Lightolier FS03 Specification

Page 1 of 2
"
2 3/8
"
1 5/8
17 1/8"
7 5/16"
Order Information:
Spec ID Powerhead
FS03 PS13SA
FS203 PS132SA
PS13QSA
FS03Q
FS203Q PS132QSA
IS03 PS50SA
Must Order Powerhead and Glass separately. Suspension Kit must be ordered separately. Spec ID is for reference only.
Suspension
Cat. No Finish
SK01 Satin Aluminum
SK02 Satin Aluminum
ST01
Satin Aluminum
ST02 Satin Aluminum
CTC Satin Aluminum
TM01 Satin Aluminum
Features
1. Power Compartment: Die Cast and Machined
Aluminum Components. Brushed and Clear Lacquer Finish.
2. Primary Glass: Triplex Hand Blown Glass.
3. Decorative Glass Casing: A Conical Section of Frosted Hand Blown Glass,
Die Cast Aluminum Holder Ring and Stainless Steel Support Pins.
Lamping (by others)
Incandescent: 50W Max. T-4 Mini Can
Compact Fluorescent:
General Electric Osram/Sylvania
(1) 13W Twin Tube 4-Pin Compact Fluorescent Lamp
N/A CF13DS/E/*
(1) 13W Quad Tube 4-Pin Compact Fluorescent Lamp
F13DBX/*/EC04P CF13DD/E/*
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0309
3/8"
7 5/16"
Inner Glass Outer Glass
SG01 GLS02
SG01 GLS02
SG01 GLS02
SG01 GLS02
SG01 GLS02
Description
Clear Metallic Straight Cord/cable, 120" Length, (10') with canopy
Clear Metallic Straight Cord/cable, 300" Length, (25') with canopy
36" Length 3/8" Stem with canopy
60" Length 3/8" Stem with canopy
Close To Ceiling Kit with canopy
Silver Track Mounting Kit with Clear Metallic Straight Cord/Cable, 120" Length, (10') (120V only)
Philips
N/A
PL-C13W/*/4P/ALTO
Architectural Decorative
4 5/8" 4 5/8"
Swivel Joint
3"
3/8" Steel Tubing
Close to Ceiling
Stem
1 1/2"
4 5/8"
3/8"
Cable/Cord Track Mount
Suspension Kit Lamp
4-Pin elect. Twin Tube 13W
*See suspensions below
4-Pin elect. Twin Tube 13W
4-Pin Quad Tube 13W
4-Pin Quad Tube 13W
T-4 Mini-Can 50W
Electrical
Lampholders: Incandescent E11 Base, Porcelain, Plated Copper
Alloy Screw Shell
Compact Fluorescent: 13W Twin: 2GX7 Base, High Impact Thermoset Polymer
with Brass Contacts.
13W Quad: G24Q-1 Base, High Impact Thermoset Polymer with Brass Contacts.
Ballasts: Fluorescent: Electronic
Voltage
Max. Watts
Max. Line Current (Amps)
Labels
cULus Listed. Suitable for Damp Locations.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
FS03
Vetro Pendant
3/8"
3 3/4"
Volts
120V
277V
120V
277V
120V
13 Watts TT 13 Watts QT
120 277 120
16 11 20
0.136 0.08 0.174
Type:
277
14
0.114
