DRAFT

OPERATING INSTRUCTIONS

FOR
WHEELCHAIR LIFT
MODEL NO. WL7
DOT-Public Use Lift
PATENTS PENDING
MP-04-02
REV. C
SEPTEMBER 2005
© MAXON Lift Corp. 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WL7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maxon WL7

Summary of Contents for Maxon WL7

  • Page 1: Operating Instructions

    DRAFT OPERATING INSTRUCTIONS WHEELCHAIR LIFT MODEL NO. WL7 DOT-Public Use Lift PATENTS PENDING MP-04-02 REV. C SEPTEMBER 2005 © MAXON Lift Corp. 2005...
  • Page 2 PATENTS PENDING...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..............4 SAFETY SUMMARY ............4 DAILY PRE-OPERATION & OPERATION CHECKLIST ..6 MAINTENANCE SCHEDULE ..........7 LIFT COMPONENTS & TERMINOLOGY ......8 DECALS AND DECAL PLACEMENT ......10 ANTI-SLIP & SAFETY STRIPING ........13 OPERATING INSTRUCTIONS .......... 15 ENTER VEHICLE ............

  • Page 4: Introduction

    SAFETY SUMMARY INTRODUCTION This manual contains safety information and operating instructions for the Maxon Wheelchair and Standing Occupant Lift. Read and understand the WARNINGS, 1. This Wheelchair Lift is intended for Commercial SAFETY CONSIDERATIONS, and operating instructions Use and to be operated by an Attendant. Do Not in this manual, before operating the Lift.
  • Page 5 4. Do not allow any part of your body, or the Lift 8. Always operate the Lift with the vehicle emergency occupant’s body, to be placed under, within, or brake set and vehicle parked on Level ground. Operating Lift without emergency brake set or around any portion of the moving Lift or its mecha- nisms, or in a position that would trap them be- parked on an incline may create a hazard for...

  • Page 6: Daily Pre-Operation & Operation Checklist

    DAILY PRE-OPERATION & OPERATION CHECKLIST NOTE: PRE-OPERATION and OPERATION CHECKS NOTE: If any of the PRE-OPERATION CHECKS should be performed by the Lift Operator. have incorrect indications, do not operate the Lift until repairs are performed by a PRE-OPERATION CHECKS qualified technician.

  • Page 7: Maintenance Schedule

    MAINTENANCE SCHEDULE NOTE: The Lift Controller counts the number of cycles & Check that all Decals are in place, undamaged, and lifts over the lifetime of the Lift. One CYCLE is legible (see DECALS pages). counted each time the Lift is unfolded from the Check that all anti-slip and safety striping is in place and stowed position to floor level, lowered to the ground, undamaged (see ANTI-SLIP &...

  • Page 8: Lift Components & Terminology

    LIFT COMPONENTS & TERMINOLOGY INBOARD RIGHT LEFT OUTBOARD LIFT COMPONENTS (SEE TABLE 9-1) FIG. 8-1 PATENTS PENDING...
  • Page 9 ITEM NAME DESCRIPTION ITEM NAME DESCRIPTION THRESHHOLD PLATE Component that bridges the entry way, through HYDRAULIC CYLINDER (Left/Right) Telescoping steel tube and rod, the Lift, into the vehicle. Detects if that portion of pressurized by hydraulic fluid, that folds and Lift is occupied during "UP/DOWN"...

  • Page 10: Decals And Decal Placement

    DECALS AND DECAL PLACEMENT DECAL (ALARM) DISPLAY DECAL “I” OVERLAY DECAL “C” DECAL“J” DECAL “A” DECAL “O” DECAL “G” SERIAL PLATE DECAL “K” DECAL “B” SERIAL DECAL “F” DECAL“N” PLATE DECAL “P” DECAL “L” DECAL “M” All WARNING, CAUTION, and OPERATION decals DECAL provided with Wheelchair Lift must always be in place on DECAL “D”...
  • Page 11 DECAL SET P/N 266704-01 FIG. 11-1 PATENTS PENDING...
  • Page 12 DECALS AND DECAL PLACEMENT - Continued SERIAL PLATE DECAL (ALARM) P/N 266686-01 P/N 905246-8 DECAL-OVERLAY P/N 266990-01 DECAL SET P/N 266704-01 FIG. 12-1 PATENTS PENDING...

  • Page 13: Anti-Slip & Safety Striping

    ANTI-SLIP & SAFETY STRIPING (30” WIDE PLATFORM) YELLOW TAPE (BOTTOM-ROLLSTOP) PN 905293-17 ANTI-SLIP TAPE PN 096013-10 ANTI-SLIP TAPE (TOP-ROLLSTOP) PN 096012-10 YELLOW TAPE (OUTBOARD) ANTI-SLIP PN 905293-11 TAPE (ROLLSTOP) PN 096015-10 YELLOW TAPE (OUTBOARD) ANTI-SLIP PN 905293-14 TAPE YELLOW TAPE PN 096014-10 YELLOW TAPE (THRESHOLD PLATE)
  • Page 14 ANTI-SLIP & SAFETY STRIPING - Continued (33” WIDE PLATFORM) YELLOW TAPE (BOTTOM-ROLLSTOP) PN 905293-18 ANTI-SLIP TAPE PN 096013-11 ANTI-SLIP TAPE (TOP-ROLLSTOP) PN 096012-11 YELLOW TAPE ANTI-SLIP TAPE (OUTBOARD) (ROLLSTOP) PN 905293-11 PN 096015-11 YELLOW TAPE (OUTBOARD) ANTI-SLIP TAPE PN 905293-14 PN 096014-11 YELLOW TAPE YELLOW TAPE...

  • Page 15: Operating Instructions

    OPERATING INSTRUCTIONS ENTER VEHICLE FOLD 3. Push the UNFOLD switch on NOTE: If equipped, Seat Belt must be fastened for Lift HAND CONTROL (FIG. 15-2) to operate. to unfold PLATFORM to horizontal position 1. Fully open and secure UNFOLD (FIG. 15-3). Wheelchair Lift access door(s) on the vehicle.
  • Page 16 OPERATING INSTRUCTIONS - Continued 4. Push the DOWN switch on 6. Position wheelchair or HAND CONTROL (FIG. 14-1) ambulatory occupant on to lower PLATFORM to the center of PLATFORM ground level (FIG. 16-1). (FIG. 16-3). SET WHEELCHAIR BRAKES or SWITCH OFF POW- ERED WHEELCHAIR.

  • Page 17: Exit Vehicle

    EXIT VEHICLE 8. Push the UP switch on HAND FOLD 1. Fully open and secure Wheel- CONTROL (FIG. 17-1) to chair Lift access door(s) on the raise PLATFORM to vehicle vehicle. floor level (FIG. 17--2). UNFOLD 2. Push the UNFOLD switch on HAND CONTROL (FIG.
  • Page 18 OPERATING INSTRUCTIONS - Continued 4. Position wheelchair or 6. If equipped, unfasten SEAT ambulatory occupant on BELT (FIG. 18-3) and place the center of platform on hanger provided. (FIG. 18-1). SET WHEELCHAIR BRAKES OR SWITCH UNFASTENING SEAT BELT OFF POWERED FIG.

  • Page 19: Stow Lift From Vehicle Floor

    STOW LIFT FROM VEHICLE FLOOR STOW LIFT FROM GROUND LEVEL 1. If equipped, fasten SEAT FOLD BELT allowing 3” - 4” of slack (FIG. 19-3). UNFOLD 2. Push the UP switch on HAND CONTROL (FIG. FASTENING SEAT BELT DOWN 19-1) to raise PLATFORM to FIG.
  • Page 20 THIS PAGE INTENTIONALLY LEFT BLANK PATENTS PENDING...

  • Page 21: Manual Pump Operation

    OPERATING INSTRUCTIONS - Continued MANUAL PUMP OPERATION LOADING & UNLOADING OCCUPANT NOTE: If possible, keep the Lift power ON/OFF switch 1. Reposition latches to manually unfold the Lift as turned ON. In most cases, operating the Lift with follows. Raise latch off anchor pin (FIG. 21-2B) on LH Manual Pump may be easier if power is ON.
  • Page 22 OPERATING INSTRUCTIONS - Continued MANUAL PUMP OPERATION - Continued 2. Remove the MANUAL 4. Observe the PLATFORM BACKUP HANDLE from unfolding to horizontal clips on the Pump Cover position at vehicle floor (FIG. 22-1). level (FIG. 22-3). PUMP COVER UNFOLD PLATFORM HANDLE FIG.

  • Page 23: Set Wheelchair

    6. Ensure OUTBOARD OUTBOARD NOTE: If there are no occupants to unload ROLLSTOP is raised up all ROLLSTOP from vehicle, skip step 8. the way (FIG. 23-1). 8. Position wheelchair or ambulatory occupant on the center of Platform (FIG. 23-3). SET WHEELCHAIR BRAKES OR SWITCH OUTBOARD ROLLSTOP...

  • Page 24: To Ground

    OPERATING INSTRUCTIONS - Continued MANUAL PUMP OPERATION - Continued NOTE: If the Inboard Rollstop 12. When PLATFORM rests on the CLOSER automatically rises ground, close pressure release all the way, skip step valve on Manual Pump by 10. Do not unpin the turning MANUAL BACKUP Actuator HANDLE clockwise until tight...

  • Page 25: Release Wheelchair Brakes Or Switch On Powered Wheelchair

    OUTBOARD NOTE: If there are no occupants to load on 14. Ensure OUTBOARD ROLLSTOP Platform, skip step 16. ROLLSTOP on Lift PLATFORM is opened to 16. Position wheelchair or the horizontal position ambulatory occupant on (FIG. 25-1). the center of Platform (FIG.
  • Page 26 MANUAL PUMP OPERATION - Continued 18. Raise the PLATFORM as CAUTION follows. Insert MANUAL Prevent the MANUAL BACKUP HANDLE from BACKUP HANDLE in Manual Pump actuator. getting damaged. Before you start pumping with Pump the handle up and the HANDLE, line up notches on tip of HANDLE as down (FIG.
  • Page 27 20. Manually LOWER the PIN ACTUATOR AT CAUTION STANDARD NEAREST HOLE INBOARD ROLLSTOP POSITION to THRESHHOLD To prevent damage to Lift and vehicle, Inboard PLATE (FIG. 27-2). Rollstop must be lowered on the Threshhold Plate Then pin ACTUATOR INBOARD before stowing the Lift. If the Inboard Rollstop ROLLSTOP to nearest hole on does not automatically lower, it must be lowered...
  • Page 28 MANUAL PUMP OPERATION - Continued CAUTION 23. Store MANUAL BACKUP HANDLE on Pump Cover To prevent damage to Lift and vehicle, after Lift (FIG. 28-3) using the clips is restored to correct operation, pin the Inboard provided. PUMP Rollstop in STANDARD position (FIG. 27-2). COVER 22.
