Use the appropriate connector according to your computer’s platform. IBM PC/AT compatible Connect the provided RS-232C PC serial cable to the D-SUB 9-pin COM 1 or COM 2 serial port on your computer. DOS/V D-SUB 9-pin serial port Computer connector RS-232C PC...
Page 161: Using A Personal Computer
USING A PERSONAL COMPUTER Make sure that the power of the personal computer and the camera are OFF. Connect the RS-232C PC serial cable to the computer’s serial port. Remove the lens cap, and connect the cable to the camera’s Computer connector.
Page 162: Transferring Data From Smartmedia
TRANSFERRING DATA FROM SmartMedia PC CARD ADAPTER The picture data in the SmartMedia can be directly transferred to a personal computer equipped with a PC card (PCMCIA) slot or an external PC card reader/writer, using the optional PC Card Adapter. FlashPath FLOPPYDISK ADAPTER The picture data in the SmartMedia can be directly transferred to a personal computer equipped with a 3.5"...
Page 163: Using Camedia Master
USING CAMEDIA Master VIEWING IMAGES STORED IN THE CARD ON YOUR COMPUTER You can view images stored in a SmartMedia card via CAMEDIA Master. Start CAMEDIA Master on the computer. Click on [My Camera]. A thumbnail index of stored images will be displayed.
Page 164 Place the cursor on the desired image and double- click on it. This will magnify and display the selected image. TRANSFERRING DATA USING CAMEDIA Master CAMEDIA Master transfers images stored in the card to your computer. Start CAMEDIA Master on the computer.
Page 165: Processing Images Using Camedia Master
PROCESSING IMAGES USING CAMEDIA Master You can process images (changing tones, composing, and so on) using the provided CAMEDIA Master or other application software. MAKING DARK IMAGES BRIGHT Some images may come out darker than expected. You can try taking pictures again right after shooting, but may often miss the right moment for a good picture.
Page 166: Correcting Blurry Images
Select [Image] - [Instant Fix] on the menu bar. This will brighten the selected image. CORRECTING BLURRY IMAGES Backlight sometimes make the whole image blurry, and an object which stands before the subject may be out-of-focus. Use CAMEDIA Master Sharpen when this happens to sharpen the whole image. However, you should note that it doesn’t wipe out image blur thoroughly.
Page 167 Place the cursor on the image you want to correct and double-click on it. This will display the selected image. Select [Image] – [Filter] – [Sharpen] on the menu bar. Specify degree sharpness either by sliding the slide bar or inputting a value from 1 to 9, while comparing “Original”...
Page 168: Composing Images With Templates
This will sharpen the selected image. COMPOSING IMAGES WITH TEMPLATES You can easily compose images with templates in CAMEDIA Master. Place the cursor on the image you want to compose and double-click on it. This will display the selected image.
Page 169 Select [Image] - [Template Superimpose] on the menu bar. This will display the compose window. Select a template and click on [Apply]. This will display the preview image. When you are happy with the sample image, click on [OK]. The composed image will be displayed.
Page 171: Camera Settings
CAMERA SETTINGS The settings can be adjusted in the Menu. Each Menu (still picture record menu, still picture display menu, movie picture record menu and movie picture display menu) has different available settings. (p. 66/99/117/131)
Page 172: All Reset
ALL RESET Clears adjustments and returns to the default settings. Set the Mode dial to P, A/S/M Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select MODE SETUP, then press the right arrow to select SETUP and press the OK button.
Page 173 With ON selected, the settings of the following items will be canceled and reset to the default when the power is turned off. Aperture priority mode (p. 51), Shutter priority mode (p. 52), Manual mode (p. 54), Zoom (p. 55/113), Exposure compensation (p.
Page 174: Sharpness
SHARPNESS You can select the image sharpness. Set the Mode dial to P, A/S/M Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select MODE SETUP, then press the right arrow to select SETUP and press the OK button.
Page 175: Shq Setup
SHQ SETUP You can select non-compression for the SHQ mode. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select MODE SETUP, then press the right arrow to select SETUP and press the OK button.
Page 176: Sq Setup
SQ SETUP You can select the file size and compression level for the SQ mode. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select MODE SETUP, then press the right arrow to select SETUP and press the OK button.
Page 177: Beep Sound
BEEP SOUND You can select the volume of the operating beep sound. Set the Mode dial to P, A/S/M, Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select MODE SETUP, then press the right arrow to select SETUP and press the OK button.
Page 178: Rec View
REC VIEW Rec view lets you select whether to display the image after recording. Set the Mode dial to P, A/S/M Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select MODE SETUP, then press the right arrow to select SETUP and press the OK button.
Page 179 Press the top/bottom arrows REC VIEW on the Jog dial to select REC FILE NAME VIEW. m/ f t Press the right arrow on the 2 / 2 Jog dial, then press the top/bottom arrows to select OFF (Rec view off) or ON (Rec view on).
Page 180: File Number
FILE NUMBER You can select the file numbering system. It is especially useful when downloading data to a personal computer. About the File No. and Folder No. The file number and folder number used for each image are expressed as shown. Folder No.
Page 181: Setup Mode
Note: • For convenience, the folder numbers remain the same when transferred to a computer in both selections. \ DCIM \ *** OLYMP \ Pmdd **** .jpg Folder No. Set the Mode dial to P or A/S/M. Press the Menu button to display the Menu.
Page 182 Press the top/bottom arrows REC VIEW on the Jog dial to select FILE FILE NAME NAME RESET NAME. AUTO FILE Press the right arrow on the Jog dial, then press the m/ f t top/bottom arrows to select 2 / 2 NAME RESET or AUTO FILE.
Page 183: Lcd Brightness
LCD BRIGHTNESS You can adjust the brightness of the LCD monitor. Set the Mode dial to P, A/S/M, Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select MODE SETUP, then press the right arrow to select SETUP and press the OK button.
Page 184 Press the top/bottom arrows REC VIEW on the Jog dial to select FILE NAME SETUP Press the right arrow on the Jog dial to select SETUP, then press the OK button. m/ f t • appears on [ 2 / 2 ] the LCD monitor.
Page 185: Meters/Feet Selection
METERS/FEET SELECTION You can select meters or feet to be used by the Manual focus setting screen. (In the Macro mode, the unit will shift between centimeters and inches.) Set the Mode dial to P, A/S/M Press the Menu button to display the Menu.
Page 186: Index-Display Adjustment
INDEX-DISPLAY ADJUSTMENT You can select the number of frames shown in the Index-Display mode. Set the Mode dial to Press the Menu button to display the Menu. Press the top/bottom arrows on the Jog dial to select MODE SETUP, then press the right arrow to select SETUP and press the OK button.
Page 187: Miscellaneous
MISCELLANEOUS...
Page 188: Questions And Answers
QUESTIONS AND ANSWERS How long will the batteries last? Battery life is affected by many variables such as the amount of LCD monitor use, the frequency of flash use, as well as by the kind of battery used and the environmental conditions under which the camera is used.
Page 189 Can I use a filter or hood? Olympus does not provide one. Can I use an extension flash? can. Please Internet home page (http://www.olympus.com).
Page 190: Troubleshooting
TROUBLESHOOTING OPERATING PROBLEMS The camera does not work. The power is OFF. [ Set the Mode dial to turn on the power. (P. 34) The batteries are loaded incorrectly. [ Reload the batteries correctly. (P. 24) The batteries are exhausted. Replace the batteries with new ones.
Page 191 The flash does not fire. The flash mode was set to the Off mode. Check the flash mode before shooting. (P. 57) The subject is lighted. Set the flash to Fill-In mode. (P. 57/59) The pictures already taken do not appear on the LCD monitor. The camera is in the Record mode.
Page 192: Problems With Images
PROBLEMS WITH IMAGES The picture is out of focus The camera moved when the shutter button was pressed. [ Hold the camera correctly, and press the shutter button. (P. 32/33) The viewfinder’s autofocus mark was not positioned on the subject. [ Position the autofocus frame on the subject, or use the focus lock.
Page 193 The picture is too bright. The flash was set to the Fill-In Flash mode. [ Set the flash mode to one other than Fill-In Flash. (P. 57) The subject was very bright. [ Either adjust the exposure or point the camera away from overly bright subjects.
Page 194: System Chart
SYSTEM CHART A variety of capabilities are available when connected to optional equipment. Printer (P-330N/P-330) SmartMedia FlashPath MO drive PC card adapter Personal computer AC adapter Modem Camera Printer (P-300) Conversion lens adapter Remote control Tele Conversion lens Wide conversion lens Modem Macro...
Page 195: Error Codes
ERROR CODES LCD monitor Error There is no card in the camera. Insert a SmartMedia card. NO CARD No more photographs can be taken. Replace the SmartMedia, erase unwanted pictures, or transfer the data to a personal computer and free up space CARD FULL in the SmartMedia.
Page 196: Optional Items
OPTIONAL ITEMS • Photo Printers For Olympus Digital Cameras • AC Adapter • Camera Case • Standard SmartMedia Card (8/16/32/64MB) • Special Function SmartMedia Cards Template Card (4MB) Calendar Card (4MB) Title Card (4MB) • FlashPath Floppy Disk Adapter • PC Card Adapter •...
Page 197: Compatibility Of The Picture Data
COMPATIBILITY OF THE PICTURE DATA • Images taken by this camera may not be properly displayed or printed with other Olympus digital cameras. • Images taken by other Olympus digital cameras may not be properly displayed or printed with this camera.
Page 198: Specifications
White balance : Full auto TTL, Manual (daylight, overcast, tungsten light, fluorescent) Lens : Olympus lens 6.5 ~ 19.5 mm, F2.0 ~ 2.8, 8 elements in 6 groups (equivalent to 35 ~ 105 mm lens on 35 mm camera), aspherical glass...
Page 199 Working range : 8" ~ 31" (Macro mode) 31" ~ ! (Standard mode) Viewfinder : Optical real image viewfinder (Autofocus mark/Backlighting correction mark), LCD monitor LCD monitor : 1.8" TFT color LCD display No. of pixels : Approx. 114,000 pixels On-screen display : Date/Time, Frame number, Protect, Recording mode, Battery check, Picture...
Page 200 Power supply : This camera uses four AA nickel metal- hydride batteries, AA alkaline batteries, AA lithium batteries or AA NiCd batteries. Do not use manganese batteries. AC adapter (optional) Dimensions : 4.2" (W) x 2.9" (H) x 2.6" (D) (107.5 x 73.8 x 66.4 mm) Weight : 10.8 oz (without batteries/card)
Page 204 San-Ei Building, 22-2, Nishi Shinjuku 1-chome, Shinjuku-ku, Tokyo, Japan. Tel. 03-3340-2026 OLYMPUS AMERICA INC. Two Corporate Center Drive, Melville, NY 11747-3157, U.S.A. Tel. 516-844-5000 OLYMPUS OPTICAL CO. (EUROPA) GMBH. (Premises/Goods delivery) Wendenstraße 14-16, 20097 Hamburg, Germany. Tel. 040-237730 (Letters) Postfach 10 49 08, 20034 Hamburg, Germany.
