Single-Package Rooftop Cooling Units
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-24
Step 1- Provide Unit Support . . . . . . . . . . . . . . . 1
• SLAB MOUNT
Step 2 - Field Fabricate Ductwork . . . . . . . . . . . 4
External Trap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Step 4 - Rig and Place Unit . . . . . . . . . . . . . . . . . 4
• POSITIONING
• HEAT ANTICIPATOR SETTINGS
PRE-START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-27
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-31
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . 32-34
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . . CL-1

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment
can be hazardous due to system pressure and electrical com-
ponents. Only trained and qualified service personnel should
install, repair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance func-
tions of cleaning coils and filters and replacing filters. All
other operations should be performed by trained service per-
sonnel. When working on air-conditioning equipment, ob-
serve precautions in the literature, tags and labels attached
to the unit, and other safety precautions that may apply.
Follow all safety codes. Wear safety glasses and work gloves.
Use quenching cloth for unbrazing operations. Have fire ex-
tinguisher available for all brazing operations.
Before performing service or maintenance operations on
unit, turn off main power switch to unit. Electrical shock
could cause personal injury.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 1 4
PC 111
Tab
1b 6b
Installation, Start-Up and
Service Instructions
Page
Catalog No. 535-042
Printed in U.S.A.
50GJ006-012
The 50GJ units may only be charged with R-407C re-
frigerant. Do not use R-22.
The use of R-407C necessitates the use of a polyolester
(POE) oil. POE oil is not to be confused with or mixed with
mineral oil typically used in R-22 systems. Precautions must
also be taken to minimize open exposure of the oil to at-
mosphere as it is very hydroscopic and will absorb moisture
from the air. To minimize the possibility of moisture con-
tamination to the refrigerant system a special 100% molecu-
lar sieve filter drier is used.
Refrigerant R-407C must always be charged liquid. Charg-
ing gas will cause the refrigerant to fractionate and change
the chemical properties, impacting system performance.

INSTALLATION

Unit is shipped in the vertical configuration. To convert to
horizontal configuration, remove side duct opening covers.
Using the same screws, install covers on vertical duct open-
ings with the insulation-side down. Seals around duct open-
ings must be tight.
Step 1 - Provide Unit Support
ROOF CURB - Assemble and install accessory roof curb
in accordance with instructions shipped with curb. See
Fig. 1A and 1B. Install insulation, cant strips, roofing felt,
and counter flashing as shown. Ductwork must be attached
to curb. If electric or control power is to be routed through
the curb, attach the accessory thru-the-curb service connec-
tion plates to the roof curb in accordance with the accessory
installation instructions. Connection plates must be installed
before unit is set on roof curb.
IMPORTANT: The gasketing of the unit to the roof
curb is critical for watertightness. Install gasket sup-
plied with the roof curb as shown in Fig. 1A and 1B.
Improperly applied gasket can also result in air leaks
and poor unit performance.
Curb should be level. Unit leveling tolerances are shown
in Fig. 2. This is necessary for unit drain to function prop-
erly. Refer to Accessory Roof Curb Installation Instructions
for additional information as required.
SLAB MOUNT (Horizontal Units Only) - Provide a level
concrete slab that extends a minimum of 6 in. beyond unit
cabinet. Install a gravel apron in front of condenser coil air
inlet to prevent grass and foliage from obstructing airflow.
NOTE: Horizontal units may be installed on a roof curb if
required.
Form 50GJ-1SI
Pg 1
4-95
