A Guide to Operating and Maintaining Your
Single-Packaged Electric Cooling Units
NFATUNG & COOLING
NOTE: Read the entire instruction manual bellk_re starting the
installation.
SAFETY CONSIDERATIONS
Note to h_stal[er:This manual should be left with the equipment
user.
Do not store or use gasoline or other flamnmble wq_ors and
liquids in the vicinity of these or any other appliances. Failure
to follow this warning could result in fire, serious injury, or
death.
Do not use either of these malts if any part has been under
water. Immediately call a qualified service technician to
inspect the unit and to replace any part of the control system
which has been under water. Failure to _k_llow this warning
could result in electrical shock, fire, serious injury, or death.
Be%re per%rming recommended maintenance, be sure the
main power switch to unit is turned off and lock-out tag
installed. Electric shock could cause serious it{jury or death.
STARTING OR SHUTTING UNIT OFF
1. To start this unit:
a. Turn on the electrical power supply to unit.
b. Select temperature and set SYSTEM switch or MODE
control to desired mode.
2. To shut this unit off:
NOTE: If the unit is being shut down because of a malNnction,
call your dealer as soon as possible.
a. Set system SWITCH or MODE contlol to OFF.
b. Turn off the electrical power supply to unit and install
lock-out tag.
OPERATING YOUR ELECTRIC AmR CONDITIONER
The operation of'your system is conholled by the indoor thermo-
stat. You simply adjust the thermostat and it maintains the indoor
temperature at the level you select. Most themaostats have 3
controls: a temperature control selector, a FAN control, and a
SYSTEM or MODE control. RefEr to your thermostat owner's
manual for more infbrmation.
To better protect your investment and to eliminate unnecessa_
sela'ice calls, familiarize yourself with the %llowing g_cts:
Step l--Cooling Mode
With the SYSTEM or MODE control set to COOL, your unit will
run in cooling mode until the indoor temperature is lowered to the
level you have selected. On extlemely hot days, your system will
run for longer periods at a time and have shorter "o_t" periods than
on moderate days.
Fig. 1--Unit 50GS (80Hz)
C99001
Step 2--Heating Mode (with optional electric heaters)
Your system may have optional electric heaters for use when
heating is desired.
With the SYSTEM or MODE control of your indoor thermostat set
to HEAT, your unit will rnn in heating mode until room tempera°
rare is raised to the level you have selected. Of course, your systenr
will run fbr longer periods to maintain a comfortable environment
on cooler days and nights than on moderate ones.
MAINTENANCE AND SERVICE
This section discusses maintenance that should be per%treed by
your dealer.
ROUTINE MAINTENAN< E
All routine maintenance should be handled by skilled, experienced
personnel Your dealer can help you establish a standard proce-
dure
For your safety, keep your unit area clear and thee of combustible
materials, gasolin< and other flammable liquids and vapors.
To assure proper ffinctioning of your unit, flow of condenser air
must not be obstructed fi'om reaching the unit. Clearance fi'om the
top of the unit is 48 in. (1220 ram). Clearance of at least 42 in.
(I070 ram) is required on sides, except the duct side which has a
12 in. (305 ram) minimum clearance.
MAINTENANCE AND <7ARE BY THE EQUIPMENT OVv_ER
Befbre proceeding with those things you might want to maintain
yourself, please careffilly consider the _bllo_;ing:
