Philips Lytespan 6289 Specification

Page 1 of 2
Ordering Information
Catalog No. Finishes
6289 WH Matte White
6289 BK Matte Black
6289 AL Metallic Aluminum
Features
1. Ring: Die-cast aluminum with cool grip insulation band, a high temperature
silicone rubber which allows aiming adjustments while fixture is on.
2. Socket Boot: Electrical spade connectors with individual insulating rubber
silicone covers; 18 ga. stranded Teflon leads with fiberglass outer sleeve.
3. Transformer: Electronic low voltage transformer with integral radio
frequency interference filter and anti-crossover circuit for increased
reliability; housed in extruded aluminum.
4. Track Attachment Fitting: Molded polycarbonate, rotates into track and
locks on with push tab; integral polarity key guard.
5. Push Tab: Locks and detaches unit from track.
6. Brass Contacts: Extends for connection to second circuit in Advent
Lytespan track.
7. Tension Pivot Mounts: Die-cast aluminum. Allows for 180° horizontal
rotation and 180° vertical rotation.
8. Lamp Guard: Molded pressed glass.
9. Spring: Steel springs hold lamp in place.
10. Housing: Aluminum, fully encloses lamp back and terminals. Vents dissipate
lamp heat.
Lightolier is a Philips group brand
Track Mountings Lamps
All Lytespan AR111, 75W Max.
Track Systems 50W Max. with Accessories
®
Lytespan
Sof-Tech Low Voltage, Enclosed Spot, AR111
®
Options & Accessories
Accessory Holder 7660
AF3 Series Lenses
AL3HC Louver
Electrical/Dimming
Dimming controls: Use only dimmers specifically designed for use with electronic
transformers, like Lightolier Sunrise™ and Neptune Momentum QE™ series. Low
voltage fixtures may produce audible sound when used with dimmers, which
may be objectionable in acoustically critical areas.
Labels
UL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • B0508
6289
Track Lighting
®
Type:
