Product dimensions
127 110
A
C
1xTL'D 18W
1xTL'D 36W
1xTL'D 58W
TCW097
1xTL'5 14W
1xTL'5 28W
1xTL'5 35W
A
660
1270
1570
B
100
100
100
C
676
1276
1586
D
417
880
590
Measurements in mm
Ordering data
Lamp
For TL'D Lamps
TCW097 1XTL-D18W HFE
1 x TL'D 18W
TCW097 1XTL-D18W I
1 x TL'D 18W
TCW097 1XTL-D18W IC
1 x TL'D 18W
TCW097 1XTL-D36W HFE
1 x TL'D 36W
TCW097 1XTL-D36W I
1 x TL'D 36W
TCW097 1XTL-D36W IC
1 x TL'D 36W
TCW097 1XTL-D58W HFE
1 x TL'D 58W
TCW097 1XTL-D58W I
1 x TL'D 58W
TCW097 1XTL-D58W IC
1 x TL'D 58W
TCW097 2XTL-D18W HFE
2 x TL'D 18W
TCW097 2XTL-D18W I
2 x TL'D 18W
TCW097 2XTL-D18W IC
2 x TL'D 18W
TCW097 2XTL-D36W HFE
2 x TL'D 36W
TCW097 2XTL-D36W I
2 x TL'D 36W
TCW097 2XTL-D36W IC
2 x TL'D 36W
TCW097 2XTL-D58W HFE
2 x TL'D 58W
TCW097 2xTL-D58W I
2 x TL'D 58W
TCW097 2XTL-D58W IC
2 x TL'D 58W
For TL'5 Lamps
TCW097 1XTL5-14W HFA
1 x TL'5 14W
TCW097 1XTL5-28W HFA
1 x TL'5 28W
TCW097 1XTL5-35W HFA
1 x TL'5 35W
TCW097 2XTL5-14W HFA
2 x TL'5 14W
TCW097 2XTL5-28W HFA
2 x TL'5 28W
TCW097 2XTL5-35W HFA
2 x TL'5 35W
Note I = electromagnetic ballast I C = electromagnetic ballast + capacitor HFE = electronic ballast (EB -S) for TL'D lamps HFA = electronic ballast for TL'5 lamps
Standard products with electromagnetic ballast are for 220V 50Hz system (Specification subject to change without prior notice)
32 1-B27 3 002-01
www.ligh tin g.p h ilip s .c o m/ apr
© Koninklijke Philips Electronics N.V. 2003
All rights reserved, reproduction in whole or in part without permission is prohibited.
B
D
D
2xTL'D 18W
2xTL'D 36W
2xTL'D 58W
TCW097
2xTL'5 14W
2xTL'5 28W
2xTL'5 35W
A
660
1270
1570
B
150
150
150
C
676
1276
1586
D
417
880
590
Gross
Packing
Quantity
Ordering number
weight (kg)
dimensions (
)
per box
mm
2
1
9104 019 83680
664 x 108 x 99
2.1
664 x 108 x 99
1
9104 019 83880
2.1
664 x 108 x 99
1
9104 019 84080
2.8
1
9104 019 84680
1274 x 108 x 99
2.9
1274 x 108 x 99
1
9104 019 84880
2.9
1274 x 108 x 99
1
9104 033 20080
4.8
1574 x 108 x 99
1
9104 033 20280
4.9
1574 x 108 x 99
1
9104 033 20480
9104 033 20680
4.9
1574 x 108 x 99
1
2.4
664 x 158 x 99
1
9104 033 21080
2.6
664 x 158 x 99
1
9104 033 21280
2.6
1
9104 033 21480
664 x 158 x 99
4.6
1274 x 158 x 99
1
9104 033 22080
4.8
1274 x 158 x 99
1
9104 033 22380
4.8
1
9104 033 22480
1274 x 158 x 99
6
1574 x 158 x 99
1
9104 033 22680
6.2
1574 x 158 x 99
1
9104 033 22880
6.2
1
9104 033 23080
1574 x 158 x 99
2
664 x 108 x 99
1
9104 019 83480
2.8
1
9104 019 84280
1274 x 108 x 99
4.8
1574 x 108 x 99
1
9104 019 84480
2.4
664 x 158 x 99
1
9104 033 20880
4.6
1274 x 158 x 99
1
9104 033 21680
6
1574 x 158 x 99
1
9104 033 21880
TCW097 Pacific II
Excellent water and dust protection
Impact-resistant
Optimum light distribution and performance
Easy installation and maintenance
