Philips ProSpec 37240 Specification

Page 1 of 2
17/32 in
[13 mm]
1 1/8 in
[29 mm]
6 5/16 in
[160 mm]
4 19/32 in
[117 mm]
5 3/32 in
[129 mm]
Cat. No. Finish
37240WH Matte White/Metalized Louver
37240BK Matte Black/Metalized Louver
Features
1. Attachment Fitting: Molded polycarbonate, pin rotates fitting to engage
into track to energize fixture.
2. Reflector: Specular Plus® finish.*
3. Body Housing: One-piece die-cast aluminum.
4. Pivot Tension Mount: 0° - 90° Vertical rotation from NADIR in both
directions; (0° - 78° from NADIR when used with Recessed Track).
5. (2) Track Adaptor Housing: Die-cast aluminum.
6. Aiming Lock: Locks vertical position at the desired aiming angle.
7. Lamp Socket: High temperature thermoplastic.
8. Louver with Parabolic Blades: Snaps inside fixtures body. Molded ABS,
semi-specular finish or integral white blades.
9. Lamp Support Clip (2): High temperature thermoplastic.
10. (2) 40W Twin Tube: Compact fluorescent lamp (by others).
11. Ballast: Electronic.
12. Locking Knob: Mechanically locks fixture to the track, independently from
the electrical connection.
13. Lever: Energizes fixture.
Electrical
Electronic Ballast Instant Start
Input Voltage: 277V
Power Factor: >0.95
Input Power: 67W (2 lamps)
Max Input Current: 0.27A @ 277V
Lightolier is a Philips group brand
13
5
6
Mounting
ProSpec 277V
Track System Only.
Ballast Factor: 0.88
Total Harmonic Distortion: <20%
Crest Factor: <1.7
Do Not Use On Dimming Circuit
ProSpec 277V Track Lighting
®
14 3/32 in
[358 mm]
12
11
24 13/16 in
[630 mm]
Ballast Input Watts Amps
Electronic 67W .27AMP
Finish
All painted finishes are baked enamel.
Labels
UL, I.B.E.W.
* Specular Plus is a registered trademark of MSC Laminates & Composites Inc.
®
Advent is a registered trademark of Lightolier.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • A1108
Lyteflood L40 Compact Fluorescent
®
1
4
3
2
8
10
Lamp
FT 40W/2G11
Type:
37240
7
