Summary of Contents for Mobi Technologies 70061
- Page 1 Model #70061 Additional Camera USER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION PACKAGE CONTENT FEATURES & COMPONENTS SAFETY TIPS INSTALLATION & SET UP CAMERA OPERATION & INSTALLATION POWER ON/OFF CHANNEL SELECTION VOICE ACTIVATION (VOX) AUTOMATIC INFRARED NIGIT VISION PROBLEMS & SOLUTIONS FCC REGULATION LIMITED WARRANTY... -
Page 3: Introduction
INTRODUCTION Thank you for purchasing the Additional Camera for the Mobi- Cam AV Wireless Audio/Video Monitoring System. The 900 MHz MobiCam AV, incorporates the latest in advanced technology enabling you to transmit picture and sound wirelessly. We highly recommend you read the entire Instruction Manual before use. PACKAGE CONTENTS Please note the package should include the following: 1 x Camera Unit... -
Page 4: Features & Components
MONITOR UNIT FEATURES & COMPONENTS (Monitor sold separately but shown as reference) 1. TFT LCD Display 2. Channel Indicator LEDs 3. Channel Selection Switch 4. Speaker 5. Automatic Channel Scan Indicator 6. Power On/O Indicator 7. Power On/O Switch & Volume Control 8. -
Page 5: Safety Tips
SAFETY TIPS For proper setup and use, please read all instructions Please keep this manual for future reference. • This Product is not intended to be used as a medical monitor and its use should not replace adult supervision • Periodically examine this product for damage to the cord, housing or other parts that may result in the risk of fire, electric shock or injury. - Page 6 • Always remember that you are using public airways when using your monitor. • Use only a dry cotton cloth to keep the Camera and Monitor units free of dust. Do not use a dampened cloth, water, or liquid cleaner of any kind.
-
Page 7: Installation & Set Up
INSTALLATION & SET UP Installing Batteries Your MobiCam AV can be powered by either using the supplied AC power adaptors or batteries. Using Batteries: a) Remove the battery door (12, 26) at the bottom/ back of each unit by loosening the child-safe screw (14, 25) and sliding the cover downward to release. -
Page 8: Camera Operation & Installation
CAMERA OPERTATION & INSTALLATION Power ON/OFF Use the Power ON/OFF sliding switch to turn ON/OFF the unit (see #21 on page 3). Channel Selection Press the Channel Selection Switch ( g. 17) on the Camera to choose which channel you want the unit to transmit on. The chan- nel indicator LED ( g. -
Page 9: Problems & Solutions
PROBLEMS & SOLUTIONS Problem Solution Poor reception • Battery Levels (check Led indicator: Full Power - Green; Low Power - Orange) • The camera may not be set to Camera Mode. • Wrong Channel (Please note the monitor will return to Channel A automatically after power off... -
Page 10: Fcc Regulation
FCC REGULATION These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio commu- nications. -
Page 11: Limited Warranty
LIMITED WARRANTY Mobi Technologies, Inc. warrants this product to be free from defects in material and workmanship for a period of ninety (90) days from the date of purchase. Should this product prove to be defective at any time during the warranty period, Mobi Tech- nologies, Inc.
