PRODUCT DATASHEET
ENERGIZER CRV3
Industry Standard Dimensions
mm (inches)
This Battery has Underwriters
Laboratories component Recognition
ø6.50 (0.256)
Typical
14.10 (0.555)
Typical
28.20 (1.110)
28.60 (1.126)
This battery contains a Positive Temperature
Coefficient (PTC) safety device to limit current
during short circuit conditions.
Simulated Application Tests
Typical Performance at 21°C (70°F)
Schedule Drain Drain
(time) (mA) (mW)
200 ---
Continuous
1000 ---
Continuous
--- 1000
Continuous
--- 2000
Continuous
This datasheet contains typical information specific to products manufactured at the time of its publication.
Form No. EBC - 4210H
(ELCRV3)
14.00 (0.551)
14.40 (0.567)
51.60 (2.031)
52.20 (2.055)
Cutoff Voltage
2.5V 2.0V 1.5V
(hours) (hours) (hours)
14.7 15.7 15.8
1.8 2.8 2.9
7.7 8.5 8.5
3 3.8 3.8

Important Notice

©Energizer Holdings, Inc. - Contents herein do not constitute a warranty.

Specifications

Classification: "Lithium Photo"
Chemical System: Non-Aqueous Lithium
Designation: Pending
Nominal Voltage: 3.0 Volts
Storage Temp: -40°C to 60°C (-40°F to 140°F)
Operating Temp: -40°C to 60°C (-40°F to 140°F)
Typical Capacity: 3000 mAh (to 2.0 volts)
(Rated at 200 mA at 21°C)
Typical Weight: 32 grams (1.1 oz.)
Typical Volume: 24 cubic centimeters (1.5 cubic inch)
Max Discharge: 2000 mA continuous (3000 mA pulse)
Typical Li Content: 1.25 grams (0.04 oz.)
UL Listed: MH12454
Shipping: For complete details, please reference:
Global (except US): Special Provision A45 of the International
Air Transport Association Dangerous
Goods Regulations
United States: 49 CFR 173.185
Typical Discharge Characteristics
Constant Current Discharge
3.5
3.0
2.5
2.0
1000 mA
1.5
0 4
Constant Power Discharge
3.5
3.0
2.5
2000 mW
2.0
1.5
0 2
1-800-383-7323 US/CAN
www.energizer.com
at 21 C
200 mA
8 12
Service, Hours
at 21°C
1000 mW
4 6 8
Service, Hours
Page 1 of 1
16
10
