Lightolier ProSpec 26690 Specification

Page 1 of 1
A
3 3/8
[85.7]
2
1 3/16
[30.9]
1
Ordering Information
Catalog No. Finish
26890WH
Matte White
26890BK Matte Black
Features
1. ProSpec Track Strip: Structural aluminum extrusion; average wall
thickness 0.08". Adjustable to ensure that the track is always flush with
the ceiling.
2. Canopy: Steel low-profile (.12") canopy to accommodate ceiling
imperfections.
3. Insulated Liner: 0.040 wall high temperature extruded thermoplastic.
4. Conductors: "U" shaped copper conductor; increases contact surface and
minimizes contact resistance; provides reliable positive connection.
5. Mounting Brackets: 18 ga. galvanized steel. Adjustable to accommodate
1/2" to 3/4" ceiling thicknesses.
6. Knockouts: Allows power feed from above using 3/8" or 1/2" (trade size)
connector (by others).
Finish
All painted finishes are baked enamel.
Electrical
(2) circuits. Each circuit is 120V, 60 Hz. Each circuit has dedicated neutral for
maximum control flexibility. Track is continuously grounded throughout. Electrical
conductors are concealed in an insulated liner in the track. Intended for wiring
to branch circuit building wire with ground, in accordance with national and
local codes.
ProSpec
6
A
5
10 1/8
[257.4]
SECTION A-A
3 1/2
[88.7]
9
[228.6]
7 1/8
[180.3]
Mounting
Compatible with drywall or T-Bar ceiling types.
Accommodates ceiling thicknesses of 1/2" to 3/4".
Labels
cULus
Lightolier
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2005 Genlyte Group LLC • 0505
Track Lighting System
®
4 3/8
[110.3]
5 9/16
[141.6]
3 5/16
[83.8]
Compatibility
ProSpec track luminaires, 500W Max. NOT FOR USE
with ProSpec PAR56 or PAR64 track mounted units.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
a Genlyte company
26690
ProSpec Recessed Monopoint
®
Type:
www.lightolier.com
