Lightolier SL202B Specification

Page 1 of 2
3 1/2"
(89 mm)
Ordering Guide (complete unit only)
Cat. No. Lamp (circular)
SL202BF4U 4-18W QT
SL202BQDU
4-18W QT
Features
1. Form: Round form fabricated from slitted corrugated anodized aluminum.
Slits hold the sand blasted glass and reflector element. The illuminated edge
of the glass is visible through the corrugations.
2. Glass: Center sand blasted glass with clear outer ring. Image of lamps seen
through the glass to create a geometric pattern on the wall or ceiling.
3. Housing: Spun painted steel construction. Mounting plate houses the bal-
last and lamp sockets.
Mounting
Mounting: Surface mounting to wall or ceiling surfaces.
Lamp Change: Fluted housing simply twists-off. Held in place by 3 locking pins.
Luminaire Weight: 10.5 lbs.
Electrical
Ballast: Electronic T4 quad lamp ballasts. Universal voltage "U" ballast auto-
matically detect 120 volts or 277 volts operation.
F4: Programmed Rapid Start by Universal
QD: High-Performance dimming by Lightolier-Controls
Lampholder: G24q-2 base, 4 Pin.
Spectral Architectural Lighting
18 1/4"
(464mm)
Volt Finish
120/277V Anodized Aluminum & Sand Blasted Glass
120/277V Anodized Aluminum & Sand Blasted Glass

Options and Accessories

DS: Double switching.
Consult your Lightolier representative for more information.
Perforated form: Consult your Lightolier representative for more information.
Finish
Anodized corrugated aluminum sheet with precise flutes.
All painted parts are with powder coat paint process.
Labels
UL "c/us" Listed. Suitable for damp locations.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2005 Genlyte Group LLC • B0605
Fluted Disk Fluted Forms 4-18W Quad Tube
Type:
a Genlyte company
SL202B
www.lightolier.com
