Philips 405X Specification

Page 1 of 2
4 1/2"
Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately
Reflector Trim
405BKX Black Step Baffle and White Flange
405WHX White Step Baffle and White Flange
Features
1. Flange Housing: Cold rolled steel 22ga. White trim flange.
2. Elbow Housing: Die-cast aluminum with stepped conical surface for low
brightness
3. Mounting Clips (3): 24ga. spring steel, zinc plated. Provide easy snap-in /
snap-out action.
4. Lamp Guard: 2" (51mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications, see 400 frame specifica-
tion sheets.
Accessories
Square Face Plate
400SQWH White
400SQBK Black
Lightolier is a Philips group brand
1/8"
Lytecaster Recessed Downlighting
4 3/4" Aperture Adjustable Premium Die-Cast Step Baffle
3 3/4"
5 1/4"
Frame-In Kit
Remodeler 400MRX
Remodeler 3401MREX
Non-IC 402MRX
Non-IC 402MREX
IC 402MRIC9X
Non-IC 602MR
Non-IC 603MR
Non-IC 604MR
Non-IC 604QMR
Labels
CSA, UL (Suitable for damp locations.)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • D1008
405X
1"MAX
Lamp
75W MR16
50W MR16
75W MR16
75W MR16
50W MR16
75W MR16
75W MR16
75W MR16
75W MR16
Type:
