Campbell Hausfeld VT6333 Operating Instructions Manual

See Warranty on page 8 for Important information about commercial use of this product.
Portable Air
Compressors
Description
Air €ompressor units are intended to
provide compressed air to power
pneumatic toob and operate spray
guns. The pumps on these units are oil
lubricated. A small amount of oil
carryover is present in the compressed
air stream. Applications requiring air
free of oil or water should hove the
appropriate filter installed, The air
compressor unit must he mounted on a
solid floor or solid ground. Any other
use of these units will void the
warranty and the manufacturer wig not
be responsible for problems or
damages resulting from such misuse.
Safety Guidelines
This manual contains information that
is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
_ Danger _ates
Inlu_€.
• poesnt;_
I_u_.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may have
occurred during transit. Make sure to
tighten fittings, bolts, etc., before
putting unit into service.
DO not operate
unit if dam_
_ m_y mult in bwst_ a_l
cause inju_y or pr_rry damaSW.
General Safety
Information
Since the air compressor and other
components (material pump, spray
guns. filters, lubricators, hoses, eta-)
used, make up a high pressure
pumping system, the following safety
precautions must be observed at all
times:
1. Read all manuals _" _ ]
included with this |
product carefully, Be[
thoroughly familiar
with the controls
and the proper use of the
equipment.
2. Follow all local electrical and safety
codes as well as in the United States,
the National Electrical Codes (NEC)
and Occupational Safety and Health
ACt (OSHA).
3. Only persons well acquainted with
these rules of safe operation should
be allowed to use the compressor.
4. Keep visitors away and NEVER allow
children in the work area.
5. Wear safety glasses and use
hearing protection when operating
the unit.
6. Do not stand on or use the unit as
a handhold.
Breathable Air Warning
This compressor/pump Is NOT
equipped and should NOT be used
"as is" to supply breathing quality
air° Fo_" any applkation of air for
human consumption, you must fit
the air €ompressor/l_m p with
suitable in4ine safety and a_ann
equipmenL This edditional
equipment is necessary to properly
filter and purify the air to meet
minimaJ specifications for Grade D
breathing as described in
Compressed Gas AssodaUon
Commodity Specifkation G 7.1 -
1966, OSHA 29 CFR 1910. 1340
and/or Canadian Standards
Associations (CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is used
for the pu_ose of breathing air
application and proper ir_line
safety and alarm equipment is not
simultaneously used, existing
warranties are void, and Campbell
Nausteld disclaims any IJability
whatsoever for any loss, personal
injury or damage.
7. Before each use, inspect compressed
air system and electrical
components for signs of damage.
deterioration, weakness or leakage.
Repair or replace defective items
before using.
8. Check all fasteners at frequent
intervals for proper tightness.
I REMINDER: Keep your dated p_oof of i_lrdtase fro" warranty purpoml Attach It to this manual fill it for I
of
saf_ke4_tg.
g
O 2002 Campbell HausfeldFacott Fatzer _r parir_p_odu_ & _r_k* inf=_matlon IN227809AV 12/02
visit www.¢hpower.€om
