Lightolier Lytespan 6296 Specification

Page 1 of 2
8 1
2 1/4" Dia.
6 1/4"
Ordering Information
Catalog No. Mounting
6296 All Lytespan Track Systems
6297
6497
Matte Black Framing Projector (For performance data see Lightolier Specification Sheet 6497)
Features
1. Transformer Housing: Die-cast aluminum. Fitter twists onto track and
locks on.
2. Housing: Die-cast aluminum.
3. Lamp Guard: Tempered glass.
4. Trunion Mounting: Tensioned, provides 90° vertical adjustment for
lighting unit.
5. Pivot Mounting: Tensioned; 90° horizontal stop for each side.
6. Movable Brass Contact: Extends for connection to 2nd circuit in Advent
Lytespan Track.
7. Polarity Key
8. Push Tab: Molded polycarbonate. Detaches unit.
Electrical/Dimming
Light-weight, electronic, low voltage transformer with integral radio frequency
interface filter; soft-start feature for longer lamp life. Constant output lamp
voltage to maintain rated lamp life and light output. Two-pin base socket,
pre-wired with No. 18 braided SF-1 leads with fiberglas braided outer sleeve.
For dimming control, use only those dimmers specifically designed for use with
electronic transformers like Lightolier's Sunrise and Neptune Momentum QE
series. Call (800) 526-2731 for further information.
Lytespan
5 6
4
Finish
Matte White
Matte Black
Options and Accessory
2" Series Color Filters and Spread Lens; Louver No. 7472.
Finish
All painted finishes baked enamel.
Labels
UL, I.B.E.W.
Lightolier
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • C0607
Track Lighting System
®
7
3
3 7/8"
Lamps
20W-65W, MR-16 12V
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
a Genlyte company
MR16 Ring Electronic
Framing Projector
Accessory
(Order Separately)
2
Type:
www.lightolier.com
6296
6296
6297
6497
