Lightolier Lytecaster 1920LV Specification

Page 1 of 1
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Conversion Kit
1920LV

Features

1. Transformer Housing: 0.036" (#20 ga.) steel. Matte black finish.
2. Transformer: Magnetic, 120V primary, nominal 12V secondary.
3. Socket: Field replacable. Two-pin socket, pre-wired with #18 SF1 leads.
4. Socket Adaptor: Medium base; nickel-plated screw shell. Pre-wired with
#18 ga. SF1 leads. Screws into previously installed Lytecaster
Frame-in Kits to energize conversion kit.
5. Socket Housing: 0.036" (#20 ga.) galvanized steel.

Dimming Information

Dimming Controls: use only dimmers specifically designed for use with magnetic
transformers, like Lightolier Onset
Lightolier Controls dimming system. Low voltage fixtures may produce audible
sound when used with dimmers, which may be objectionable in acoustically criti-
cal areas.
Lightolier is a Philips group brand
4
Compatible Incandescent
Frame-in Kits
1002P1 1000IC
1003R 1000AICM
or Sunrise series LV or VA dimmers, or any
® ®
Lytecaster Recessed Downlighting
®
5" Aperture MR16 Low Voltage Conversion Kit
Compatible Reflector Trims —
See Individual Reflector Trim Specification Sheets
Step Baffle Aperture Cone
1055LV 1063LV 1064WDLV
1055WHLV 1064LV 1064WDPLV
Options & Accessories
MR16 Replacement Socket:

Labels

UL (Suitable for Damp Locations), I.B.E.W.
® incandescent
Lytecaster is a registered trademark of Lightolier.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • D1108
1
2
5
3
Adjustable
Pinhole Elbow
1052LV 1062LV
1975A
Type:
1920LV
