ASSEMBLY
OPERATION
REPLACEMENT PARTS
BOLT TORQUE SPECIFICATIONS
STANDARD BOLTS:
Size
Grade
Torque
5/16"
5
20 ft/lbs.
3/8"
5
35 ft/lbs.
7/16"
5
56 ft/lbs.
1/2"
5
85 ft/lbs.
8
1
REF.
PART
NO.
NO.
1.
00523
2.
00060
3.
00059
4.
00061
5.
07280
6.
07284
7.
07971-35
8.
07972-35
9.
07973-35
10.
07974-35
Please order replacement parts by PART NO. and DESCRIPTION.
• Dethmers Mfg. Co. • 4010 320th Street • P.O. Box 189 • Boyden, IA 51234
DEMCO
PH: (712) 725-2311 • Toll Free: 1-800-543-3626 • FAX: (712) 725-2380
METRIC BOLTS:
Size
8mm
10mm
12mm
14mm
6
5
1
2
1
9517047 PARTS LIST
QTY.
DESCRIPTION
8
3/8"-16UNC x 1-1/4" Hex Bolt Gr.5
8
3/8" Lockwasher
2
3/8" Flatwasher
8
3/8"-16UNC Hex Nut
2
10mm x 1.25 x 30mm Hex Bolt Gr.8.8
2
10mm Lockwasher
1
Left Mounting Bracket
1
Right Mounting Bracket
1
Cross Member
1
Center Support
www.demco-products.com
READ complete manual CAREFULLY
Torque
22 ft/lbs.
42 ft/lbs.
70 ft/lbs.
95 ft/lbs.
4
4
2
10
2
6
5
3
3
1
1
4
‘95-’97 Honda Odyssey
BEFORE attempting operation.
9
6-03
TP20047,Rev.2
7
Advertisement
Related Manuals for Demco TP20047
Summary of Contents for Demco TP20047
- Page 1 Center Support Please order replacement parts by PART NO. and DESCRIPTION. • Dethmers Mfg. Co. • 4010 320th Street • P.O. Box 189 • Boyden, IA 51234 DEMCO PH: (712) 725-2311 • Toll Free: 1-800-543-3626 • FAX: (712) 725-2380 www.demco-products.com...
-
Page 2: Installation Instructions
200 miles. At a minimum, these vehicles require sig- nificant modification, such as the use of an aftermarket product, to make them towable. The availability of a Demco Tow Bar Base Plate does not imply that these vehicles can be modified or that there is an aftermarket product available. - Page 3 2. Attach right and left mounting bracket with two previously existing bolts on each side. 3. Install cross member with three 3/8" x 1- 1/4" hex bolts, lockwashers and hex nuts on each side. 4. Install center support brace by taking two bolts out of vehicles center brace.
- Page 4 5. Trim splash shield according to photos and install. Note: Lower photos show where ears of splash panel will have to be trimmed off.
