Evolution MK-425C/449C/461C Advanced User Guide
Assigning MIDI CC's
Once the controller you want to edit has been selected, you can change the assigned
MIDI cc number in the following way:
1.
Press "CONTROL ASSIGN". The LCD will flash the CC symbol.
The 3 digit display will indicate the currently assigned MIDI cc number.
2.
Type in a new MIDI cc value using the numeric keypad or '+' and '-' buttons.
The MIDI controller number you select will be assigned to the currently selected
controller, shown by the number on the small, 2-digit display.
Assigning An Individual MIDI Channel
1.
Select the controller you want to edit as described earlier.
2.
Press "CHANNEL ASSIGN".
The LCD will display the CHAN symbol and the 3-digit display will show the
current channel assignment of the selected controller, preceded by a 'c'. The
small 2-digit display will show the currently selected controller for assignment.
3.
Type the MIDI channel number (01-16) you want the controller to send to,
using the numeric keypad or the +/- keys.
If the controller is assigned to channel 00, it will transmit on the global channel.
Setting Toggle Values For The Buttons
The 10 assignable buttons can each be assigned to toggle between two values. You
may for instance want to send out value 15 when you first press the button followed by
value 74 when you press the button for a second time. This is how you do it:
1.
Press the Function button labelled "DATA MSB" 2 times.
2.
Type in 15 using the numerical keypad or the +/- keys.
3.
Press the Function button labelled "DATA LSB" 2 times.
4.
Type in 74 using the numerical keypad or the +/- keys.
If you want the button to send the same value every time you press it, simply type in the
same value both times.
Example: After pressing ASSIGN, the display shows the
cc symbol and in this case displays that currently the MIDI cc 07 is
assigned to fader/rotary controller number 33.
6
