ORDER NO.
CPD0706228C1

Notebook Computer

CF-52AJYZDZM
Model No.
This is the Service Manual for
the following areas.
M ...for U.S.A. and Canada
© 2007 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOUGHBOOK CF-52AJYZDZM and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic TOUGHBOOK CF-52AJYZDZM

Summary of Contents for Panasonic TOUGHBOOK CF-52AJYZDZM

  • Page 1: Notebook Computer

    ORDER NO. CPD0706228C1 Notebook Computer CF-52AJYZDZM Model No. This is the Service Manual for the following areas. M …for U.S.A. and Canada © 2007 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 3 LASER SAFETY INFORMA TION For U.S.A. Class 1 LASER-Product This product is certified to comply with DHHS Rules 21 CFR Subchapter J. This product complies with European Standard EN60825 (or IEC Publication 825) For all areas This equipment is classified as a class 1 level LASER product and there is no hazardous LASER radiation. Caution: (1) Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

  • Page 6: Table Of Contents

    CONTENTS 1. Specifications ··················································································································1-1 2. Names and Functions of Parts ······················································································2-1 3. Block Diagram ···············································································································3-1 4. Diagnosis Procedure ·····································································································4-1 5. Power-On Self Test (Boot Check) ·················································································5-1 6. List of Error Codes <Only when the port replicator is connected> ································6-1 7. Self Diagnosis Test ········································································································7-1 8.

  • Page 7: Specifications

    1. Specifications This page provides the specifications for the basic model CF-52AJCBDBM / CF-52BJCBZBM / CF-52AJCHDBM / CF- 52CCABXBM / CF-52DCABZBM. The model number is different according to the unit configuration. To check the model number: Check the bottom of the computer or the box the computer came in at the time of purchase. To check CPU speed, memory size and the hard disk drive (HDD) size: Run the Setup Utility and select [Information] menu.
  • Page 8 Main Specifications Model No. CF-52AJCBDBM / CF-52BJCBZBM / CF-52CCABXBM / CF-52DCABZBM CF-52AJCHDBM Battery Pack Li-ion 11.1 V, 7.65 Ah Operating Time Approx. 3.5 hours to 4.5 hours Approx. 6.0 hours to 9.5 hours (Approx. 4.5 hours (Approx. 7.5 hours Approx. 4 hours Charging Time Clock Battery Coin type lithium battery 3.0 V...
  • Page 9 Wireless LAN <Only for model with wireless LAN> ® Intel Wireless WiFi link 4965 AGN (802.11 a + b + g) IEEE802.11a: 54/48/36/24/18/12/9/6 Mbps (automatically switched) Data Transfer Rates IEEE802.11b: 11/5.5/2/1 Mbps (automatically switched) IEEE802.11g: 54/48/36/24/18/12/9/6 Mbps (automatically switched) Standards Supported IEEE802.11a/IEEE802.11b/IEEE802.11g Transmission method OFDM system, DSSS system...

  • Page 10: Names And Functions Of Parts

    2. Names and Functions of Parts A : Speaker Hard disk drive status B : Multimedia pocket Power status C : SD Memory Card slot (Off: Power off/Hibernation, Green: Power on, Blink- ing green: Standby, Blinking green rapidly: Cannot D : Battery pack power on or resume due to low temperature.) E : Headphone jack Battery status...
  • Page 11 Right side EX PC 1394 Rear side Bottom LOCK A : Hard disk drive I : Security lock A Kensington cable can be connected. B : Smart Card slot For further information, read the manual that comes <Only for model with Smart Card slot> with the cable.

  • Page 12: Block Diagram

    3 Block Diagram Intel Intel® Core Core™ Duo 2 processor Duo 2 processor Processor Number T7300 Processor Number T7300 L2 Cache 4M L2 Cache 4M (uFCBGA) (uFCBGA) Clock Sp ock Speed eed 2GHz 2GHz Front Side Bus 800MHz Front Side Bus 800MHz (15.4”...

  • Page 13: Diagnosis Procedure

    4 Diagnosis Procedure 4.1.

  • Page 14: Troubleshooting

    4.2. Troubleshooting Please take note of the following two points with regard to troubleshooting: 1. Know-how of diagnosis upon occurrence of heavy troubles, e.g. ‘Set cannot be turned ON’, ‘Set fails to start’, ‘No display on screen’, etc. 2. Explanation of each trouble, mainly symptom of trouble in operation. Flow Chart Pay attention to the following points when in pursuit of the cause of a troubleshooting.

  • Page 15: Power-On Self Test (Boot Check)

    5 Power-On Self Test (Boot Check) Outline of POST The set has a boot check function called POST (Power-On Self Test) in it. The condition of the main body is diagnosed by checking beep sound or error code. z Start .....Test begins automatically when power switch is set to ON. z Normal finish ..After memory checking, a beep sound is issued once and the set is placed into automatic stop.

  • Page 16: List Of Error Codes

    6 List of Error Codes <Only when the port replicator is connected> The following is a list of the messages that BIOS can display. Most of them occur during POST. Some of them display information about a hardware device, e.g., the amount of memory installed.
  • Page 17 02D0 System cache error - Cache disabled Contact Panasonic Technical Support. 02F0: CPU ID: CPU socket number for Multi-Processor error. 02F4: EISA CMOS not writable ServerBIOS2 test error: Cannot write to EISA CMOS. 02F5: DMA Test Failed ServerBIOS2 test error: Cannot write to extended DMA (Direct Memory Access) registers. 02F6: Software NMI Failed ServerBIOS2 test error: Cannot generate software NMI (Non-Maskable Interrupt).

  • Page 18: Self Diagnosis Test

    7 Self Diagnosis Test As for the self-diagnosis test(PC-Diagnostic utility) to use this model, a standard test and the enhancing test by the module of the main body building in are possible. Notes To skip BIOS password Use <Ctrl>+<F10> key to skip BIOS password or authentication of fingerprint. This key is only for entering DIAG mode.
  • Page 19 2. Operation of PC-Diagnostic Utility -Only the device which can be inspected on the entire screen is displayed. -The item does not appear when the device of wireless LAN etc. is not physically connected. -The movement of the item must use an arrow key or a flat pad. -As for the device under the diagnosis, blue and yellow are alternately displayed at the left of the icon.
  • Page 20 2-1. Selection of tested device -To test only a specific device, "Test" and "Do not test" of each device can be selected. -The device which can select the enhancing test changes in order of "The standard is tested" and "Do not test"...
  • Page 21 3. Test Item and Division of trouble Enhan- Place with possibili- Test item Stanard Content of standard test Content of enhancing test cing ty of breakdown CPU is shifted to protected mode, and "Violation of the paging", "Operation of CPU / CPU / the violation of a privileged instruction", Main board...

  • Page 23: Wiring Connection Diagram

    8 Wiring Connection Diagram SPEAKER (R) SPEAKER (L) SERIAL PCB SW LED MDC PCB CN4000 CN4001 CN4201 SERIAL PORT CN4200 CN4202 CN4203 INVERTER EX/PC CARD EJECTOR EXTERNAL EXPANTION Connector by Cable DISPLAY CN29 CN30 Direct connection by Connectors CN28 Parts on Bottom Side MODEM JK1000 DC-IN...

  • Page 24: Disassembly/Reassembly

    9 Disassembly/Reassembly Note: Power off the computer. Do not shut down to the Suspend or hibernation mode. Do not add peripherals while the computer is in the Suspend or hibernation mode; abnormal operation may result. 9.1. Disassembly Instructions 9.1.1. Disassembly Flowchart The chart below shows the various parts which should be removed in order to remove the parts that are to be replaced.

  • Page 25: Dvd Multi Drive

    9.1.2. Preparation 9.1.3.2. HDD Mounting Kit Before disassembling, be sure to make the following prepara- 1. Pull out the HDD Mounting Kit with sliding the Lock Knob tions. (HDD). • Shut down Windows and turn off the power. 9.1.3.3. DVD Multi Drive •...
  • Page 26 9.1.5. Removing the Tilt Panl Ass’y 9.1.6. Removing the DIMM Memory Card 1. Turn the Cover down and pull the Tilt Panel in the direc- 1. Remove the Screw <N10>, and remove the DIMM Cover. tion of arrows. <N10> DIMM cover Tilt panel 2.

  • Page 27: Wireless Lan Module

    9.1.7.1. Wireless LAN Module white, blue and grey). Remove the two Screws <N2>, and BIOS HIGH PCB. 1. Remove the two Screws <N2> and two Cables(Gray and Blue). 2. Pull out the Wireless LAN Module in the direction of Speaker holder arrows.
  • Page 28 9.1.9. Removing the LCD unit, Inverter 9.1.10. Removing the Handle Ass'y Ass’y and ANTENNA PWB L,R 1. Remove the two Handle Sheets and two Screws <K172>, remove the Handle Ass’y. 1. Remove the two LCD Rubbers and five LCD Sheets. 2.

  • Page 29: Removing The Modem

    9.1.11. Removing the Modem 9.1.12.2. Speaker R 1. Disconnect the Cable from the Connecor(CN4200). 1. Remove the Speaker Holder R, and remove the Speaker 2. Remove the two Screws <N2>, and remove the Modem. 9.1.12.3. Speaker L <N2> 1. Remove the Tape, and remove the Speaker L. 9.1.13.

  • Page 30: Removing The Top Cover

    9.1.14. Removing the Top Cover Screws <N12> : DXSB2+4FNLT Screws <N14> : XTB26+10GJKT 1. Remove the Gasket. 2. Remove the Screws <N2>, <N4>, <N9> and ten Screws 9.1.15. Removing the Pad and TOUCH PAD <N14> 1. Remove the six Screws <N12>. <N14>...
  • Page 31 9.1.17. Removing the WWAN PCB 9.1.19. Removing the PWR BATTERY LED 1. Disconnect the Cables(Gray and Blue) from the WWAN PCB. 1. Remove the PWR BATTERY LED PCB, and disconnect 2. Remove the two Screws <N2> and the Screw <N9>. the Cable from the Connector(CN4400).
  • Page 32 9.1.20. Removing the KBD Earth Plate 9.1.21. Removing the Hinge Support R 1. Remove the Tape in the direction of arrow. 1. Peel off the Tape and remove the Screw <N4>. 2. Disconnect the Cable from the Connector (CN7). Tape 3.

  • Page 33: Removing The Battery Connector

    9.1.23. Removing the Hinge Support L and Screw <N5> : DRHM0112ZA Screw <N6> : DRHM0115ZA MP Hold Plate 1. Peel off the three Tapes and remove the two Cables(Gray 9.1.25. Removing the SC RELAY PCB and and Blue). HDD Hold Plate 2.
  • Page 34 9.1.27. Removing the SERIAL PCB 1. Remove the two Screws <N1> and Hex Spacer. 2. Remove the SERIAL PCB. Hex spacer <N1> <N1> SERIAL PCB Screw <N1> : DFHE5035ZB 9.1.28. Removing the MAIN HIGH PCB 1. Remove the two Screws <N1>, four Screws <N4> and two Screws <N13>.

  • Page 35: Reassembly Instructions

    9.2. Reassembly Instructions 9.2.1. Attention when CF-52 series is repaired • Please execute writing BIOS ID when you exchange the Main Board. • You cannot reuse the Conductive Clothes and the heat dissipating parts such as Sheet and Rubber. Use new parts. 9.2.2.
  • Page 36 ■ Setting of Main PCB before assembling. 9-13...
  • Page 37 9-14...
  • Page 38 9.2.3. Setting the SERIAL PCB 1. Set the SERIAL PCB to the computer. 2. Fix the SERIAL PCB using the two Screws <N1>. No1, No.2 3. Tighten the Hex Spacer to the SERIAL PCB. No.3 Hex spacer :No.3 <N1> :No.2 <N1>...
  • Page 39 9.2.5. Setting the Fan Ass’y 1. Fix the Fan Case Plate to the Fan Case using the three Screws <N2>. 2. Fix the Fan to the Fan Case using the three Screws <N12>. 3. Set the Fan Ass’y to the computer, and fix it using two Screws <N4>. No.1, No.2 <N12>...
  • Page 40 9-17...
  • Page 41 9.2.6. Setting the SC RELAY PCB and HDD Hold Plate 1. Set the SC REALY PCB to the HDD Hold Plate, and fix it using two Screws <N2>. No.1, No.2 2. Fix the HDD Hold Plate to the MAIN HIGH PCB using the two Screws <N4>. No.3, No.4 3.
  • Page 42 9.2.7. Setting the Battery Connector Ass’y 1. Fix the Batt Con Holder to the FPC Batt using the two Screws <N5>. 2. Fix the Batt Con Holder to the Batt FPC Plate using the two Screws <N6>. 3. Fix the Batt FPC Plate to the computer using the two Screws <N4>. No.1, No.2 4.
  • Page 43 9.2.9. Setting the Hinge Cover R 1. Place the Cable through the rectangled hole of Hinge Support R and connect the Cable to the Connector (CN7). 2. Fix the Hinge Support R to the computer using the Screw <N4>. <N4> Tape Hinge support R Cover PC card...
  • Page 44 9.2.10. Setting the KBD Earth Plate 1. Set the KBD Earth Plate to the computer. 2. Fix the KBD Earth Plate using the four Screws <N4>. No.1 to No.4 3. Fix the KBD Earth Plate using the two Screws<N13>. <N13> <N4>:No.3 <N4>:No.2 <N4>:No.1...
  • Page 45 9.2.11. Setting the PWR BATTERY LED PCB 1. Connect the Cabel to the Connector(CN4400), and insert it to the computer. Cable CN4400 PWR BATTERY LED PCB Bottom case ass'y 9-22...
  • Page 46 9.2.12. Setting the AUDIO PCB 1. Connect the Cable to the Connector(CN3000). 2. Set the AUDIO PCB to the computer, and fix it using the two Screws <N4>. No.1, No.2 <N4>:No.1 AUDIO PCB CN3000 <N4>:No.2 Cable Screw <N4> : DRHM0093ZA ■Arranging the Cable and setting the WL button.
  • Page 47 9.2.13. Setting the WWAN PCB 1. Connect the FPC to the Connector(CN7002). 2. Set the WWAN PCB, and fix it using two Screws <N2> and the Screw <N9>. No.1 to No.3 3. Connect the Cable(Gray) to JK7002 and Cable(Blue) to JK7004. <N9>:No.3 <N2>:No.2 <N2>:No.1...
  • Page 48 9.2.14. Setting the SD PCB 1. Connect the FFC to the Connector(CN4300). 2. Set the SD PCB to the Top Cover, and fix it to using the two Screws <N12>. No.1, No.2 <N12> <N12> CN4300 SD PCB Screw <N12> : DXSB2+4FNLT 9.2.15.
  • Page 49 9.2.16. Setting the Top Cover 1. Connect the KBD FPC and FFC to the Connectors(CN22 and CN23), and place the Top Cover on the computer. 2. Fix the Top Cover using the five Screws <N8>. No.1 to No.5 3. Fix the Top Cover using the Screw <N12>. 4.

  • Page 50: Setting The Keyboard

    9.2.17. Setting the Keyboard 1. Connect the FPCs to the Connector on the KBD FPC. 2. Place the Keyboard Lid Plate on the Top Cover, and fix it using the four Screws <N2>. No.1 to No.4 <N2>:No.2 <N2>:No.3 Key board lid plate <N2>:No.4 <N2>:No.1 Connectors...
  • Page 51 ■Caution for when assembling the Keyboard. 9-28...
  • Page 52 9.2.18. Setting the Speakers 1. Place the Speakers on the computer. 2. Connect the Cables to the Connector(CN4202 and CN4203). 3. Paste the Tape on the Cable. 4. Attach the Speaker Holder R to the computer. Speaker Tape Speaker holder R Cable CN4202 CN4203...
  • Page 53 ■How to paste the Tape 9-30...
  • Page 54 9.2.20. Setting the Handle Ass’y 1. Assemle the Handle Ass’y (Grip Upper, Grip Lower, Handle Base L, Handle Base R, Handle Ring and Handle Pom), and fix them using the two Screws <K92-5>. 2. Fix the Handle Base Ass’y to the computer using the two Screws <K172>. Paste the Handle Sheet on the Screws <K172>.
  • Page 55 9.2.21. Setting the LCD Unit, Inverter Ass’y and Antenna PWB L, R 1. Set the LCD Unit to the LCD Rear Cover 2. Fix the Inverter Ass’y using the Screw <N12>. 3. Fix the Anttena PWB L and R using the Screws <N2>. LCD unit <N12>...
  • Page 56 ■Setting of LCD unit ass’y LCD DAMPER D Using JIG LCD DAMPER A LCD DAMPER B Gasket LCD DAMPER C Gap within 0.5mm Using JIG Alminium (silvery) paster is stuck on the gasket. Gasket Paster Pressurizing range Schematic for sticking at Point A SHIELD SHEET A SHIELD SHEET B SHEET...
  • Page 57 ADHESIVE TAPE B ADHESIVE TAPE B ADHESIVE TAPE A Do not exceed Do not exceed the edge. the edge. Do not exceed the edge. 9-34...
  • Page 58 Safety Working S1:Insulation S2:Pinching Cables S3:Sharp Edge CAUTION S4:Part No. Check S5:Others The Cable is under the base plate Along the slot Along the slot PWB ANT L SCREW PWB ANT R SCREW Tape shall not cover the round hole Tape shall not cover the round hole LCD REAR COVER TAPE...
  • Page 59 SHEET Note: Paster shall be firmly stuck and Note: Paster shall be firmly stuck and does not float. does not float. Note: Do not exceed the edge of the metal frame LCD ASS'Y There are total 12 gaskets indicated by yellow arrows which must be installed surely.
  • Page 60 9-37...
  • Page 61 9.2.22. Setting the Display Unit, BIOS HIGH PCB and SW LED MDC PCB 1. Set the Display Unit to the computer, and fix it using the four Screws <N4>. No.1 to No.4 <N4> <N4> :No.1 :No.2 Display unit <N4> <N4> :No.4 :No.3 2.
  • Page 62 6. Fix the SW LED MDC PCB using the six Screws <N2>. No.1 to No.6 <N2> :No.6 <N2> :No.3 <N2> :No.2 <N2> :No.5 <N2> :No.4 <N2> :No.1 SW LED MDC PCB Screw<N2> : DFHE5122YA Screw <N4> : DRHM0093ZA ■Arranging the Cables when assembling the LCD Unit. 9-39...
  • Page 63 9-40...
  • Page 64 ■Arranging the Speaker Cables when assembling the SW LED MDC PCB. 9.2.23. Setting the Wireless LAN Module, BIOS PCB and ROBSON Cover 1. Put the Wireless LAN Module into the connector at an angle of fourty-five degrees. 2. Attach the BIOS PCB to the MAIN HIGH PCB, fix it using the two Screws <N2>. 3.
  • Page 65 9.2.24. Setting the DIMM Memory Card and DIMM Cover 1. Put the DIMM Memory Card into the connector. 2. Close the right and left Hooks, and paste the Tape. DIMM memory card DIMM memory connector Hook 3. Set the DIMM Memory Card, and fix it using the Screw <N10>. <N10>...
  • Page 66 2. Open the Cover, push the Tilt Panel Ass’y into the computer until it clicks. Tilt panel Tilt panel Cover Screw <N202> : DRSB2+4FKLT ■Caution for when assembling the Tilt Panel Ass’y 9-43...
  • Page 67 9.2.26. Setting the HDD 1. Connect the HDD FPC Ass’y to the HDD. 2. Insert the HDD Ass’y into the HDD Damper. 3. Set the HDD Ass’y into the HDD Case Upper. 4. Attach the HDD Case into the HDD Case Upper Ass’y Hook HDD case upper Hook...

  • Page 68: Exploded View

    10 Exploded View E N202 K214 K120 E N202 K213 E N202 K216 K212 K121 K215 K212 K140 K218 K217 E201 K211 K151 K176 K175 K155 H N8 K154 K160 H N8 E N9 K159 E N9 E N2 K160 K174 F N2 K125...
  • Page 69 K93-3 K152 K93-4 K134 K158 H N4 H N4 K143 H N4 K157 K157 H N13 K153 K142 K153 K93-1 K132 H N4 K93-2 K103 K158 K138 K141 K137 K93-5 K142 K156 K139 K138 K101 K139 K104 K138 K136 K105 K105 K139 K145...
  • Page 70 DM1-1 K130 K129 K119 K118 K117 K127 K126 K147 K161 K149 K150 K148 K162 K201 K168 K92-4 K170 K92-9 K92-2 K92-8 K92-3 K166 K92-2 K92-6 K163 K92-2 K92-3 K165 K167 K221-3 K92-1 K92-9 K172 K92-8 K92-5 K221-6 K173 K170 K221-5 K116 K115 K92-7...
  • Page 71 E16-2 H N4 E16-1 E N2 E15-1 H N4 E15-2 K23 H N4 E N2 H N4 E N2 E N12 B N15 H N4 H N4 H N4 Screw tightening torque 0.18 ± 0.02 N.m 0.44 ± 0.02 N.m H N4 (1.8 ±...

  • Page 72: Replacement Parts List

    Replacement Parts List Note : Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-52AJYZDZM NRP: Non Reusable Parts REF. NO and　AREA PART NO. DESCRIPTION Q'TY Main Block Unit DL3U11616AAA...
  • Page 73 DFPE0875ZCT ACCESSORY HOLDER DFPK1234ZAT PACKING CASE DFPH0077ZAT PROTECTION SHEET DFPP0136ZAT PROTECTION BAG Mechanical Parts DFHR3G84ZB LCD DAMPER A DFHR3G85ZC LCD DAMPER B DFHR3G86ZC LCD DAMPER C DFHR3G87ZA LCD DAMPER D DFMC0770ZA CONDUCTIVE TAPE DFHE1071ZB CONDUCTIVE TAPE DFMC0889ZA SHIELD SHEET A DFMC0890ZA SHIELD SHEET B DFHR3J68ZA...
  • Page 74 DFHR3G78ZA FIN DUCT DFMC0895ZA EARTH PLATE PORTRE DFHE1061ZA GASKET-6-6-20 DFHR3G83ZA BOTTOM WP CUSHION DFUN0056ZA PORT RE COVER SPRING S DFKE0555YA-0 PORTRE COVER DFME0138ZA SHUTTER HOLD PLATE DFMX1294ZB INSULATION SHEET POTORE DFMC0804ZB EARTH PLATE PORTRE L DFMD9098ZC KENGSINTONG PLATE ASS'Y DFHR3J14ZA PORTRE SHEET DFHR3J88ZA CUSHION-B...
  • Page 75 K114 DFHG2034ZB-0 FOOT RUBBER K115 DFHE1089ZA GASKET-3-3-65 K116 DFHE1088ZA GASKET-65TSV2.5-1.5-20 K117 DFHR6342ZB MODELAN HOLDER-1 K118 DFMX1311ZA INSULATION SHEET LAN K119 DFHR6343ZB MODELAN HOLDER-2 K120 DFHM0430ZA KBD LID PLATE K121 DFHR3G76ZB KBD LID SHEET K122 DFHR6344ZB SC EJECTER DUMMY K123 DFMD7B33ZC SMART CARD HOLDER K124 DXHM0040ZA...
  • Page 76 K212 DFGE0132ZB-0 CENTER COVER NET K213 DFGX0493ZA-0 TILT PANEL K214 DFHR3H21ZA TILT PANEL SHEET K215 DFHR3H77ZC TILT PANEL WP SHEET K216 DFHR3H78ZB TILT PANEL WP SHEET B K217 DFHR3H79ZB TILT PANEL WP SHEET C K218 DFHR3H99ZC KBD TAPE K221 DFWV99A0120 HDD MOUNTING KIT K221-1 DFGX0492ZC-0...
  • Page 77 Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components use only manufacturer's specified parts. CF-52AJYZDZM REF. NO and AREA PART NO. DESCRIPTION Q'TY MAIN PCB IC 1 C2GBD0000033 IC 2 C1CB00002803...
  • Page 78 C 41, 107, 110, 194, 195, F1J0J4750019 CAPACITOR, 6.3V, 4.7µF 236, 312, 328, 334, 336, 339, 400, 416, 471, 473, 486, 487, 499, 546, 547, 560, 583 C 45, 421, 422, 423, 439, F1G1H102A496 CAPACITOR, 50V, 1000pF 488, 558, 588, 598, 600, 612, 732, 1041, 1043, 1048, 1082, 1085, 1089, 1134, 1141, 1216, 1219...
  • Page 79 C 420, 1005 F1G1H271A495 CAPACITOR, 50V, 270pF C 434, 435, 436, 437, 496, F1H1A1050015 CAPACITOR, 10V, 1µF 503, 523, 524, 529, 530, 592, 616, 617, 632, 633, 634, 635, 1102, 1177 C 443, 444, 1132 F1G1H330A542 CAPACITOR, 50V, 33pF C 465 F1L3D102A003 CAPACITOR, 2000V, 1000pF C 468, 1045, 1083...
  • Page 80 CN 1000 K1KB40AA0217 CONNECTOR D 2, 3, 10, 17, 18 MA2J72900L DIODE D 4, 7, 29, 1033, 1039, MA3J741E0L DIODE D 8, 9, 22, 23, 30, 31, 33, B0KB00000044 DIODE D 19, 20, 21, 25, 26, 27, B0ADDH000004 DIODE 28, 1030, 1031, 1032 D 24, 1027, 1029, 1042 MA2S111-TX DIODE...
  • Page 81 JK 1000 S K2EEYB000001 JACK JK 8101, 8102 K1QZA1AE0001 CONNECTOR G1C91NM00001 INDUCTOR G1C1R0Z00002 INDUCTOR L 5, 7, 8, 12, 17, 67, 68 J0JJC0000021 INDUCTOR L 10, 13 G1C1R0MA0076 INDUCTOR L 11 INDUCTOR DDAZR100KTD L 16, 64 J0JGC0000038 CHIP BEADS L 20, 25, 26, 43, 44 J0JDC0000105 CHIP BEADS L 22, 33, 34, 47, 48...
  • Page 82 R 10, 11, 31, 333, 334, D1BA1000A023 RESISTOR, 1/16W, 100Ω 335, 336, 341, 342, 343, R 14, 16 D1BA27R4A023 RESISTOR, 1/16W, 27.4Ω R 15, 17, 36, 37 D1BA54R9A023 RESISTOR, 1/16W, 54.9Ω R 19 D0GA680JA023 RESISTOR, 1/16W, 68Ω R 20, 24, 25, 257, 305, D0GA560JA023 RESISTOR, 1/16W, 56Ω...
  • Page 83 R 159, 163, 366 D1H85604A024 RESISTOR ARRAY R 168, 169, 206, 207 D0GA150JA023 RESISTOR, 1/16W, 15Ω R 173, 187, 188, 203, 205, D1H81034A024 RESISTOR ARRAY 222, 264, 375, 423, 439, 473, 587, 589 R 174, 457 D1H83304A024 RESISTOR ARRAY R 180, 183, 184, 202, 265, D0GA330JA023 RESISTOR, 1/16W, 33Ω...
  • Page 84 R 1011 D1BA3093A023 RESISTOR, 1/16W, 309KΩ R 1012 D1BA1052A023 RESISTOR, 1/16W, 10.5KΩ R 1013 D1BA2151A023 RESISTOR, 1/16W, 2.15KΩ R 1015 D1BA2000A023 RESISTOR, 1/16W, 200Ω R 1016 D1BA2550A023 RESISTOR, 1/16W, 255Ω R 1021 D1BA1821A023 RESISTOR, 1/16W, 1.82KΩ R 1028 D0GB101JA065 RESISTOR, 1/16W, 100Ω R 1030, 1031, 1220 D0GB3R3JA065 RESISTOR, 1/16W, 3.3Ω...
  • Page 85 C 3036 F1G1C104A042 CAPACITOR, 16V, 0.1µF C 3037, 3038 F1G1H1010005 CAPACITOR, 50V, 100pF C 3039, 3040 F1H1A225A039 CAPACITOR, 10V, 2.2µF C 3047 ECUV1H103ZFG INDUCTOR D 3001, 3002 B3ACB0000020 DIODE D 3046 B0JCMD000014 DIODE IC 3052 C1CB00002733 AUDIO CODEC IC 3053 C1AB00002507 IC, AUDIO POWER AMPLIFIER IC 3054...
  • Page 86 Q 4300 UNR9113J0L TRANSISTOR R 4300 D0GD101JA052 RESISTOR, 1/8W, 100Ω R 4301 D0GA101JA023 RESISTOR, 1/16W, 100Ω SW 4301 K0ZZ00000619 PWR BATTERY LED PCB CN 4400 K1KA05BA0014 CONNECTOR D 4401 B3ABB0000210 DIODE D 4402 B3AGB0000040 DIODE SC RELAY PCB CN 6502 K1KA10BA0162 CONNECTOR CN 6503...
  • Page 87 L 5001 J0JJC0000021 INDUCTOR L 5003 G1C6N8JA0024 CHIP INDUCTOR Q 5000 B1GBCFNN0042 TRANSISTOR Q 5001 B1DHDC000028 TRANSISTOR R 5000, 5001 D0GA104JA023 RESISTOR, 1/16W, 100KΩ R 5002 D0GAR00J0005 RESISTOR, 1/16W, 0Ω...
