  • Page 1 WIRELESS IMAGER Reference Manual International Edition, Rev. B5...

  • Page 2: Revision History

    Revision History Rev. No. Description Rev. A Oct 16, 2009 First Release Page 6 Revise “Clone Function” operation method. Rev. A1 Oct 22, 2009 Page 68 Add “Save Configuration” and “Master Default” to System Commands. Page 53 “Bluetooth Device Name” – Modify user define characters from 1 – 14 characters to 1 –...
  • Page 3 Revision History Rev. No. Description Page 48 Remove ”Scan Voting” and add “Scan Rate Control ” Rev. A6 Sep 20, 2010 Page 54 Add “ ” parameter selection in Batch Data Quantity Output Format. Rev. A7 Nov 10, 2010 Page 44 Baud Rate –...
  • Page 4 Revision History Rev. No. Description Page 3, 5, 10 “Paging/ Reset button” is changed from 3 seconds to 5 seconds. Rev. B3 Nov 04, 2011 Page 24 Add a new function “Codabar Check Digit Settings” Page 49 Cancel 1 parameter of “Code 39/Code 128 Emulation”.(Disable standard code 39 emulation - -0) Page 49 Change of default setting to Enable standard code 39 skip emulation in “Code...
  • Page 5 © Copyright PC Worth Int’l Co., Ltd Cino makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranty of merchantability and fitness for any particular purpose. Cino shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance, or use of this publication.
  • Page 6 MIC T401 LED Eye Safety IEC62471 Exempt group Laser Eye Safety IEC60825-1 Class 1...

  • Page 7: Table Of Contents

    Getting Started Getting Familiar with Your FuzzyScan Preparation before Using Decide Your Radio Link Mode Using FuzzyScan in PAIR Mode Using FuzzyScan in PICO Mode Using FuzzyScan in HID Mode Using FuzzyScan in SPP Mode Out-of-range Scanning/Presentation Scanning/Paging Function Batch Scanning (Inventory Mode) Configure Your FuzzyScan Bar Code Programming Manual Programming Procedures...
  • Page 8 Getting Started Thank you for choosing Cino FuzzyScan Bluetooth Cordless Image Scanner. Powered by the combination of cutting-edge FuzzyScan 2.0 Imaging Technology and Bluetooth 2.1 EDR wireless technology, it not only provides outstanding reading performance, but also delivers the convenience and freedom of mobility. This document provides a quick reference for...
  • Page 9 Getting Started Ensure the battery contacts of the battery pack are facing the charging contacts inside the battery cavity. Slide the battery pack into the battery cavity until hearing a click sound before locking it with the end cap. The scanner will give 4 beeps when the battery pack is installed properly if the battery pack still has power.
  • Page 10 Getting Started The FuzzyScan Bluetooth image scanner provides several radio link modes to communicate with most host devices. When the Bluetooth-enabled host device is not available, it can work with the smart cradle in PAIR mode (one to one connection) or PICO mode (multiple connections) to provide a plug-and-play cordless migration of your existing non-Bluetooth-enabled IT assets.

  • Page 11: Preparation Before Using

    The default host interface of smart cradle is preset to USB HID. If you want to set the host interface to USB COM, you have to install the USB virtual COM driver into your host device before using the scanner. Please visit the CINO website to download...
  • Page 12 Getting Started Ensure the battery is fully charged and choose your desired interface cable, then plug it into the host interface port of the smart cradle and connect it to the host device. Turn on the power of your host device. Ensure the side indicators of the smart cradle give alternative red and green blinks (in “Uninstall”...
  • Page 13 Getting Started For the user’s convenience, the clone function will help you to clone the host interface related parameters (please refer to following table for details) from one of the paired scanners to the rest of paired scanners under PICO mode. You can use one of the paired scanners to set the host interface related parameters first and then scan “Save Configuration”...
  • Page 14 FxxxBT-xxxx’’ is shown in the list if the scanner is successfully discovered already. Double click the “CINO FxxxBT-xxxx” in the discovered Bluetooth device list. If the PIN Code or Passkey is requested for security connection, please enter “00000000” (default setting). You will see “Keyboard on CINO FxxxBT-xxxx”, and double click this HID service to establish the connection between the scanner and the remote host device.
  • Page 15 Getting Started Ensure the battery is fully charged. Please go to the folder of “Hardware” located in Bluetooth Advanced Setting of the remote host device to check its device MAC address. Then prepare a 12-character Code 128 barcode of the remote host device MAC address, or follow the step 4 to input MAC address by scanning 12 option codes.
  • Page 16 ‘’CINO FxxxBT-xxxx’’ is shown in the list if the scanner is successfully discovered already. Double click the “CINO FxxxBT-xxxx” on the discovered Bluetooth devices. If the PIN Code or Passkey is requested for security connection, please enter “00000000” (default setting). You will see “Serial Port on CINO FxxxBT-xxxx”, and double click this SPP service to establish the connection between the scanner and the remote host device.
  • Page 17 Getting Started When the radio is connected between the scanner and the remote host device, the scanner will transmit each scanned data right after scanning the barcode. However, the scanner is preset for unable to scan any barcode data when it loses the radio connection with the remote host device.
  • Page 18 Getting Started Thanks to the specially designed Batch Scanning function, the scanner is capable of storing the barcode data up to 20,000 EAN-13 labels. It is an ideal cost-saving solution for inventory applications. Once you scan the “Enter Batch Scanning” command to activate this function, all scanned barcode data will be stored into the memory storage, and the status indicator of scanner will give green blink at regular interval during batch scanning.
  • Page 19 Getting Started Auto Delete Stored Data Keep Stored Data after after Transmission Transmission ◆ ◆ ◆ ◆ If you scanned a wrong barcode, the “Delete Last Scanned Data’’ command is helpful to recover mistake. By scanning the ‘’Delete Last Scanned Data’’ command, the last stored data can be deleted. Delete Last Scanned Data If you want to input the quantity information of barcode data, you can enter the quantity from 1 to 9999 by scanning the quantity barcodes right after you scanned the barcode data.
  • Page 20 Configure Your FuzzyScan The FuzzyScan bar code commands are specially designed System Command System Command System Command System Command Proprietary bar code labels which allow you to set the The System Command is the highest level bar code FuzzyScan internal programming parameters. There are command which directs FuzzyScan to perform immediate System Command, Family Code and Option Code for operations,...

  • Page 21: Programming Procedures

    Configure Your FuzzyScan If the programming family must take multiple scans Programming Procedures Programming Procedures Programming Procedures Programming Procedures selection, cycling scan selection, or dual level selection As you scan the bar code command to select the desired procedures, the family of the programming menu will be parameters, information about the final selected parameters marked with...
  • Page 22 Configure Your FuzzyScan Program & End Program & End Program & End Program & End System List, Group & Master Default System List, Group & Master Default System List, Group & Master Default System List, Group & Master Default Scan Scan “SYSLIST”...
  • Page 23 Configure Your FuzzyScan Single scan selection Single scan selection Single scan selection Single scan selection Multiple scans selection Multiple scans selection Multiple scans selection Multiple scans selection Scan Scan “PROGRAM” Enter programming mode. “PROGRAM” Enter programming mode. Select one of desired Select one of desired Scan Scan...
  • Page 24 Configure Your FuzzyScan Cycling scan selection Cycling scan selection Cycling scan selection Cycling scan selection Dual level selection Dual level selection Dual level selection Dual level selection Scan Scan “PROGRAM” Enter programming mode. “PROGRAM” Enter programming mode. Select one of desired Select one of desired Scan Scan...
  • Page 25 Configure Your FuzzyScan Family Code Selection Parameter Selection Option Code...
  • Page 26 Configure Your FuzzyScan ♦ ♦ ♦ ♦ User Defined Symbol ID ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code 2nd Option Code...
  • Page 27 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Symbology ID Transmission ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 28 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Readable Bar Code Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 29 Configure Your FuzzyScan Code 39/Code 32 Setting ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 30 Configure Your FuzzyScan Code 39 Setting ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 31 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Codabar/NW-7 Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 32 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Codabar/NW-7 Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 33 Configure Your FuzzyScan ♦ ♦ ♦ ♦ UPC-A & UPC-E Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code UPC-A UPC-E EAN-13 EAN-8...
  • Page 34 Configure Your FuzzyScan ♦ ♦ ♦ ♦ UPC-A & UPC-E Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code ...
  • Page 35 Configure Your FuzzyScan ♦ ♦ ♦ ♦ EAN Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code ...
  • Page 36 Configure Your FuzzyScan ♦ ♦ ♦ ♦ EAN Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 37 Configure Your FuzzyScan ♦ ♦ ♦ ♦ UCC Coupon Extended Code Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 38 Configure Your FuzzyScan ♦ ♦ ♦ ♦ IATA & Interleaved 2 of 5 Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 39 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Code 25 Family Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 40 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Code 11 & Code 93 Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 41 Configure Your FuzzyScan ♦ ♦ ♦ ♦ MSI/Plessey Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 42 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Code 128 & UCC/EAN 128 Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 43 Configure Your FuzzyScan ♦ ♦ ♦ ♦ UK/Plessey Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 44 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Telepen Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 45 Configure Your FuzzyScan ♦ ♦ ♦ ♦ GS1 DataBar Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 46 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Linear-stacked & Korea Post Code Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 47 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Keyboard Layout (Language) Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 48 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Record Suffix, Preamble, Postamble & Caps Lock ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 49 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Delay Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 50 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Emulation Setting & Upper/Lower Case Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 51 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Record Suffix, Preamble ,Postamble Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 52 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Delay Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 53 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Protocol, ACK/NAK Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 54 Configure Your FuzzyScan...
  • Page 55 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Time Out Setting, Baud Rate, Data Frame ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 56 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Code 39/Code 128 Emulation ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 57 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Operation Mode ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 58 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Buzzer, Indicator, Vibrator, Inverse Reading ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 59 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Dollar Sign Control, Redundancy, Scan Rate Control ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code ￥ ...
  • Page 60 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Delay Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 61 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Time-out Setting, Good Read Duration ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 62 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Presentation Scanning Setting, Laser Aiming Control ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code ◆...
  • Page 63 Configure Your FuzzyScan ♦ ♦ ♦ ♦ 1D Barcode Direction Indication Transmission, etc. ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code ◆ 〔 〔 〔 〔 〕 〕 〕 〕 ◆ 〔 〔 〔 〔 〕 〕 〕 〕...
  • Page 64 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Out-of-range Scanning, Sleep Time-out Control ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 65 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Batch Scanning Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 66 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Batch Scanning Data Transmission Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code ， – ．...
  • Page 67 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Bluetooth Device Name & Security Setting♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 68 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Bluetooth Other Settings ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 69 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Preamble, Postamble, Data Length & Symbol ID Trans. ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code...
  • Page 70 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Data Formatter Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code 2nd Option Code...
  • Page 71 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Data Verifier Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code 2nd Option Code...
  • Page 72 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Data Replacer Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code 2nd Option Code...
  • Page 73 Configure Your FuzzyScan ♦ ♦ ♦ ♦ Data Organizer Setting ♦ ♦ ♦ ♦ Family Code Selection Parameter Selection Option Code 2nd Option Code...

  • Page 74: Condensed Datawizard

    Configure Your FuzzyScan [Data Verifier, Data Replacer, Data Organizer] Select a Bar Code Symbology Select a Bar Code Symbology Select a Bar Code Symbology Select a Bar Code Symbology If there is a 11-character data string, please refer to the You can select one or all types of bar code symbologies to following to calculate the actual position for identification.
  • Page 75 Configure Your FuzzyScan Programming Procedure Programming Procedure Programming Procedure Programming Procedure [Data Verifier] [Data Replacer] Scan “Program” to enter the programming mode. Scan “Replacer Control” and set bar code symbology to “48”. Scan “Verifier Control” and set bar code symbology to “48” (Interleaved 2 of 5).
  • Page 76 Appendix Each AIM Code Identifier contains the three-character string ]cm where: ] = Flag Character c = Code Character m = Modifier Character...

  • Page 77: Keyboard Function Code Table

    Appendix ANSI ASCII Key Function ANSI ASCII Key Function To emulate the keyboard function key input for user definable parameters, user must configure actual content using the Reserved ASCII 0 – 31 characters, and also Enable the “Function Key Emulation”. Otherwise, the Ctrl output will be done by the scanner.

  • Page 78: Option Codes

    Appendix To configure the user definable parameters of FuzzyScan via HEX/ASCII Reference Table programming menu, FuzzyScan will ask you to scan your desired ASCII value in HEX form. You have to refer to the “HEX/ASCII Table” for details. Example: If you want the scanned data output leading with a Dollar Sign, you have to set the “Preamble”...
  • Page 79 Appendix...
  • Page 80 Appendix Uninstall SPP Slave Mode PAIR Mode HID Mode SPP Master Mode PICO Mode Trigger Mode Presentation Mode...
  • Page 81 Appendix (Work with Smart Cradle only) RS232 Serial PS/2 (DOS/V) KBW Standard Mode USB HID Standard Mode Keyboard Replacement PS/2 (DOS/V) KBW Turbo Mode USB HID Turbo Mode USB Com Port Emulation...
  • Page 82 Appendix FIN (Finish) END (Exit)
  • Page 83 Appendix Enable Variable PIN Code Disable Variable PIN Code BT PIN Code Please refer to Quick Reference Guide of “Connecting FuzzyScan Bluetooth Cordless Scanners with your Apple iOS Devices” for more details.
  • Page 84 Appendix PROGRAM Save Configuration (Enter Programming Mode) Sleep FIN (Finish) Clone Paging Factory Default (Exit Programming Mode) PowerTool Host Link System Information List Master Default (SYSLIST) Save User Default User Default...
  • Page 85 Appendix Link Indicator Status Indicator Descriptions Link Indicator Beeper Descriptions Status Indicator Beeper...
  • Page 86 Appendix Center Indicator Side Indicators Descriptions Power Beeper Indicators Descriptions Beeper Center Side...
  • Page 87 FuzzyScan Wireless Reference Manual CINO GROUP www.cino.com.tw PC WORTH INT’L CO., LTD.
