Lightolier Lytespan 83PC Specification

Page 1 of 1
1-5/8" Sq. Uni-Strut
1" Min. Diameter
1-3/4" Max. Diameter
Ordering Information
Catalog No. Finish
83PCWH Matte White
83PCBK
Matte Black
Features
1. Body: Extruded aluminum profile.
2. Thumb Screw: Easy to adjust for toolless clamp positioning.
3. Luminaire Mounting Slot: Integral slot accepts PowerArc
naires.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • D0410
Lytespan
2.9"
(74mm)
3.4"
(86mm)
2
Mounting
1" to 1 3/4" Diameter,
round or square supports
Finish
All painted finishes are baked enamel.
Labels
Modular lumi-
™
UL, cUL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Track Lighting System
®
PowerArc
3
Compatibility
PowerArc Modular Track Luminaires:
™
8313WH, BK, AL
8314WH, BK, AL
8316WH, BK, AL
83W4WH, BK, AL
83W6WH, BK, AL
83W7WH, BK, AL
Type:
83PC
Modular Pipe Clamp
™
1
