If you have selected the Admin/Link status mode, a port is considered:
•
•
•
•
If you have selected the Admin status mode, a port is considered:
•
•
These conditions do not reflect link status.
If you have selected the Link status mode, a port is considered:
•
•
•
Viewing Chassis Information
ON if the port is enabled and has a valid link.
OFF if it has not been enabled or if it has been disabled through management
action.
SEG (segmented) if the port has been enabled by management and has a valid
connection, but has been segmented by the repeater because 33 consecutive
collisions have occurred on the attached segment, or the collision detector was
on for more than 2.4 µs.
NLK (Not Linked) when the port is on, but there is no physical link to the port.
This field is a combination of two status conditions: No Link and Port
Administrative Status On.
ON if the port is enabled.
OFF if the port has been disabled by management.
LNK (Linked) when a valid link has been established between the port and the
device at the other end of the segment.
NLK (Not Linked) when the port is on, but there is no physical link to the port
or the device at the other end of the port's segment is down.
N/A (not available) when NetSight Element Manager cannot determine the
link status for the port.
