1.10 Audio Subsystem

The onboard audio subsystem consists of the following:
• Intel 82801IR (ICH9R)
• IDT STAC9271 audio codec
• Back panel audio connectors
• Component-side audio headers:
⎯ Intel High Definition Audio front panel header
®
⎯ HD audio link header
The audio subsystem supports the following features:
• Dolby Home Theater support
• A signal-to-noise (S/N) ratio of 95 dB
• Independent multi-streaming 7.1 audio (using the back panel audio connectors)
and stereo (using the Intel High Definition Audio front panel header)
• ADAT support from the back panel optical S/PDIF port
NOTE
Systems built with AC 97 front panel will not be able to obtain the Microsoft Windows
Vista* logo after June 2007.
Table 4 lists the supported functions of the front panel and back panel audio jacks.
Table 4. Audio Jack Retasking Support
Audio Jack
Front panel – Green
Front panel – Pink
Back panel – Blue
Back panel – Green
Back panel – Pink
Back panel – Black
Back panel - Orange
1.10.1

Audio Subsystem Software

Audio software and drivers are available from Intel's World Wide Web site.
For information about
Obtaining audio software and drivers
Supports Supports
Line in? Line out?
No Yes
No No
Yes Yes
No Yes
No No
No Yes
No Yes
Product Description
Supports
Microphone? Headphones?
No Yes
Yes No
No No
No Yes
Yes No
No No
No No
Refer to
Section 1.2, page 15
Supports
23
