IS_LSCW
Lighting Systems
Page 1 of 3
Instruction Sheet for Assembly and Installation of Lytespread Curve Wall Mount
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE PROCEEDING.
RETAIN THESE INSTRUCTIONS FOR MAINTENANCE REFERENCE.
To assure full compliance with local codes and regulations, check with your local electrical inspector before
installation. To prevent electrical shock, turn off electricity at electrical panel before proceeding.
DO NOT INSTALL THIS SYSTEM IN A WET OR DAMP LOCATION.
DO NOT ENERGIZE ANYTHING OTHER THAN THE FIXTURES IN THE SYSTEM.
DO NOT EXCEED MAXIMUM WEIGHT LOADING.
CONTRACTOR IS RESPONSIBLE FOR ADEQUATELY REINFORCING WALL TO SUPPORT FIXTURE WEIGHT.
1/2"
3 5/16"
2 5/8"
7 7/8"
10 1/2"
We reserve the right to change details of design, materials and finish.
C0110
