Philips Lytespan 24MHT4RNF Specification

Page 1 of 2
Ordering Information
Catalog No. Finish
24MHT4RNF Anodized
24MHT4RNFCCZ
Champagne Bronze
24MHT4RFWRM Incandescent Warm
Features
1. Narrow Flood Reflector: Aluminum, faceted, specular, anodized
and sealed.
Finish
Specular Anodized and Sealed.
Labels
UL, cUL
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • C0510
Lytespan Track Lighting System
®
Mini HID T4 GU6.5, BT PGJ5 Narrow Flood Reflector
3 5/32 in
[ 80.0 mm]
17/32 in
[ 13.6 mm]
Lamps For Use With Luminaires
T4 GU6.5, BT PGJ5 8109 & 8111
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
24MHT4RNF
1 9/16 in
[39.9 mm]
2 11/16 in
[68.6 mm]
Type:
