10" RANDOM ORBIT POLISHER/WAXER
WITH ERGONOMIC HANDLE
Model 43424
ASSEMBLY AND OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
©
®
Copyright
2003 by Harbor Freight Tools
. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.

Advertisement

Table of Contents
loading

Related Manuals for Chicago Electric 43424

Summary of Contents for Chicago Electric 43424

  • Page 1 10” RANDOM ORBIT POLISHER/WAXER WITH ERGONOMIC HANDLE Model 43424 ASSEMBLY AND OPERATING INSTRUCTIONS ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at: http://www.harborfreight.com © ® Copyright 2003 by Harbor Freight Tools . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.

  • Page 2: Product Specifications

    PRODUCT SPECIFICATIONS E194601 Item Description Electrical Requirements 120 Volt / 60 Hz / Single Phase / .75 Amp Pad Diameter 10” Oscillations Per Minute 3,000 Orbital Design Direct Drive Power Switch Type Toggle Accessories Waxing Bonnet (1) / Polishing Bonnet (1) Weight 4.70 Pounds SAVE THIS MANUAL...

  • Page 3: Electrical Safety

    Keep bystanders, children, and visitors away while operating a power tool. Distractions can cause you to lose control. Protect others in the work area from debris such as chips and sparks. Provide barriers or shields as needed. ELECTRICAL SAFETY Grounded tools must be plugged into an outlet properly installed and grounded in accordance with all codes and ordinances.
  • Page 4 Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting. Be sure the Power Switch is off before plugging in.

  • Page 5: Specific Safety Rules

    Check for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect the tool’s operation. If damaged, have the tool serviced before using. Many accidents are caused by poorly main- tained tools. Use only accessories that are recommended by the manufacturer for your model.
  • Page 6 Avoid unintensional starting. Make sure you are prepared to begin work before turning on the Polisher/Waxer. Do not force the Polisher/Waxer. This tool will do the work better and safer at the speed and capacity for which it was designed. Do not force the rotating Pad (part #20) into the vehicle being waxed/polished.

  • Page 7: Grounded Tools: Tools With Three Prong Plugs

    GROUNDING WARNING! Improperly connecting the grounding wire can result in the risk of electric shock. Check with a qualfified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify the power cord plug provided with the tool.

  • Page 8: Double Insulated Tools: Tools With Two Prong Plugs

    DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS Tools marked “Double Insulated” do not require grounding. They have a special double insulation system which satisfies OSHA requirements and complies with the applicable standards of Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code. (See Figure B.) Double insulated tools may be used in either of the 120 volt outlets shown in the following illustration.
  • Page 9 If you are using an extension cord outdoors, make sure it is marked with the suffix “W-A” (“W” in Canada) to indicate it is acceptable for outdoor use. Make sure your extension cord is properly wired and in good electrical condition. Always replace a damaged extension cord or have it repaired by a qualified electrician before using it.
  • Page 10 UNPACKING When unpacking, check to make sure all the parts shown on the Parts List on page 14 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. ASSEMBLY AND OPERATING INSTRUCTIONS IMPORTANT Carefully inspect the condition of the accessory before use and check the accessory...
  • Page 11 sweeping strokes in a criss-cross pattern . Apply the wax evenly over the surface of the vehicle, and add additional wax as needed. After the wax has been applied to the vehicle’s surface, turn the Power Switch (part #26) to its “OFF” position. Then unplug the Power Cord (part #25) from the electrical extension cord, and unplug the extension cord from the grounded, 120 volt, electrical outlet.

  • Page 12: Inspection, Maintenance, And Cleaning

    Grip the Polisher/Waxer firmly with both hands. Then turn the Power Switch (part #26) to its “ON” position and allow the Pad (part #20) to rotate to its fullest speed. (See Figure D.) Begin polishing the vehicle by lightly buffing off the wax residue in a circular pattern.

  • Page 13: Please Read The Following Carefully

    The Waxing/Polishing Bonnets (parts #30, #31) may be machine-washed, in cold water, with detergent. Then, machine-dry the Bonnets at medium heat. Use only a clean cloth and mild detergent to clean the body of the Waxer/Polisher. Do not use solvents. Do not immerse any part of the tool in liquid.

  • Page 14: Parts List

    PARTS LIST Part # Description Qty. Part # Description Qty. Motor Thru Bolts Bearing Cover End Bell Assy. Bearing Motor Brush Set Pad Holder Sphere Bearing Armature Screw Magnet, Yoke Assy. Screw Cord Retainer Shim Screw Motor Plate Assy. Power Cord Power Switch Motor Bearing Bridge Rectifier...
