ASSEMBLY
OPERATION
REPLACEMENT PARTS
BOLT TORQUE SPECIFICATIONS
STANDARD BOLTS:
Size
Grade
Torque
5/16"
5
20 ft/lbs.
3/8"
5
35 ft/lbs.
7/16"
5
56 ft/lbs.
1/2"
5
85 ft/lbs.
Pin Height 13"
8
1
REF.
PART
NO.
NO.
1.
00077
2.
00060
3.
00059
4.
00061
5.
07280
6.
07284
7.
10305-35
8.
10306-35
9.
07973-35
10.
10307-35
Please order replacement parts by PART NO. and DESCRIPTION.
DEMCO
Dethmers Mfg. Co. 4010 320th Street P.O. Box 189 Boyden, IA 51234
PH: (712) 725-2311 Toll Free: 1-800-543-3626 FAX: (712) 725-2380 or 1-800-845-6420
METRIC BOLTS:
Size
8mm
10mm
12mm
14mm
Centers- 24"
6
5
1
2
1
9517094 PARTS LIST
QTY.
DESCRIPTION
8
3/8"-16UNC x 1-1/4" Hex Bolt Gr.5
8
3/8" Lockwasher
2
3/8" Flatwasher
8
3/8"-16UNC Hex Nut
2
10mm x 1.25 x 30mm Hex Bolt Gr.8.8
2
10mm Lockwasher
1
Left Mounting Bracket
1
Right Mounting Bracket
1
Cross Member
1
Center Support
www.demco-products.com
READ complete manual CAREFULLY
Torque
22 ft/lbs.
42 ft/lbs.
70 ft/lbs.
95 ft/lbs.
4
4
2
10
2
6
5
3
3
1
1
4
Honda Odyssey
BEFORE attempting operation.
9
11-05
TP20094,Rev.4
7
