Operating Instructions
ABSORPTION-REFRIGERATOR
RM 7390 (L)
EN
OPERATING INSTRUCTIONS / INSTALLATION INSTRUCTIONS
Type C40 / 110
Please state for future reference :
Model number
.............................................
Product number
.............................................
Serial number
.............................................
for RECREATIONAL VEHICLES
ABSORPTION REFRIGERATOR
T.B. MB 05/2006
English
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dometic RM 7390 (L
Summary of Contents for Dometic RM 7390 (L
-
Page 1: Operating Instructions
Operating Instructions ABSORPTION-REFRIGERATOR for RECREATIONAL VEHICLES RM 7390 (L) OPERATING INSTRUCTIONS / INSTALLATION INSTRUCTIONS ABSORPTION REFRIGERATOR Please state for future reference : T.B. MB 05/2006 Model number ..........Product number ..........Type C40 / 110 Serial number ..........English... -
Page 2: Safety Instructions
Please observe the following sections in these instructions: "5.1 Cleaning" and "5.3 Storing food". These operating instructions should be kept in a safe place. If this device is passed on, please include these operating instructions with it. © Dometic GmbH - 2006 - Subject to change without notice - Printed in Germany... -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........FOR YOUR SAFETY . -
Page 4: Introduction
1 1 . . 0 0 INTRODUCTION You have made an excellent choice in selecting the Dometic Absorption Refrigerator. We are sure that you will be fully satisfied with your new appliance in all respects. The appliance, which works silently, meets high quality standards and guarantees the efficient utilisation of resources and energy throughout its entire life cycle, during manufacture, in use and when being disposed of. -
Page 5: Warranty And Customer Service
Warranty arrangements are in accordance with EC Directive 44/1999/CE and the normal conditions applicable for the country concerned. For warranty or other servicing, please contact our Dometic Service department. Any damage due to impro- per use is not covered by the warranty. The warranty does not cover any modifica- tions to the appliance or the use of non-original Dometic parts;... -
Page 6: Using The Refrigerator
Using the refrigerator The cooling unit is silent in operation. When the appliance is first put into operation, there may be a mild odour which will disappear after a few hours. Ensure the living area is well ventilated. The freezer compartment should be cold about one hour after switching on the refrigerator. -
Page 7: Electrical Operation
5.2.2 Electrical operation 1. 12V DC The refrigerator should only be used while the motor is running. Set energy selector switch (A) to 12 V . The refrigerator operates without thermostatic control (continuous operation). 2. Mains power This option should only be selected where the supply voltage of the connection for power supply corresponds to the value specified on the data plate. - Page 8 1. Manual Ignition with "Piezo igniter" 1. Open the valve of the gas cylinder. 2. Open the shut-off valve to the gas supply. 3. Set energy 4. Press and hold selector switch rotary switch (B) (A) to 5. Activate Piezo 6.
-
Page 9: Storing Food
Dometic refrigerators work according to the absorption principle. Due to physical reasons, an absorption system responds slowly to changes made on the thermostat controller, or a loss in cooling through opening the door, or storing food. The devices fulfill the cooling performance require- ments of the Climatic Class SN acc. -
Page 10: Making Ice Cubes
Making ice cubes Ice cubes are best frozen overnight. At night, the refrigerator has less work to do and the unit has more reserves. 1. Fill the ice 2. Place the ice cube tray cube tray with in the freezer drinking water. -
Page 11: Door Locking
Door locking open close Always shut and lock the refrigerator before you start your journey. Switching off park position 1. Set energy selector switch (A) 2. Secure the door open by means of the door to position "0" (OFF). The appliance is stop. -
Page 12: Winter Operation
3. Fit new light bulb. bulb. Note: for 12V DC : 1 light bulb 8V, 2W for 24V DC : 2 light bulbs 28V, 1,5W Please contact Dometic Service centres for 4. Clip the cover back in replacement light bulbs. place. -
Page 13: Changing The Decor Panel
5.11 Changing the decor panel 1. Open the door 2. Take off the door 3. Unscrew the door strip and loosen the by moving it upwards. (3 screws). hinge screw. 5. Screw the door 6. Put the door 4. Remove the decor 7. -
Page 14: Changing The Door
5.12 Changing the doorhang It is not always possible to change the door when the refrigerator is installed. 1. Tür öffnen, Scharnier- 2. Tür nach oben schraube lösen und wegnehmen. aufbewahren. 5. Tür aufsetzen. 8. Scharnierschraube einschrauben. -
Page 15: Troubleshooting
5.13 Troubleshooting Before calling the authorised Service Department, please check whether: 1. The instructions in the section "Using the refrigerator" have been followed. 2. The refrigerator is not tilted excessiveley. 3. It is possible to operate the refrigerator with an available power source. Failure : The refrigerator does not work in gas operation mode. -
Page 16: Maintenance
5.15 Product liability The product liability of Dometic GmbH does not cover damage due to improper use or any modifications or damage caused by the effect of environmental influence on the device or in direct proximity to the device as a result of this effect, e.g. temperature fluctuations and humidity. -
Page 17: Technical Data
5.19 Technical data Model Dimensions Groos capacity Usable Connection * Consumption Netweight Ignition Stepped H x W x D (mm) incl. freezer capacity of Mains / Battery electricity / gas Piezo cabinet depth incl. door compartment freezer in 24 hrs compart. -
Page 18: Installation Guide
25 mm! If the door/grille distance is between 25mm and 45 mm, we recommend installing a Dometic ventilation kit ( spare part no. 241 2985 - 00/0 ) to achieve an optimal cooling perfor- mance in high ambient temperatures. -
Page 19: Rear Installation
6.1.2 Side installation with floor-roof ventilation It is also possible to perform ventilation of the refrigerator via an aperture in the floor and a roof ventilation (see fig. 3). A flue has to be provided between the top edge of the refrigerator and the roof ventilation which directs the hot air and the exhausts hot air straight to the air vent in the roof. -
Page 20: Draught Free Installation
The device manufacturer's product liability and guarantee shall lapse if such materials are used. Proposal 1: Using the Installation Sealing Kit from Dometic (SP.No. 241 2559-00, available from Dometic) Insert lipped seals (A) into the installation recesses at the bottom and at each side. -
Page 21: Ventilation And Air Extraction
13cm² ( EN 1949). The ventilation grilles must have an open cross- section of at least 250 cm². This is reached using Dometic Absorber Ventilation and Air Extraction System L100 / L 200 that has been tested and approved for this purpose. -
Page 22: Installation Of The Ventilation System
Installing the ventilation system L 200 L 100 To install the ventilation grilles, cut two rectangles (451mm x 156mm) in the outer wall of the vehicle (for position of the cuts, see point 6.3). Item 1 does not apply for installation framess with an integrated seal. -
Page 23: Installation Recess
Installation recess The refrigerator must be installed draught-free in a recess. The measurements of the recess are given in the table below. Step (A) is only required for cabinets with a step. Push the appliance far enough into the recess until the front edge of the refrigerator casing is flush with the front of the recess. -
Page 24: Fume Extraction
Fume extraction Fume extraction must be arranged in such a way as to provide complete extraction of all products of combustion to an area outside the living area. The flue system must slope in an upward direction in order to avoid a build-up of condensation. -
Page 25: Gas Installation
6.7.2 Separate fume extraction min. 10 mm max. 20 mm Cut: 80mm high 40mm wide 1. Cut an 80mm x 40mm rectangle in the outer wall of the caravan. The position of the cut must be appropriate to the particular model of refrigerator and installation conditions. - Page 26 The gas connection to the appliance is effected by means of a suitable coupling tube fitting L8, DIN 2353-ST, complying with European Standard EN 1949 (e.g. Ermeto). The gas connection may only be carried out by a qualified personnel. SW 14 SW 17 Following proper installation, a testing for leakage and a flame test must be carried...
-
Page 27: Electrical Installation
Changes at the internal electrical installation or the connection of other electrical components (e.g. additional fan, no Dometic part) to the internal wiring of the appliance will expire the e1/ CE admittance as well as any claims from guarantee and product liability! 6.9.1... -
Page 28: Wiring Diagrams
6.9.3 Wiring diagrams 1. Wiring diagram with manual ignition and no interior light. battery connection DC mains connection AC heating- element thermo cut-off current heating- element 2. Wiring diagram with manual ignition and interior light Battery connection 12V/24V - A = Ground heating element DC, white battery connection B = heating element DC-, 12V/24V --... - Page 30 Dometic GmbH In der Steinwiese 16 D-57074 Siegen www.dometic.com...
