Manual ref-XMOB200
1 Ch HD MOBI DVR
Operation Manual
12V Micro HD DVR !
Perfect solution for covert,
mobile or temporary CCTV.
HD 1080P Recording
Easy Micro SD Card Storage
TVI & AHD 2MP Compatible
Low Voltage 12V DC
1 Ch Video & Audio
1
Version 1.01 – Last Revised 09/03/18
www.mobidvr.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mobi Technologies 1 Ch HD
Summary of Contents for Mobi Technologies 1 Ch HD
- Page 1 Manual ref-XMOB200 1 Ch HD MOBI DVR Operation Manual 12V Micro HD DVR ! Perfect solution for covert, mobile or temporary CCTV. HD 1080P Recording Easy Micro SD Card Storage TVI & AHD 2MP Compatible Low Voltage 12V DC 1 Ch Video & Audio Version 1.01 –...
- Page 2 Manual ref-XMOB200 A tiny 9x 9cm size means you can use it anywhere and the 12V DC operation means you can use it for both permanent and temporary installations that are battery powered. It’s simple to get up and running, just plug in your HD camera or video source, power it up and you’ll be recording high quality 1080P video in seconds! It even records audio from your camera or a separated connected microphone so you can get useful voice and sound recordings that add extra context to your footage.
-
Page 3: Product Description
Manual ref-XMOB200 Product description: This is a single channel 1080P SD card DVR. It works with a 1080P TVI camera or 1080P AHD camera and supports up to a 128GB micro SD card. The DVR’s working modes support power-up record and manual record. Features: 1. - Page 4 Manual ref-XMOB200 Special Features The DVR has no buttons and relies on the remote control for operation. It starts recording as soon as power is applied. When set to loop record (1, 3 or 5 mins) it records continuously and overwrites when full.
- Page 5 MOB200 1080P SINGLE CHANNEL DVR Connect to camera and monitor Connect to computer by USB After connecting DVR to a computer, you can copy recorded files from t h e DVR to computer and then play back the files. Version 1.01 – Last Revised 09/03/18 www.mobidvr.com...
-
Page 6: Remote Control
MOB200 1080P SINGLE CHANNEL DVR Remote Control Button Function Down Confirm, start/stop recording Menu Enter into menu Stop Return to last menu Play Playback mode Del. Screen Icon instructions Preview mode (Remain recording 0 as no SD card) (Remain recording time on SD card) Version 1.01 –... - Page 7 MOB200 1080P SINGLE CHANNEL DVR Recording mode (Record Time displays in Red) Video playback mode Version 1.01 – Last Revised 09/03/18 www.mobidvr.com...
- Page 8 MOB200 1080P SINGLE CHANNEL DVR Set Up (All settings will be activated after DVR reboot) Press “MENU” button in preview mode to enter into DVR menu How to select items and set it up? Press “ ” or “ ” to move up or down. Press “OK”...
- Page 9 MOB200 1080P SINGLE CHANNEL DVR 2. Time stamp Off: No time or date appears in video and it will not appear on recorded files either. Date Only: Only year/month/day info appears on video. Date & Time: Both date and time info appear on video. 3.
- Page 10 MOB200 1080P SINGLE CHANNEL DVR 5. Signal: Setup video input signal type (TVI or AHD) TVI: Works with 1080P TVI format camera AHD: Works with 2.0MP AHD format camera Note: if you use a TVI camera when DVR is in AHD mode, the video output will be corrupted. 6.
- Page 11 MOB200 1080P SINGLE CHANNEL DVR 6.2 Language (English, Chinese, French,Germany,Italian,Spanish,Portuguese,Japanese,Korean) 6.3 TV output PAL: If your camera is in PAL mode, please set DVR in PAL mode too. NTSC: If your camera is in NTSC mode, please set DVR in NTSC mode too. NOTE: if DVR mode is different to the camera mode, the video output will be problematic.
- Page 12 MOB200 1080P SINGLE CHANNEL DVR 6.5 Date Input: Press “ ” or “ ” to select, press “OK” to set and go to next item. The data will be saved after you set up the last item. 6.6 Time Input: Press “ ”...
- Page 13 MOB200 1080P SINGLE CHANNEL DVR 6.8 FW Upgrade (Will only be available if faults are encountered – currently none) Attention: Please contact your installer for information. Firmware updates will only be pursued for fault resolution. 6.9 FW Version: Check current software version 7.
- Page 14 MOB200 1080P SINGLE CHANNEL DVR 7.2 Playback on TV/Monitor Press “Play” key on remote controller when DVR is in preview mode, and then get into “Playback” mode. Press “ ” or “ ”key to choose the different files. After selecting the file, press the “OK” key to playback. During video playback, press the “OK”...
- Page 15 MOB200 1080P SINGLE CHANNEL DVR 7.4 Protect files Lock Current: Locks current file Unlock Curr. Unlocks the current locked file Lock All: Locks all files on memory card Unlock All: Unlocks all locked files on memory card Note: 1. Locked files will not be deleted when you delete files by the DVR. 2.
- Page 16 1 channel 1080P DVR operation manual 7.5 Volume function To alter volume select Volume and press “ ” or “ ” keys to adjust volume level. Volume level is 0-8 and 8 is the highest level. If you set it to 0, the audio is muted. 7.6 Setup Enter into DVR set up menu.
